Essentials |
|
Product collection |
Legacy Intel Core Processors |
|
Code Name |
Products formerly Ivy Bridge |
|
Vertical Segment |
Mobile |
|
Processor Number |
i7-3537U |
|
Status |
Launched |
|
Launch Date |
Q1'13 |
|
Lithography |
22 nm |
|
|
|
Performance |
|
# of Cores |
2 |
|
# of Threads |
4 |
|
Processor Base Frequency |
2.00 GHz |
|
Max Turbo Frequency |
3.10 GHz |
|
Cache |
4 MB SmartCache |
|
Bus Speed |
5 GT/s DMI |
|
TDP |
17 W |
|
|
|
Supplemental Information |
|
Embedded Options Available |
No |
|
Conflict Free |
Yes |
|
|
|
Memory Specifications |
|
Max Memory Size (dependent on memory type) |
32 GB |
|
Memory Types |
DDR3/L/-RS 1333/1600 |
|
Max # of Memory Channels |
2 |
|
Max Memory Bandwidth |
25.6 GB/s |
|
ECC Memory Supported |
No |
|
|
|
Graphics Specifications |
|
Graphics Base Frequency |
350 MHz |
|
Graphics Max Dynamic Frequency |
1.20 GHz |
|
Graphics Output |
eDP/DP/HDMI/SDVO/CRT |
|
Intel Quick Sync Video |
Yes |
|
Intel InTru 3D Technology |
Yes |
|
Intel Flexible Display Interface (Intel FDI) |
Yes |
|
Intel Clear Video HD Technology |
Yes |
|
# of Displays Supported |
3 |
|
Device ID |
0x166 |
|
|
|
Expansion Options |
|
PCI Express Revision |
2.0 |
|
PCI Express Configurations |
1x16, 2x8, 1x8 2x4 |
|
Max # of PCI Express Lanes |
16 |
|
|
|
Package Specifications |
|
Sockets Supported |
FCBGA1023 |
|
Max CPU Configuration |
1 |
|
TJUNCTION |
105°C |
|
Package Size |
31mm x 24mm (BGA1023) |
|
Low Halogen Options Available |
See MDDS |
|
|
|
Advanced Technologies |
|
Intel Turbo Boost Technology |
2.0 |
|
Intel vPro Technology |
No |
|
Intel Hyper-Threading Technology |
Yes |
|
Intel Virtualization Technology (VT-x) |
Yes |
|
Intel Virtualization Technology for Directed I/O
(VT-d) |
Yes |
|
Intel VT-x with Extended Page Tables (EPT) |
Yes |
|
Intel 64 |
Yes |
|
Instruction Set |
64-bit |
|
Instruction Set Extensions |
AVX |
|
Intel My WiFi Technology |
Yes |
|
4G WiMAX Wireless Technology |
Yes |
|
Idle States |
Yes |
|
Enhanced Intel SpeedStep Technology |
Yes |
|
Intel Demand Based Switching |
No |
|
Thermal Monitoring Technologies |
Yes |
|
Intel Fast Memory Access |
Yes |
|
Intel Flex Memory Access |
Yes |
|
Intel Identity Protection Technology |
Yes |
|
|
|
Security & Reliability |
|
Intel AES New Instructions |
Yes |
|
Secure Key |
Yes |
|
Intel Trusted Execution Technology |
No |
|
Execute Disable Bit |
Yes |
|
Anti-Theft Technology |
Yes |
