Camera |
|
|
Camera Hardware
Profile |
1/3.2 5 Megapixel CMOS
sensor |
|
20 metre IR
illumination distance |
|
Built-in Infrared-Cut
Removable (ICR) Filter module |
|
Minimum
illumination: |
|
0.5 Lux Color
mode |
|
0.1 Lux Black and White
mode |
|
0 Lux Black and White
mode with IR LED on |
|
Minimum object distance
0.3 m |
|
3 ~ 10.5 mm DC iris
vari-focal lens |
|
Aperture
F1.4 |
|
Angle of
view |
|
(H) 26.94 to
67.23 |
|
(V) 20.17 to
48.88 |
|
Shutter Speed: 1/2.5 ~
1/10,000 |
|
4x Digital
zoom |
|
|
|
Camera
Housing |
IP66 compliant
weatherproof housing |
|
IK-10 compliant
vandal-proof housing |
|
Included
sunshield |
|
|
|
Features |
Configurable image
size, quality, frame rate, and bit rate |
|
Time stamp and text
overlays |
|
3 Configurable motion
detection windows |
|
Tamper
detection |
|
Configurable privacy
mask zones |
|
Configurable exposure,
brightness, saturation, contrast, sharpness, white balance, WDR, flip and
mirror |
|
|
|
Video
Compression |
Simultaneous
H.264/MJPEG format compression |
|
H.264 multicast
streaming |
|
JPEG for still
images |
|
Video Resolution 16:9
1920x1080, 1280x720, 960 x 540, 640 x 360 at up to 30
fps |
|
4:3 - 2560x1920,
2048x1536, 1600x1200, 1280x960, 800 x 600, 640 x 480, 320 x 240 at up to
15 fps |
|
|
|
Audio
Support |
AAC |
|
G.711 |
|
|
|
External Device
Interfaces |
10/100 BASE-TX Ethernet
port with PoE |
|
1 DI / 1
DO |
|
Reset
button |
|
Video Out
(BNC) |
|
microSD card Slot
(SD/SDHC) |
|
Audio input /
output |
|
|
|
Network |
|
|
Network
Protocols |
IPv6 |
|
IPv4 |
|
TCP/IP |
|
UDP |
|
ICMP |
|
DHCP
client |
|
NTP client
(D-Link) |
|
DNS
client |
|
DDNS client
(D-Link) |
|
SMTP
client |
|
FTP
client |
|
HTTP /
HTTPS |
|
Samba
client |
|
PPPoE |
|
UPnP port
forwarding |
|
RTP / RTSP/
RTCP |
|
IP
filtering |
|
QoS |
|
CoS |
|
Multicast |
|
ONVIF
compliant |
|
SNMP |
|
|
|
Security |
Administrator and user
group protection |
|
Remote client access
control |
|
HTTP and RTSP
authentication |
|
HTTPS encryption for
web access |
|
|
|
System
Management |
|
|
System Requirements
for Web Interface |
Browser: Internet
Explorer 7 or higher, Firefox, Chrome, Safari |
|
|
|
Event
Management |
Motion
detection |
|
Event notification and
uploading of snapshots/video clips via e-mail or FTP |
|
Supports multiple HTTP,
SMTP, and FTP servers |
|
Multiple event
notifications |
|
Multiple recording
methods for easy backup |
|
|
|
Remote
Management |
Take snapshots/video
clips and save to local hard drive |
|
Configuration interface
accessible via web browser |
|
|
|
OS
Support |
Operating System:
Windows 10/8/7/2000/Vista/XP |
|
|
|
D-ViewCam System
Requirements |
Operating System:
Windows 10/8/7/2000/Vista/XP |
|
Web Browser: Internet
Explorer 7 or higher |
|
Protocol: Standard
TCP/IP |
|
|
|
D-ViewCam Software
Functions |
Remote
management/control of up to 32 cameras |
|
Supports all management
functions provided in web interface |
|
Viewing of up to 32
cameras on one screen |
|
Scheduled motion
triggered, or manual recording options |
|
|
|
General |
|
|
Weight |
1.25 kg (2.75
lbs) |
|
|
|
Power |
Input: 12 V DC 1.5 A.
50/60 Hz, IEEE 802.3af PoE Class 0 |
|
|
|
Power
Consumption |
Max:11.6 W (PoE, heater
on) |
|
|
|
Temperature |
Operating: -40 to 50 C
(-40 to 122 F) |
|
Storage: -20 to 70 C
(-4 to 158 F) |
|
|
|
Humidity |
Operating: 20% to 90%
non-condensing |
|
Storage: 5% to 95%
non-condensing |
|
|
|
Certifications |
CE |
|
CE
LVD |
|
FCC |
|
C-Tick |
