All stock codes associated to this product
ArcherT4UHV2, Archer T4UH V2, NWTLARCHERT4UH, NWTL-ARCHERT4UH, 6935364097332
Overview
Features
- Upgrade your Wi-Fi to watch HD movies and quickly download files at fast
AC1300 speeds
- Selectable dual 2.4 GHz (400 Mbps) and 5 GHz (867 Mbps) bands
- High gain antennas deliver wider reach and stronger signal
- Set the adapter on the included dock and swivel the slim antenna to find
the perfect position
- WPS button lets you quickly connect to Wi-Fi
- Activate SoftAP mode to create a Wi-Fi hotspot so other devices can
connect
- OS compatibility includes Windows (XP 10), Mac OS X (10.6 10.11), Linux
(Kernel 2.6.18 ~ 3.19.3)
Overview
Upgrade to AC Wi-Fi Today
The Archer T4UH Wi-Fi Adapter upgrades laptops and PCs to fast AC1300 Wi-Fi
speeds for smooth HD streaming and quick downloads. Switch between dual 5 GHz
(867 Mbps) and 2.4 GHz (400 Mbps) bands to avoid crowded networks and Wi-Fi
slowdowns for speed and range in any situation.
AC1300 Wireless Speed
The 5GHz 867Mbps is perfect for HD video streaming and lag-free online
gaming, while using 2.4GHz 300Mbps Wi-Fi for normal use such as web surfing.
USB 3.0 - Up to 10X faster than USB 2.0
Experience blazing speed data transfers of up to 4.8Gbps with USB 3.0 - the
latest USB connectivity standard. USB 3.0 transfers data up to 10X faster than
USB 2.0 and is also backward compatible with USB 2.0. This high-speed transfer
rate combined with 802.11ac is ideal for HD streaming, online gaming and large
file downloads.
The Best of Both Bands
TP-LINKs Archer T4UH is an AC1300 Wireless Dual Band USB Adapter, giving
users the ability to access crystal clear 5GHz connections or legacy 2.4GHz
connections to upgrade their PCs wireless capabilities to operate with new 5GHz
band wireless networks, while ensuring that they can still access legacy 2.4GHz
band wireless networks.
Specifications
HARDWARE FEATURES |
Interface |
USB 3.0 |
Button |
WPS button |
Dimensions ( W x D x H ) |
3.52.70.7 in. (906816.8mm) |
Antenna Type |
Omni Directional |
|
|
WIRELESS FEATURES |
Wireless Standards |
IEEE 802.11ac, IEEE 802.11a, |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Frequency |
5GHz |
2.4GHz |
Signal Rate |
5GHz |
11ac: Up to 867Mbps(dynamic) |
11n: Up to 300Mbps(dynamic) |
11a: Up to 54Mbps(dynamic |
|
2.4GHz |
11n: Up to 300Mbps(dynamic) |
11g: Up to 54Mbps(dynamic) |
11b: Up to 11Mbps(dynamic) |
Transmit Power |
<20dBm (EIRP) |
Wireless Modes |
Ad-Hoc / Infrastructure mode |
Wireless Security |
Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x |
Modulation Technology |
DBPSK, DQPSK, CCK, 16-QAM, 64-QAM, 256-QAM |
|
|
OTHERS |
Certification |
CE, FCC, RoHS |
Package Contents |
Wireless Adapter Archer T4UH |
Resource CD |
Quick Installation Guide |
USB Cable |
System Requirements |
Windows 8.1 (32/64bits), Windows 8 (32/64bits), |
Windows 7 (32/64bits), Windows XP(32/64bits), |
Mac OS X 10.7~10.10, Linux |
Environment |
Operating Temperature: 0°C ~ 40°C
(32°F~104°F) |
Storage Temperature: -40°C~70°C (-40°F~158°F) |
Operating Humidity: 10%~90% non-condensing |
Storage Humidity: 5%~90%
non-condensing |
