6TB |
|
Standard Model Number1 |
ST6000NE0023 |
|
Interface |
SATA 6Gb/s |
|
Features |
|
|
Drive Bays Supported |
Up to 16 Bays |
|
Multi-User Technology (TB/yr) |
300 |
|
Rotational Vibration (RV) Sensors |
Yes |
|
Hot-Plug Support2 |
Yes |
|
Cache (MB) |
256 |
|
Reliability/Data Integrity |
|
|
Mean Time Between Failures (MTBF, hours) |
1,200,000 |
|
Reliability Rating @ Full 247 Operation (AFR) |
0.73% |
|
Non-recoverable Read Errors per Bits Read, Max |
1 per 10E15 |
|
Power-On Hours per Year (247) |
8,760 |
|
Sector Size (Bytes per Logical Sector) |
512E |
|
Rescue Services3 |
Yes |
|
Limited Warranty (years) |
5 |
|
Performance |
|
|
Spindle Speed (RPM) |
7,200 |
|
Interface Access Speed (Gb/s) |
6.0, 3.0, 1.5 |
|
Max. Sustained Transfer Rate OD (MB/s) |
214MB/s |
|
Average Latency (ms) |
4.16 |
|
Interface Ports |
Single |
|
Rotational Vibration @ 10-1,500 Hz (rad/s2) |
12.5 |
|
Power Consumption |
|
|
Startup Current, Typical (12V, A) |
2 |
|
Idle Power, Average (W) |
7.5 |
|
Average Operating Power (W) |
8.1 W |
|
Standby Mode (W) |
0.6 |
|
Sleep Mode (W) |
0.6 |
|
Power Supply Requirements |
+12 V and +5 V |
|
Environmental/Temperature |
|
|
Operating (ambient, min C) |
5 |
|
Operating (drive case, max C) |
60 |
|
Non-operating (ambient, min C) |
-40 |
|
Non-operating (ambient max C) |
70 |
|
Environmental/Acoustics |
|
|
Vibration, Non-operating: 10 Hz to 500 Hz
(Grms) |
3 |
|
Environmental/Shock |
|
|
Shock, Operating 2 ms (Read/Write) (Gs) |
70/40 Gs |
|
Shock, Non-operating, 1 ms and 2 ms (Gs) |
250 |
|
Physical |
|
|
Height (mm/in) |
26.11 mm/1.028 in |
|
Width (mm/in, max) |
101.85 mm/4.01 in |
|
Depth (mm/in, max) |
146.99 mm/5.787 in |
|
Weight (lb/g) |
705 g/1.55 lb |
|
Carton Unit Quantity |
|
|
Cartons per Pallet / Cartons per Layer |
|
