Essentials |
|
|
Vertical Segment |
Server |
|
Processor Number |
E3-1275V6 |
|
Status |
Launched |
|
Launch Date |
Q1'17 |
|
Lithography |
14 nm |
|
|
|
Performance |
|
|
# of Cores |
4 |
|
# of Threads |
8 |
|
Processor Base Frequency |
3.80 GHz |
|
Max Turbo Frequency |
4.20 GHz |
|
Cache |
8 MB |
|
Bus Speed |
8 GT/s DMI3 |
|
TDP |
73 W |
|
VID Voltage Range |
0.55V-1.52V |
|
|
|
Supplemental Information |
|
|
Embedded Options Available |
Yes |
|
Conflict Free |
Yes |
|
|
|
Memory Specifications |
|
|
Max Memory Size (dependent on memory type) |
64 GB |
|
Memory Types |
DDR4-2400, DDR3L-1866 |
|
Max # of Memory Channels |
2 |
|
Max Memory Bandwidth |
37.5 GB/s |
|
ECC Memory Supported |
Yes |
|
|
|
Graphics Specifications |
|
|
Processor Graphics |
Intel HD Graphics P630 |
|
Graphics Base Frequency |
350.00 GHz |
|
Graphics Max Dynamic Frequency |
1.15 GHz |
|
Graphics Video Max Memory |
1.7 GB |
|
Graphics Output |
eDP/DP/HDMI/DVI |
|
4K Support |
Yes, at 60Hz |
|
Max Resolution (HDMI 1.4) |
4096x2160@24Hz |
|
Max Resolution (DP) |
4096x2304@60Hz |
|
Max Resolution (eDP - Integrated Flat Panel) |
4096x2304@60Hz |
|
Max Resolution (VGA) |
N/A |
|
DirectX* Support |
12 |
|
OpenGL* Support |
4.4 |
|
Intel Quick Sync Video |
Yes |
|
Intel InTru 3D Technology |
Yes |
|
Intel Clear Video HD Technology |
Yes |
|
Intel Clear Video Technology |
Yes |
|
# of Displays Supported |
3 |
|
Device ID |
0x191D |
|
|
|
Expansion Options |
|
|
Scalability |
1S Only |
|
PCI Express Revision |
3 |
|
PCI Express Configurations |
1x16, 2x8, 1x8+2x4 |
|
Max # of PCI Express Lanes |
16 |
|
|
|
Package Specifications |
|
|
Sockets Supported |
FCLGA1151 |
|
Max CPU Configuration |
1 |
|
Package Size |
37.5mm X 37.5mm |
|
|
|
Advanced Technologies |
|
|
Intel Optane Memory Supported |
Yes |
|
Intel Turbo Boost Technology |
2 |
|
Intel vPro Technology |
Yes |
|
Intel Hyper-Threading Technology |
Yes |
|
Intel Virtualization Technology (VT-x) |
Yes |
|
Intel Virtualization Technology for Directed I/O
(VT-d) |
Yes |
|
Intel VT-x with Extended Page Tables (EPT) |
Yes |
|
Intel TSX-NI |
Yes |
|
Intel 64 |
Yes |
|
Instruction Set |
64-bit |
|
Instruction Set Extensions |
SSE4.1/4.2, AVX 2.0 |
|
Idle States |
Yes |
|
Enhanced Intel SpeedStep Technology |
Yes |
|
Thermal Monitoring Technologies |
Yes |
|
|
|
Intel Data Protection Technology |
|
|
Intel AES New Instructions |
Yes |
|
Secure Key |
Yes |
|
Intel Software Guard Extensions (Intel SGX) |
Yes |
|
Intel Memory Protection Extensions (Intel MPX) |
Yes |
|
|
|
Intel Platform Protection Technology |
|
|
OS Guard |
Yes |
|
Trusted Execution Technology |
Yes |
|
Execute Disable Bit |
Yes |
|
Intel Device Protection Technology with Boot Guard |
Yes |
