Hardware Specifications |
|
|
CPU |
|
|
CPU Model |
Realtek RTD1296 |
|
CPU Architecture |
64-bit |
|
CPU Frequency |
Quad Core 1.4 GHz |
|
Hardware Encryption Engine |
|
|
Hardware Transcoding Engine |
10-bit H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1;
maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS):
60 |
|
|
|
|
Memory |
|
|
System Memory |
2 GB DDR4 |
|
|
|
|
Storage |
|
|
Drive Bays |
2 |
|
Compatible Drive Type* (See all supported
drives) |
3.5" SATA HDD |
|
|
2.5" SATA HDD |
|
|
2.5" SATA SSD |
|
Maximum Internal Raw Capacity |
24 TB (12 TB drive x 2) (Capacity may vary by RAID
types) |
|
Maximum Single Volume Size |
108 TB |
|
Hot Swappable Drive |
|
|
Notes |
"Compatible drive type" indicates the drives that have been tested to
be compatible with Synology products. This term does not indicate the
maximum connection speed of each drive bay. |
|
|
The maximum single volume size is not directly related to the
maximum raw capacity. (Learn more) |
|
|
|
|
External Ports |
|
|
RJ-45 1GbE LAN Port |
1 |
|
USB 2.0 Port |
1 |
|
USB 3.0 Port |
2 |
|
Copy Button |
|
|
|
|
|
File System |
|
|
Internal Drives |
EXT4 |
|
External Drives |
EXT4 |
|
|
EXT3 |
|
|
FAT |
|
|
NTFS |
|
|
HFS+ |
|
|
exFAT* |
|
Notes |
exFAT Access is purchased separately in Package
Center. |
|
|
|
|
Appearance |
|
|
Size (Height x Width x Depth) |
165 mm x 108 mm x 233.2 mm |
|
Weight |
1.3 kg |
|
|
|
|
Others |
|
|
System Fan |
92 mm x 92 mm x 1 pcs |
|
Fan Speed Mode |
Full-Speed Mode |
|
|
Cool Mode |
|
|
Quiet Mode |
|
Brightness adjustable front LED indicators |
|
|
Power Recovery |
|
|
Noise Level* |
19.3 dB(A) |
|
Scheduled Power On/Off |
|
|
Wake on LAN/WAN |
|
|
Power Supply Unit / Adapter |
60W |
|
AC Input Power Voltage |
100V to 240V AC |
|
Power Frequency |
50/60 Hz, Single Phase |
|
Power Consumption* |
14.99 W (Access) |
|
|
5.78 W (HDD Hibernation) |
|
British Thermal Unit |
51.15 BTU/hr (Access) |
|
|
19.72 BTU/hr (HDD Hibernation) |
|
|
|
|
Environment Temperature |
|
|
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
|
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
|
Relative Humidity |
5% to 95% RH |
|
|
|
|
Certification |
FCC Class B |
|
|
CE Class B |
|
|
BSMI Class B |
|
|
EAC |
|
|
CCC |
|
|
RCM |
|
|
KC |
|
|
|
|
Warranty |
2 Years |
|
Notes |
Power consumption is measured when fully loaded with Western Digital
1TB WD10EFRX hard drive(s). |
|
|
|
|
DSM Specifications ( See more ) |
|
|
Storage Management |
|
|
Maximum Internal Volume Number |
256 |
|
Maximum iSCSI Target Number |
10 |
|
Maximum iSCSI LUN |
10 |
|
SSD TRIM |
|
|
Supported RAID Type |
Synology Hybrid RAID |
|
|
Basic |
|
|
JBOD |
|
|
RAID 0 |
|
|
RAID 1 |
|
RAID Migration |
Basic to RAID 1 |
|
Volume Expansion with Larger HDDs |
Synology Hybrid RAID |
|
|
RAID 1 |
|
Volume Expansion by Adding a HDD |
Synology Hybrid RAID |
|
|
|
|
File Sharing Capacity |
|
|
Maximum Local User Accounts |
2048 |
|
Maximum Local Groups |
256 |
|
Maximum Shared Folder |
256 |
|
Maximum Shared Folder Sync Tasks |
2 |
|
Maximum Concurrent CIFS/AFP/FTP Connections |
200 |
|
Windows Access Control List (ACL) Integration |
|
|
NFS Kerberos Authentication |
|
|
|
|
|
Log Center |
|
|
Syslog Events per Second |
100 |
|
|
|
|
Add-on Packages (learn more about the complete add-on package
list) |
|
|
Chat |
|
|
Maximum Users |
500 |
|
Notes |
The number of concurrent HTTP connections for Chat was configured to
the maximum. |
|
|
CPU and RAM usage were both under 80% when the number of maximum users
was reached. |
|
|
|
|
Cloud Station Server |
|
|
Maximum Number of Concurrently Connected Devices |
200 |
|
Maximum Number of Synced Files (ext4) |
100,000 / single file reaction time 632 ms |
|
Notes |
The maximum number of concurrently connected devices refers to the
maximum number of devices that can remain connected at the same time. For
more information on file processing capability, please refer to the
reaction time for file processing. |
|
|
File reaction time refers to the preparation time required for other
devices to start downloading a 10KByte file from a Synology NAS after the
file has been added to the NAS. RAM expansion was not used during
testing. |
|
|
Non-encrypted shared folders were used during the aforementioned
testing. |
|
|
|
|
Download Station |
|
|
Maximum Concurrent Download Tasks |
30 |
|
|
|
|
Drive |
|
|
Maximum Number of Synced Files |
100,000 / single file reaction time 941 ms |
|
Maximum Number of Concurrent Connections for PC
Clients |
200 |
|
Notes |
The EXT4 file system was used for the purpose of
testing. |
|
|
The maximum number of concurrent connections refers to the maximum
number of connections that could be maintained when the maximum number of
synced files was reached. |
|
|
File reaction time refers to the preparation time required for other
devices to start downloading a 10KByte file from a Synology NAS after the
file has been added to the NAS. |
|
|
Non-encrypted shared folders were used during the aforementioned
testing. |
|
|
|
|
exFAT Access (optional) |
Yes |
|
|
|
|
Media Server |
Yes |
|
DLNA Compliance |
Yes |
|
|
|
|
Moments |
Yes |
|
Facial recognition |
Yes |
|
Subject recognition |
Yes |
|
|
|
|
Office |
Yes |
|
Maximum Users |
200 |
|
Notes |
Multiple files were opened for testing and each file was edited by 30
users simultaneously. |
|
|
CPU and RAM usage were both under 80% when the number of maximum users
was reached. |
|
|
Client performance may affect maximum simultaneous editing users.
Client PCs used for testing: Intel Core i3-3220 / 8GB
RAM |
|
|
|
|
Surveillance Station |
|
|
Maximum IP cam (Licenses required) |
20 (including 2 Free License) (See All Supported IP
Cameras) |
|
Total FPS (H.264)* |
600 FPS @ 720p (1280x720) |
|
|
300 FPS @ 1080p (1920×1080) |
|
|
200 FPS @ 3M (2048x1536) |
|
|
150 FPS @ 5M (2591x1944) |
|
|
110 FPS @ 4K (3840x2160) |
|
Total FPS (H.265)* |
600 FPS @ 720p (1280x720) |
|
|
300 FPS @ 1080p (1920×1080) |
|
|
240 FPS @ 3M (2048x1536) |
|
|
200 FPS @ 5M (2591x1944) |
|
|
180 FPS @ 4K (3840x2160) |
|
Total FPS (MJPEG)* |
240 FPS @ 720p (1280x720) |
|
|
200 FPS @ 1080p (1920×1080) |
|
|
130 FPS @ 3M (2048x1536) |
|
|
80 FPS @ 5M (2591x1944) |
|
Notes |
Surveillance Station throughput is tested with Axis network camera,
using continuous recording with live view from Surveillance Station and
motion detection by camera. Live view and recording are sharing the same
stream from the camera. |
|
|
|
|
Video Station |
|
|
Video Transcoding |
4K Group 3 (See morez) |
|
Maximum Transcoding Channel Number |
1 channel, 60 FPS @ 4K (4096 x 2160), H.265 (HEVC), 10-bit or
|
|
|
1 channel, 30 FPS @ 1080p (1920 × 1080), H.264 (AVC)/MPEG-4 Part 2
(XVID, DIVX5)/MPEG-2/VC-1 |
|
|
|
|
VPN Server |
|
|
Maximum Connections |
5 |
|
|
|
|
Environment & Packaging |
|
|
Environment |
RoHS Compliant |
|
Packaging Content |
Main Unit X 1 |
|
|
Accessory Pack X 1 |
|
|
AC Power Adapter X 1 |
|
|
AC Power Cord X 1 |
|
|
RJ-45 LAN Cable X 1 |
|
|
Quick Installation Guide X 1 |
|
Optional Accessories |
Surveillance Device License Pack |
|
|
VS360HD |
|
|
VS960HD |
