Features
Intel Z370 Ultra Durable motherboard with HDMI 2.0a 21:9 / HDR, PCIe
bifurcation support, Intel USB 3.1 Gen1 with USB Type-C, Dual Intel GbE LAN
with 25KV protection, 2x2 11ac Wireless, Dual M.2, RGB Fusion, Smart Fan 5
- Supports 8th Gen Intel Core Processors
- Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
- Intel Optane Memory Ready
- Supports PCIe x16 slot bifurcation in 2x8 mode by riser card
- Integrated HDMI 2.0 Support
- Intel USB 3.1 Gen1 with USB Type-C
- ALC1220 120dB SNR HD Audio with Smart Headphone Amp
- Intel 802.11ac Dual Band 867Mbps wireless supports MU-MIMO and BT4.2
- Dual Intel Gigabit LAN with cFosSpeed Internet Accelerator Software
- Ultra Durable 25KV ESD and 15KV Surge LAN Protection
- Dual Ultra-Fast M.2 with PCIe Gen3 x4 &ATA interface
- RGB FUSION with Multi-Zone Digital LED Light Show design, support digital
LED &GB LED strips
- Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers
with FAN STOP
- Ultra Durable Metal Shielding over PCIe Slot
- Anti-Sulfur Resistors Design
- APP Center Including EasyTune and Cloud Station Utilities
Overview
Smart Fan 5
With Smart Fan 5 users can ensure that their gaming PC can maintain its
performance while staying cool. Smart Fan 5 allows users to interchange their
fan headers to reflect different thermal sensors at different locations on the
motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that
support both PWM and Voltage mode fans have been introduced to make the
motherboard more liquid cooling friendly.
Fan pin header
Fan/Water Pump pin header
Temperature Sensors
Different models have different number of fan pin headers and temperature
sensors. Smart Fan 5 function may vary by model.
- 6 Temperature Sensors
- 3 Fan/Water Pump Connectors
- All Fan Pin Headers Upgraded to Hybrid Fan Headers
- Interoperable Fans and Sensors
- Intuitive UI for Fan Control
Hybrid Fan Headers
Achieve fan silence. With Fan Stop map any fan to stop completely when
temperatures drop below a specified threshold. Which fan stops, based on
readings from which sensor, and at what temperatureall of it can be customized
to your liking.
Hybrid Fan Pin Headers
Assume complete control over your liquid cooling setup! Smart Fan 5 receives
up-to-the-second information on flow-rate through the Hybrid Fan Pin
Headersgiving you absolute mastery over your PC.
All
Hybrid Fan Headers can automatically detect the type of cooling device whether
it be fan or pump with different PWM or Voltage mode.
New Smart Fan 5 Software
Choose from different modes, Quiet to Full Speed, to match your system usage
scenario.
For
each fan or pump, you can use the intuitive fan curve to define trigger
thresholds and corresponding fan speeds.
Interoperable Sensors and Fans
Each fan can be customized to operate at different speeds according to any
defined temperature source input (except the CPU fan).
Fan Curve
Customize fan curves based on specific temperatures with the intuitive
graphical UI.
System Information Viewer
GIGABYTE System Information Viewer is a central location that gives you
access to your current system status. Monitor components such as the clocks and
processor, set your preferred fan speed profile, create alerts when temperatures
get too high or record your systems behavior; these are the possibilities of the
System Information Viewer.
AUDIO
ALC1220 120dB SNR HD Audio with Smart Headphone Amp
ALC1220 120dB SNR HD Audio
The ALC1220 is a high-performance multi-channel High Definition Audio Codec
with up to 120dB SNR for crystal clear audio and features such as Smart
Headphone Amp, 114dB SNR recording for precise voice chats and hardware decoding
of DSD128, ensuring users get the best possible audio quality from their PC.
Smart Headphone AMP
Automatically detects impedance of your head-worn audio device, whether
earbuds or high-end headphones to provide optimal audio dynamicspreventing
issues such as low volume and distortion.
High-End Audio Capacitors
GIGABYTE motherboards use high-end audio capacitors. These high quality
capacitors help deliver high resolution and high fidelity audio to provide the
most realistic sound effects for gamers.
Audio Noise Guard
GIGABYTE Z370 motherboards feature an audio noise guard that essentially
separates the boards sensitive analog audio components from potential noise
pollution at the PCB level. LED trace path lighting Illuminates to show the
separation of the PCB layers.
CONNECTIVITY
Dual PCIe Gen3 x4 M.2
GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts
who want to maximize their systems potential.
GIGABYTE M.2 Thermal Guard
PERFORMANCE FUELED BY OPTANE
The GIGABYTE Z370 Platform is the first enthusiast platform that supports
Intels latest Optane technology. Optane fuels storage performance by acting as a
cache drive giving users a significant boost compared to traditional mechanical
drives.
HDMI 2.0 for 4K / 60P / 21:9 / HDCP 2.2 Support
HDMI 2.0, which is backwards compatible with HDMI 1.4, offers 18 Gb/s of
bandwidth nearly twice that of the previous generation. This unlocks the
potential for users to transfer multiple video streams, as well as a native
cinematic 21:9 ratio (which most movies are shot in), offering the best
visual
Dual Intel GbE LAN with cFosSpeed Internet Accelerator
Software
Dual IntelGigabit
LAN features cFosSpeed, a network traffic management application which helps to
improve network latency and maintain low ping times to deliver better
responsiveness in crowded LAN environments.
Faster and Better Coverage with Intel Dual Band 802.11ac WiFi+BT4.2
Module
The Industry's Leading Static-Electricity &urge
Protection
Connecting the Future - USB Type-C:
The World's Next Universal Connector
The USB Type-C is a new reversible connector that is loaded with useful
features such as USB 3.1 Gen1 support and faster charging capabilities. Powered
by the Intel controller, this little port is the better USB Type-C.
Immersive VR Gaming Experience
- VR requires more performance than Full HD graphics for a steady 90FPS or
greater.
- Only Gaming PCs can provide the best VR experience.
Recommended configuration for VR Gaming PC*
- Graphics Card: NVIDIA GTX 1060 / AMD RX 480 or greater, Compatible HDMI
1.4 video output
- CPU: Intel i5 equivalent or greater
- Motherboard: GIGABYTE Z370 motherboards
- Memory: 8GB RAM or greater
- USB Ports: 3x USB 3.0 ports plus 1x USB 2.0 port or greater
- OS: Windows 10 64-bit or newer
*Please check VR vendor website for full system requirements.
To create a seamless VR experience GIGABYTE Motherboards offer the best
features to make your virtual reality feel like your actual reality. With
technologies such as NVMe support via M.2 or U.2 and a one piece metal shielding
to brace for heavier discrete graphics cards it's obvious that GIGABYTE has the
tools you need to start your journey in VR. To set the mood GIGABYTE
Motherboards include RGB Fusion to put you in the center of action.
PERFORMANCE
Support for DDR4 XMP Up to 4400MHz and Beyond*
GIGABYTE is offering a tested and proven platform that ensures proper
compatibility with profiles up to 4400MHz and beyond. All users need to do to
attain this performance boost is to ensure that their memory module is XMP
capable and that the XMP function is activated and enabled on GIGABYTE
motherboard.
What is XMP?
DDR4 memory modules are available at a stock frequency of 2133MHz, but as
frequency tweaking requires a considerable amount of effort and knowledge,
memory vendors encode XMP profiles which can automatically modify the timings of
the supported memory modules to work with your CPU and to achieve increased
performance.
LIGHTING
RGB Fusion with Digital LEDs
With Z370 Motherboards, RGB Fusion is even better with Digital LEDs.* RGB
Fusion offers users the option to control onboard and external LED light strips
for their PC. Already feature filled with colors and patterns, RGB Fusion on
Z370 Series Motherboards are now upgraded with Digital LED support. With onboard
options and external digital LED strips*, where each LED is digitally
addressable, users can experience even more patterns, styles, and
illuminations.
Z370 Motherboards will support either 5v or 12v digital LED strips. RGB
Fusion with Digital LEDs comes with 9 new patterns and various speed settings
with more to come.
*Digital LEDs are available only on select Motherboards, external LED
Strips, Digital LED Strips are not included with Motherboard purchase.
Supports RGBW &V Light Strips
Independently Programmable Onboard Pin Header for RGBW/UV LED
Strips
Not bright enough? You can install standard 12V external RGB, RGBW or RGB/UV
light strips on the RGBW pin header and control its color from the RGB Fusion
software. Using a RGBW light strip with a dedicated white LED, users will
experience brighter and more vibrant shades of colors.
When using RGB/UV LED strips, users can give their systems a fluorescent glow
with the use of UV reactive liquid, neon braided cables, and acrylic paint for a
wicked-looking gaming PC.
No need to worry when choosing light strips as GIGABYTE motherboards support
a wide variety of RGBW/UV light strips on the market thanks to the RGB Fusion
software that allows users to redefine the pin location for the R/G/B
Signal.
RGB Fusion (Advanced mode)
With the all new RGB Fusion software, users have access to different preset
LED lighting configurations with choice of colors. You can even set the LEDs to
synchronize with your favorite music or have them change colors to indicate the
CPU temperature. For true lighting experts there is an Advanced Mode, which can
be fully customized by individual area with its own effects and color
transitions, along with specific duration and transition times.
GIGABYTE RGB Fusion APP
Don't just make your PC shine, make it a work of art that friends will envy.
With the GIGABYTE RGB Fusion mobile app users can watch as they control the
lighting within their gaming PC. This gives users ease of access as they try and
adjust colors and speeds for different modes, all this can be achieved away from
the keyboard and monitor of their PC.
ULTRA DURABLE
GIGABYTE Patented Double Locking Bracket
Long Lifespan Durable Black Solid Caps
GIGABYTE motherboards integrate the absolute best quality solid state
capacitors that are rated to perform at maximum efficiency for extended periods,
even in extreme performance configurations. With ultra-low ESR no matter how
high the CPU load, this provides peace of mind for end users who want to push
their system hard, yet demand absolute reliability and stability. These
exclusive capacitors also come in customized jet black, exclusively on GIGABYTE
motherboards.
GIGABYTE Patented DualBIOS Design
GIGABYTE Ultra Durable motherboards feature GIGABYTE DualBIOS, an exclusive
technology from GIGABYTE that protects arguably one of your PC's most crucial
components, the BIOS. GIGABYTE DualBIOS means that your motherboard has both a
'Main BIOS' and a 'Backup BIOS', protecting users from BIOS failure due to
virus, hardware malfunction, improper OC settings or power failure during the
update process.
START SULFURIZATION PROTECTION
Sulfur compounds in the air can penetrate tiny onboard resistors creating
chemical change and causing these resistors to open or short. If either of these
occurs the motherboard will fail to function. By equipping resistors with an
Anti-Sulfur Design GIGABYTE gives Ultra Durable Motherboards a whole new
meaning.
GIGABYTE EXCELLENCE
GIGABYTE BIOS &pplications
Refreshed BIOS
The BIOS is essential for users during initial setup to allow for the most
optimal settings. With a new GUI and easier to use functionalities, GIGABYTE has
been able to reinvent the BIOS to give users a better experience while setting
up their new system.
GIGABYTE APP Center
The GIGABYTE APP Center gives you easy access to a wealth of GIGABYTE apps
that help you get the most from your GIGABYTE motherboard. Using a simple,
unified user interface, GIGABYTE APP Center allows you to easily launch all
GIGABYTE apps installed on your system, check related updates online, and
download the latest apps, drivers, and BIOS.
EasyTune
GIGABYTE's EasyTune is a simple and easy-to-use interface that allows users
to fine-tune their system settings or adjust system and memory clocks and
voltages in a Windows environment. With Smart Quick Boost, one click is all it
takes to automatically overclock your system, giving an added performance boost
when you need it the most.
Overclocking to Boost Your Frame Rates
Get
the highest levels of performance from your PC with easy-to-use GIGABYTE
overclocking features.
3D OSD
3D OSD automatically detects and displays your system information during
games, allowing you to easily get a hold of your system information without
switching between screens.
TriDef SmartCam | Custom Stream Modding
To facilitate being the full streaming solution each GIGABYTE motherboard
includes TriDefSmartCam
software, you are now able to remove backgrounds without the hassle of using a
green screen. Through the SmartCam application you can now apply live filters,
and fully control your background, not only while streaming, but also through
other video applications such as Skype.
*Free 1 month TriDefSmartCam
License.
XSplit Gamecaster + Broadcaster: Cast Your Game Anytime,
Anywhere
Now set up your stage and share the greatest gaming moments with XSplit
Gamecaster + Broadcaster! Fully optimized social media integration is ready for
real-time chatskeeping you notified yet focused in the game. It takes just one
click to stream your gameplay to Twitch. Host your game like a pro!
*Free 14 days XSplit Gamecaster + Broadcaster Premium License.
CEC 2019 Ready
Saving energy, Environmental Friendly
The Z370 Motherboards are now ready for CEC 2019! The California Energy
Commission(CEC) regulation measures PC systems level power consumption. The Z370
Motherboards with selected key components fulfill CEC 2019 power saving
requirements.
Specifications
|
CPU |
1. Support for 8th Generation Intel Core i7
processors/Intel Core i5 processors/Intel Core i3 processors in
the LGA1151 package |
|
2. L3 cache varies with CPU |
|
(Please refer "CPU Support List" for more
information.) |
|
|
|
Chipset |
1. Intel Z370 Express Chipset |
|
|
|
Memory |
1. 2 x DDR4 DIMM sockets supporting up to 32 GB of system
memory |
|
2. Dual channel memory architecture |
|
3. Support for DDR4 4400(O.C.)/4000(O.C.) / 3866(O.C.) / 3800(O.C.) /
3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) /
3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 /
2400 / 2133 MHz memory modules |
|
4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate
in non-ECC mode) |
|
5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory
modules |
|
6. Support for Extreme Memory Profile (XMP) memory
modules |
|
(Please refer "Memory Support List" for more
information.) |
|
|
|
Onboard Graphics |
|
|
Integrated Graphics Processor+
MegaChips MCDP2800
chip |
1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60
Hz |
|
* Support for HDMI 2.0 version, HDCP 2.2, and HDR. |
|
(Requires the latest Intel graphics driver from the GIGABYTE
website.)
|
|
Integrated Graphics Processor-
Intel HD Graphics
support |
1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30
Hz |
|
* Support for HDMI 1.4 version and HDCP 2.2. |
|
2. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60
Hz |
|
* Support for DisplayPort 1.2 version, HDCP 2.2, and
HDR. |
|
Support for up to 3 displays at the same time |
|
Maximum shared memory of 1 GB |
|
|
|
Audio |
1. Realtek ALC1220 codec |
|
2. High Definition Audio |
|
3. 2/4/5.1/7.1-channel |
|
* To configure 7.1-channel audio, you have to use an HD front panel
audio module and enable the multi-channel audio feature through the audio
driver. |
|
4. Support for S/PDIF Out |
|
LAN |
1. 2 x Intel GbE LAN chips (10/100/1000 Mbit) |
|
Wireless Communication module |
1. Intel Wi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz
Dual-Band |
|
2. BLUETOOTH 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR |
|
3. Support for 11ac wireless standard and up to 867 Mbps data
rate |
|
* Actual data rate may vary depending on environment and
equipment. |
|
Expansion Slots |
1. 1 x PCI Express x16 slot, running at x16 |
|
(The PCIEX16 slot conforms to PCI Express 3.0
standard.) |
|
|
|
Storage Interface |
|
|
Chipset |
1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and
PCIe x4/x2 SSD support) (M2A_32G) |
|
2. 1 x M.2 connector on the back of the motherboard (Socket 3, M key,
type 2260/2280 PCIe x4/x2 SSD support) (M.2) |
|
3. 4 x SATA 6Gb/s connectors |
|
4. Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
|
Intel Optane Memory Ready |
|
|
|
USB |
|
|
Chipset |
1. 2 x USB 2.0/1.1 ports available through the internal USB
header |
|
2. 8 x USB 3.1 Gen 1 ports (6 ports on the back panel, 2 ports
available through the internal USB header) |
|
3. 1 x USB Type-C port on the back panel, with USB 3.1 Gen 1
support |
|
|
|
Internal I/O Connectors |
1. 1 x 24-pin ATX main power connector |
|
2. 1 x 8-pin ATX 12V power connector |
|
3. 1 x CPU fan header |
|
4. 2 x system fan headers |
|
5. 1 x digital LED strip header |
|
6. 1 x digital LED strip power select jumper |
|
7. 1 x RGB (RGBW) LED strip header |
|
8. 4 x SATA 6Gb/s connectors |
|
9. 2 x M.2 Socket 3 connectors(one on the back of the
motherboard) |
|
10. 1 x front panel header |
|
11. 1 x front panel audio header |
|
12. 1 x USB 3.1 Gen 1 header |
|
13. 1 x USB 2.0/1.1 header |
|
14. 1 x S/PDIF Out header |
|
15. 1 x speaker header |
|
16. 1 x Clear CMOS jumper |
|
17. 1 x chassis intrusion header |
|
Back Panel Connectors |
1. 2 x HDMI ports |
|
2. 1 x DisplayPort |
|
3. 2 x SMA antenna connectors (2T2R) |
|
4. 6 x USB 3.1 Gen 1 ports |
|
5. 1 x USB Type-C port, with USB 3.1 Gen 1 support |
|
6. 2 x RJ-45 ports |
|
7. 3 x audio jacks (Line In, Line Out, Mic In) |
|
I/O Controller |
1. iTE I/O Controller Chip |
|
H/W Monitoring |
1. Voltage detection |
|
2. Temperature detection |
|
3. Fan speed detection |
|
4. Overheating warning |
|
5. Fan fail warning |
|
6. Fan speed control |
|
* Whether the fan speed control function is supported will depend on
the cooler you install. |
|
BIOS |
1. 2 x 128 Mbit flash |
|
2. Use of licensed AMI UEFI BIOS |
|
3. Support for DualBIOS |
|
4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI
5.0 |
|
Unique Features |
1. Support for APP Center |
|
* Available applications in APP Center may vary by motherboard model.
Supported functions of each application may also vary depending on
motherboard specifications. |
|
3D OSD |
|
@BIOS |
|
AutoGreen |
|
BIOS Setup |
|
Color Temperature |
|
Cloud Station |
|
EasyTune |
|
Easy RAID |
|
Fast Boot |
|
Game Boost |
|
ON/OFF Charge |
|
Platform Power Management |
|
RGB Fusion |
|
Smart Backup |
|
Smart Keyboard |
|
Smart TimeLock |
|
Smart HUD |
|
System Information Viewer |
|
USB Blocker |
|
V-Tuner |
|
2. Support for Q-Flash |
|
3. Support for Xpress Install |
|
Bundle Software |
1. Norton Internet Security (OEM version) |
|
2. cFosSpeed |
|
Operating System |
1. Support for Windows 10 64-bit |
|
Form Factor |
1. Mini-ITX Form Factor; 17.0cm x 17.0cm |
|
Remark |
1. Due to different Linux support condition provided by chipset
vendors, please download Linux driver from chipset vendors' website or 3rd
party website. |
|
2. Most hardware/software vendors may no longer offer drivers to
support Win9X/ME/2000/XP. If drivers are available from the vendors, we
will update them on the GIGABYTE
website. | |
