All stock codes associated to this product
112660420G, 11266-04-20G, VCSRX5704G04PULSE, VCS-RX5704G04PULSE, 4895106282025
Overview
For gamers on a slightly smaller budget, the SAPPHIRE Pulse Radeon RX 570 is
the card to pick for smooth 1080p gaming in high details @ 60 FPS. This model is
powered by 2048 GCN stream processors that run at a 1284 MHz boost clock. The
card is cooled using the quiet Dual-X two-fan solution, with an easy fan swap
Quick Connect system in place as well.
Black Diamond Choke 4
Our Black Diamond Chokes are 10% cooler and 25% more power efficient than a
normal choke - and these Mark 4 Chokes reduce the coil temperatures by other 15%
over the Mark 3s.
These exclusive chokes will maintain gaming stability using their built-in
heatsinks and help minimize coil whine.
Robust VRM Cooling
The SAPPHIRE NITRO+ cards are designed with robust VRM cooling and have a
high thermal conductivity pad on the backplate to take away the heat efficiently
and effectively.
Long life black polymer cap
High quality aluminum-made long life capacitor is not only to extend the
component life time, the product reliability and overclocking ability are also
improved. When operational temperatures dropped by 20°C, the product life span
is going to be extended up to a factor of ten. In addition, when the operational
temperature increased by 20°C, the product life span only decreased by 10%.
Fuse protection
In order to protect your card, the SAPPHIRE NITRO+ series cards have fuse
protection built into the circuit of the external PCI-E power connector to keep
the components safe.
Precision fan control
Standard industry fans may have up to 10% difference between their fan
rotation cycles (RPM). With the new Fan IC Control on SAPPHIRE NITRO + graphics
cards, this differential is reduced to 3%. This 70% improvement on accuracy
ensures that cooling and noise performance of every NITRO + card is up to
scratch.
NITRO Quick Connect
SAPPHIRE’s Quick Connect System provides a quick and easy solution. If
there’s a fan issue detected, the user doesn’t need to return the entire card –
SAPPHIRE’s partners will send out a replacement fan directly to the customer or
the retailer. Please contact your place of purchase to request a fan
replacement. SAPPHIRE’s channel partner will arrange the ideal solution for you
to receive your replacement fan.
VR Friendly
The SAPPHIRE NITRO Gaming Series cards come with Dual HDMI ports,
specifically designed to work with VR. By having two HDMI ports, you can have
both an HD monitor and cutting-edge VR headset running at the same time.
The ports are HDMI 2.0b, the latest update, with an 18Gbps bandwidth, up to
32 audio channels, and is able to support 4K 50/60 resolutions like 2160P,
whilst remaining entirely backwards compatible with older HDMI
specifications.
Frame Rate Target Control
Frame Rate Target Control (FRTC) enables users to set a target maximum frame
rate when playing an application in full screen mode; the benefit being that
FRTC can reduce GPU power consumption (great for games running at frame rates
much higher than the display refresh rate) and therefore reduce heat generation
and fan speeds/noise on the graphics card.
Frame Rate Target Control caps performance not only in 3D rendered in-game
scenes, but also in splash screens, loading screens and menus, where frame rates
can often run needlessly into the hundreds of FPS. Users might wish to set a
very high cap just to limit wasteful FPS like that seen in menus and such, while
still taking advantage of the responsiveness given by FPS well beyond 60.
DirectX® 12
DirectX® 12 is a new, “console-like” graphics API from Microsoft® that
empowers game developers with more direct and obvious control of PC hardware.
This direct or “explicit” control better exposes the hardware resources of AMD
Radeon™ GPUs to yield higher hardware throughput and, ultimately, more
performance for users. To put it simply: much more efficient hardware through
smarter software! At the discretion of a game developer, this superior
efficiency can be spent on higher framerates, lower latency (VR), lower power
consumption, better image quality, or some calculated balance of all four. In
any scenario, gamers stand to benefit greatly from choosing AMD hardware to run
their favorite DirectX® 12 game.
AMD Freesync technology
No stuttering. No tearing. Just gaming.
- AMD FreeSync technology allows a compatible graphics card and monitor to
dynamically change frame rates for the optimum display quality without tearing
or stuay.
Industry-Standard Displayport
- Freesync uses industry-standard displayport Adaptive-Sync Eliminates
screen tearing without all the usual lag and latency.
- Synchronizes the refresh rate of a compatible monitor to the frame rate of
your content, however much it varies.
- Monitor partners are validating with drivers from AMD now.
AMD XConnect Technology
Plug in and game on with AMD XConnect technology.
Now its easier than ever to connect and use an external Radeon graphics card.
With AMD XConnect technology, external GPU enclosures configured with Radeon
Graphics can easily connect and disconnect to a compatible ultrathin notebook or
2-in 1 over Thunderbolt 3 at any time, just like a USB flash drivea first for
external GPUs!
AMD Eyefinity Technology
Multidisplay technology for gaming, productivity and entertainment
We are taking you beyond the boundaries of traditional PC displays. AMD
Eyefinity technology expands the traditional limits of desktop computing by
multiplying your screen area. With multiple monitors, games become more
immersive, workstations become more useful and you become more productive (an
average of 42% more productive according to one study).
Take your PC games to the next level of reality and immersion. Most modern
games look great on three screens, and only AMD Radeon graphics offer you the
ability to play across five screens for an eye-popping gaming experience. Other
combinations and configurations with up to six screens work too.1 Create your
dream display.
AMD Crossfire
Harness the power of multiple GPUs
AMD CrossFire technology is the ultimate multi-GPU performance gaming
platform. Unlocking game-dominating power, AMD CrossFire harnesses the power of
two or more discrete graphics cards working in parallel to dramatically improve
gaming performance.1 AMD CrossFire technology ready graphics cards fit
practically every budget. With the flexibility to combine two, three or four
GPUs, AMD CrossFire technology is the perfect solution for those who demand
extreme performance.
HDR Ready
High Dynamic Range (HDR) is a state-of-the-art technology for gamers and
cinephiles that care deeply about the display quality of their TV or monitor.
Modeled after the acuity of human vision, HDR vastly expands the range of colors
and contrast ratios that can be shown by compatible displays. HDR-ready games
and movies played on an HDR display appear strikingly sharp, colorful, and
vivid, with enhanced contrast and sophisticated nuance compared to even the most
stunning SDR content.
Specifications
GPU |
2048 Stream Processors |
|
14 nm FinFET |
|
4th Graphics Core Next (GCN) |
|
1284 MHz Boost Engine Clock |
Memory |
256 bit Memory Bus |
|
GDDR5 Memory Type |
|
1750 MHz, 7000 MHz Effective |
|
4 GB Size |
BIOS Support |
UEFI BIOS |
Displays |
Maximum 5 Outputs |
Output |
1 x DVI-D |
|
2 x HDMI |
|
2 x DisplayPort 1.4 |
Resolution |
3840x2160 (120Hz) Pixel DisplayPort
Resolution |
|
2560x1600 (60Hz) Pixel Dual Link DVI
Resolution |
|
38402160p (60 Hz) HDMI Resolution |
API |
OpenGL 4.5 |
|
OpenCL 2.0 |
|
DirectX 12 |
|
Shader Model 5.0 |
Feature |
AMD CrossFire |
|
FreeSync Technology |
|
AMD Eyefinity |
|
AMD Xconnect ready |
|
DirectX 12 Optimized |
|
HDR Ready |
|
Frame Rate Target Control |
|
NITRO Quick Connect system |
|
Intelligent Fan Control III |
|
Black Diamond Choke 4 |
|
Fuse protection |
|
Radeon Chill |
|
Radeon Relive |
Cooling |
Dual-X fans |
Form Factor |
2 Part Slot Occupied |
|
230(L)X 125(W)X 40 (H) Dimension /mm |
Power Consumption |
<180W |
OS |
Windows 10Windows 7 |
System Requirement |
500 Watt Power Supply (Suggestion) |
|
1 x 8-pin AUX Power Connector |
|
Blue-ray / HD DVD playback requires Blu-ray / HD DVD
drive. |
|
PCI Express 2.0 or higher version based PC is required with one X16
lane graphics slot available on the motherboard in order for the card to
be compatible with. |
