Operating
System |
QTS
4.3.4 (embedded Linux) |
Supported
Client Operating Systems |
Apple
Mac OS 10.7 or later |
|
Linux
and UNIX |
|
Microsoft
Windows 7, 8, and 10 |
|
Microsoft
Windows Server 2003, 2008 R2, 2012, 2012 R2 and 2016 |
Supported
Browsers |
Apple
Safari 7 or later |
|
Google
Chrome |
|
Microsoft
Internet Explorer 10 or later |
|
Mozilla
Firefox |
Supported
Languages |
Chinese
(traditional and simplified), Czech, Danish, Dutch, English, Finnish,
French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian,
Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai,
and Turkish |
Supported
File Systems |
Internal
hard drive (EXT4) |
|
External
hard drive (EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT) |
|
Note:
To use exFAT you must purchase an exFAT driver license from License
Center. |
Network
& Virtual Switch |
TCP/IP:
Dual stack (IPv4 and IPv6) |
|
Jumbo
frame (failover, multi-IP settings, port trunking/NIC
teaming) |
|
DHCP
server and client |
|
USB
Wi-Fi adapter |
|
Note:
This feature does not support ad hoc networks because of security
considerations. |
|
Virtual
switch |
|
-Virtual
switch editing in Virtualization Station |
|
-Combining
virtual machines and containers in the same virtual
switch |
|
-Network
Address Translation (NAT) |
|
-Spanning
Tree Protocol (STP) |
|
-Thunderbolt
to Ethernet converter (T2E) |
|
Note:
This feature is only supported on models with built-in thunderbolt
ports. |
|
WirelessAP
Station |
Security |
Network
access protection with auto-blocking (SSH, Telnet, HTTP(S), FTP, CIFS/SMB,
and AFP) |
|
Host
access control for shared folders (CIFS/SMB) |
|
140-2
validated AES 256-bit volume-based and shared folder data encryption
(FIPS) |
|
256-bit
external drive encryption (AES) |
|
Importing
of SSL certificates from Let’s Encrypt |
|
Instant
alerts through email, SMS, push service, and audio |
|
2-step
verification |
Storage
Management |
Storage
space utilization monitoring |
|
Flexible
volumes and LUNs with thin provisioning and space
reclaiming |
|
Supported
RAID types: RAID 0, 1, 5, 6, 10, JBOD, Single |
|
RAID
hot spare and global hot spare |
|
RAID
rebuild speed customization |
|
Advanced
secure data erase |
|
Storage
pools |
|
Qtierâ„¢
Technology (automated storage tiering) |
|
-Automatic
or scheduled data tiering |
|
-IO-aware
auto tiering |
|
-Shared
folder tiering on demand |
|
Snapshots |
|
-Volume
and LUN snapshots |
|
-Snapshot
Dashboard |
|
-Snapshot
Manager |
|
-Snapshot
cloning |
|
-Snapshot
Vault |
|
-Snapshot
Replica |
|
-Unified
Snapshot Directory |
|
-Support
for Windows Previous Versions (CIFS/SMB) |
|
-Snapshot
Agent for Microsoft Windows and VMware vSphere |
|
Online
volume expansion |
|
Online
storage pool expansion |
|
Online
RAID capacity expansion |
|
Online
RAID level migration |
|
SMART
data migration |
|
Storage
expansion using QNAP expansion units |
|
JBOD
enclosure roaming |
|
SSD
read-only or read-write cache |
|
Note:
The maximum cache size depends on installed memory. |
|
Bad
block scan and hard drive S.M.A.R.T test. |
|
Bad
block recovery and RAID recovery |
|
Bitmap
support |
iSCSI
(IP SAN) |
iSCSI
targets with multiple LUNs per target |
|
Note:
The maximum number of targets is 256. |
|
LUN
mapping and masking |
|
Online
LUN capacity expansion |
|
SPC-3
persistent reservation |
|
MPIO
& MC/S |
|
iSCSI
Extensions for RDMA (iSER) with VMware ESXi |
|
Note:
This feature requires an Intel or AMD-based NAS with a PCIe slot, and a
compatible Mellanox network card. |
|
iSCSI
LUN backup, one-time snapshot, and restoration |
|
Virtual
disks using iSCSI initiator |
|
Note:
The maximum number of virtual disks is eight. |
|
Stack
chaining master |
Power
Management |
Wake-on-LAN
(WoL) |
|
Standby
mode for internal drives |
|
Scheduled
power on and off |
|
Automatic
power on after power recovery |
|
USB
and network UPS support with SNMP management |
Access
Rights Management |
Multiple
user creation |
|
User
data importing and exporting |
|
User
quota management |
|
Local
user access control (AFP, CIFS/SMB, FTP, and WebDAV) |
|
Application
access control (File Station, Music Station, Photo Station, and Video
Station) |
|
Subfolder
permissions (AFP, CIFS/SMB, FTP, and File Station) |
Domain
Authentication |
Microsoft
Active Directory (AD) and domain controller support |
|
LDAP
server and client |
|
Domain
user login (AFP, CIFS/SMB, FTP, and File Station) |
myQNAPcloud |
Free
host name registration (DDNS) |
|
Optional
myQNAPcloud SSL certificates (DDNS) |
|
Auto
router configuration using UPnP |
|
Web-based
file manager with HTTPS 2048-bit encryption |
|
CloudLink
for remote access without complex router setup |
Qsync |
File
syncing across multiple devices with SSL secure
connection |
|
Selective
synchronization for specific folders or subfolders |
|
Team
folders as file center for better collaboration |
|
Note:
The maximum number of sync tasks is 32. |
|
File
sharing using email links |
|
Policy
settings for conflicting files and file type filter |
|
Version
control for a maximum of 64 versions |
|
Unified
privilege and configuration management |
|
Central
configuration mode |
|
Remote
erase and restore |
|
Windows
and Mac OS support |
Resource
Monitor |
Monitoring
of NAS system resources such as CPU, memory and
network |
|
Monitoring
of NAS storage resources such as volumes, RAID, and disk
activity |
|
Monitoring
of NAS application resource use |
|
Creation
of extra swap space when SSDs are installed |
Helpdesk |
Reporting
of issues to the QNAP support team, with automatic collection of system
information |
|
Remote
connection between QNAP support engineers and NAS for issue resolution
(with user permission) |
Web
Administration |
Multi-window,
multitasking system management |
|
Smart
toolbar and dashboard for system status display |
|
Dynamic
DNS (DDNS) |
|
SNMP
versions 2 and 3 |
|
Resource
monitor |
|
Network
recycle bin |
|
-Recover
files deleted using AFP, CIFS/SMB, and File Station |
|
-Automatic
cleanup |
|
-File
type filter |
|
Comprehensive
logs (events and connections) |
|
Syslog
server and client |
|
Backup
and restoration of system settings |
|
Qmanager:
Mobile application for remote system monitoring and
management |
|
Qboost |
File
Server |
File
sharing across Windows, Mac, and Linux/UNIX |
|
Microsoft
networking |
|
Windows
ACL |
|
Advanced
folder permissions (AFP, CIFS/SMB, and FTP) |
|
Shared
folder aggregation (CIFS/SMB) |
FTP
Server |
FTP
over SSL/TLS (explicit) |
|
FXP
support |
File
Station |
Cloud
drive mounting for Google Drive, Dropbox, Microsoft OneDrive, Microsoft
OneDrive for Business, HiDrive, Amazon Cloud Drive, Yandex Disk and
Box |
|
Remote
shared folder mounting (CIFS/SMB, FTP, and WebDAV) |
|
Document
viewing using Office Online, Google Docs, and Chrome
extension |
|
Microsoft
Office file editing using Google Docs, Sheets, and
Slides |
|
ISO
file mounting (maximum: 256 ISO files) |
|
Mount
smart phones as external storage |
|
Read
access for compatible optical disc drives |
|
Read
access for compatible smartphones (MTP) |
|
Download
and upload link sharing |
|
File
dragging and dropping (Chrome and Firefox) |
|
Photos,
video, and music preview and playback with hardware-accelerated
transcoding |
|
File
compression (ZIP and 7z) |
|
Download
link creation and sending for publicly shared files, with expiration date
and password protection |
|
Subtitle
display (SRT and UTF-8) |
|
Video
seeking during on-the-fly transcoding video playback |
|
Slideshow
playback in media viewer |
|
Qfile:
Mobile app for file browsing and management |
Qfiling |
Auto
filing |
|
Recipe
function |
|
Archiving
through iSCSI, USB, DVD and remote NAS |
|
Advanced
settings |
|
-File
deletion |
|
-Intelligent
subtitle filing for videos |
|
-Data
integrity check |
|
-File
conflict policy |
|
Note:
This feature is supported by all QNAP NAS devices with at least 2 GB of
memory (excluding the TAS series) |
Transcode
Management |
Video
transcoding (240p, 360p, 480p, 720p and 1080p
resolution) |
|
Automatic
video transcoding for watched folders |
|
Hardware-accelerated
transcoding |
|
Embed
subtitles into videos for background transcoding |
Hybrid
Backup Sync |
Cloud
storage backup to Amazon S3, Amazon Glacier, Microsoft Azure, Google Cloud
Storage, Openstack Swift, WebDAV, and HKBN |
|
Cloud
storage syncing with Microsoft OneDrive, Google Drive, Dropbox, Amazon
Drive, Yandex Disk, Box, hubiC, BackBlaze B2, Amazon S3, and
HiDrive |
|
RTRR
server & client with bandwidth control |
|
Rsync
server with download bandwidth control |
|
Remote
server syncing (CIFS/SMB, FTP, Rsync, and RTRR) |
|
Scheduled
backup to local and remote storage spaces |
|
Backup
versioning (RTRR) |
|
Encryption,
compression, and file filters |
|
Centralized
management for backup, restoration, and sync jobs |
|
Support
for Apple Time Machine |
|
Data
backup to multiple external storage devices |
|
Desktop
backup with QNAP NetBak Replicator for Windows |
|
Support
for the following third-party backup software: Veeam Backup &
Replication, Acronis True Image, Arcserve Backup, Retrospect, Nakivo
Backup & Replication, and Veritas Backup Exec |
Station |
organization by thumbnail, list, timeline, or folder |
|
Virtual
and smart albums |
|
Validity
control for album sharing |
|
tagging with text, colors, and ratings |
|
Slideshows
with background music and transition effects |
|
geotagging and display on Google Maps |
|
and video uploading to Picasa, Flickr, and Weibo |
|
Album
configuration backup and restoration |
|
Advanced
folder permissions |
|
Support
for domain users |
|
Station Extension: Supports face detection and PDF to
image |
|
Note:
This feature is only available on x86-based NAS
models. |
|
Qphoto:
Mobile application for online browsing and sharing |
Music
Station |
Music
playing and sharing through web browsers |
|
Music
streaming to multiple devices |
|
Changing
of album covers through Google search or by uploading
photos |
|
Internet
radio (MP3) |
|
Eight
music alarms |
|
Switching
between spotlight mode and manage mode |
|
Advanced
search |
|
Scrolling
lyrics |
|
Qmusic:
Mobile application for music streaming and management |
iTunes
Server |
Audio
and video sharing for Windows & Mac iTunes |
Video
Station |
Video
organization by thumbnail, list, timeline, or folder |
|
Virtual
and smart collections |
|
Video
tagging with text, colors, and ratings |
|
Video
link sharing through social media and email |
|
Movie
information and poster display from Internet sources or user-uploaded
files |
|
Subtitle
display (SRT, ASS, SSA) |
|
Subtitle
search and downloading |
|
Subtitle
file importing |
|
Subtitle
display style adjustment |
|
Playback
speed adjustment |
|
Direct
video streaming for certain file formats |
|
Facebook
login |
|
Advanced
folder permissions |
|
Support
for LDAP users |
|
Video
uploading to YouTube and Youku |
|
Multi-zone
video display |
|
Video-seeking
support for video playback during on-the-fly
transcoding |
|
Qvideo:
Mobile application for online video browsing and
management |
Virtualization
Station |
Virtual
machine creation (Windows, Linux, Unix, and Android) |
|
Virtual
machine importing, exporting, cloning, snapshot capturing, backup, and
restoration |
|
Console
display using HDMI output (QVM) |
|
HTML5-based
shared remote console |
|
Various
networking modes using virtual switches |
Container
Station |
Support
for LXC and Docker |
|
Note:
Docker containers support Bridge, NAT, and Host mode. Linux containers
(LXC) support only NAT. |
|
Application
downloading from the built-in Docker Hub Registry |
|
One-click
installation |
|
Container
importing and exporting |
|
Console
mode |
|
Three
networking modes (Bridge, NAT, and Host) |
|
Auto-start
containers |
|
Docker
certificate downloading |
|
Private
registry addition |
|
Application
repository for switching to any repository on
GitHub.com |
Qsirch |
Full-text
search |
|
Data
distribution using a bar chart |
|
Previews
for photos, music, videos, PDFs, Gmail, and others |
|
Advanced
search operators and search scope |
|
Customized
search filters with included or excluded conditions |
|
Related
files suggestion in Viewer |
|
Search
Chrome extension |
Surveillance
Station |
Support
for over 3,000 IP cameras |
|
Four
free camera licenses |
|
Note:
The application supports a maximum of 40 camera channels. You can purchase
additional licenses on the QNAP website. |
|
Instant
playback for checking of recent events |
|
Visual
aid using e-map |
|
Playback
and speed control using the shuttle bar |
|
Video
preview on playback timeline |
|
Intelligent
video analytics (IVA) for advanced video searching |
|
Surveillance
client for Mac |
|
Vmobile:
Mobile surveillance application for iOS and Android |
|
Vcam:
Mobile recording application for iOS and Android |
QVPN
Service |
VPN
server |
|
-Secure
remote access with PPTP, L2TP/IPSec, and OpenVPN
services |
|
-Support
for a maximum of 100 clients |
|
-Support
for domain users |
|
VPN
client |
|
-Support
for PPTP, L2TP/IPSec, and OpenVPN VPN protocols |
|
C20OVPN
file importing for creation of OpenVPN connections |
|
Easy
VPN connection (Windows VPN utility) |
|
Note:
QVPN combines an integrated VPN Server, a VPN client, and L2TP/IPSec VPN
services. |
DLNA
Server |
Support
for DLNA/UPnP TVs and players such as PlayStation 4 and Xbox
One |
|
Support
for CUE indexing file for APE and FLAC |
Q’center
(NAS CMS) |
Monitoring
of multiple NAS devices |
|
Utilization
history reports |
|
Unified
configuration management |
|
Monitoring
of NAS devices behind NAT routers with Connect to
Q’center |
|
Note:
The application is available in the App Center and in virtual appliance
marketplaces (VMware vSphere ESXi and Microsoft
Hyper-V). |
OceanKTV |
YouTube
video streaming |
|
Sorting
by artist, language, and favorites |
|
Effects
such as tuning echo, key, and applause |
|
Playlist
control with a mobile application |
|
Support
for keyboard and remote control (RM-IR002 and
RM-IR004) |
|
Note:
Microphones are not included. |
Qfinder
Pro |
QNAP
NAS location on the same local network |
|
NAS
shared folder mounting |
|
Basic
setting configuration (firmware, SMTP server, and network
settings) |
|
Direct
connection with USB QuickAccess and Thunderbolt (specific models
only) |
|
Storage
Plug & Connect (Windows only) |
|
-Creation
and mapping of NAS shared folders |
|
-Creation
of and connection to iSCSI targets and LUNs |
|
Media
upload (Windows only) |
|
-Media
file upload to the NAS |
|
-Automatic
creation of thumbnails or transcoding of videos using the
computer |
App
Center |
Official
and community software add-ons |
|
Automatic
updates and notifications for new versions |
|
Repository
for imported third-party content |
|
User-specified
volume for storing applications |
AirPlay
& Chromecast |
Video,
photo and music streaming to Apple TV or Chromecast using the
following: |
|
-NAS
applications: File Station, Music Station, Photo Station, and Video
Station |
|
-Mobile
applications: Qfile, Qmusic, Qphoto, and Qvideo |
|
Note:
You must install the Media Streaming add-on from App
Center. |
Download
Station |
PC-less
downloads (BitTorrent, FlashGet, FTP/FTPS, HTTP/HTTPS, QQDL, and
Thunder) |
|
Note: |
|
-The
application supports a maximum of 500 tasks. |
|
-The
maximum number of concurrent downloads is 90 (30 BT/PT, 30 HTTP, 30
FTP) |
|
BitTorrent:
Support for search, magnet links, private trackers, and
proxy |
|
Scheduled
download and bandwidth control |
|
RSS
subscription and download (broadcatching) |
|
Support
for add-ons that extend download functionality |
|
Qget:
Mobile application for download browsing and
management |
Notes
Station 3 |
Multi-user
text editing using the collaborative editor |
|
Table
creation using the spreadsheet editor |
|
Online
quick preview of multimedia attachments |
|
Smart
snapshot for version control |
HD
(HybridDesk) Station 3 |
Photo,
video, and music playback on TV through HDMI |
|
Support
for Chrome and Firefox |
|
Support
for international keyboards and mouse input |
|
User
login permissions |
|
Note:
The decoding capability of the CPU and graphics card may affect playback
of some video files. |
Linux
Station |
Usage
of the NAS as a Linux-based computer |
|
Support
for Ubuntu 14.04, Ubuntu 16.04 and Ubuntu Kylin 16.04 |
|
Application
downloading and usage from the Ubuntu Software Center |
|
Remote
desktop for remote monitoring and accessing of Ubuntu |
|
Note:
The application requires at least 4 GB of memory and installation of
Container Station. |
Qcontactz |
One-way
scheduled sync of contacts from multiple Google
accounts |
|
Contact
importing from CSV or vCard 3.0 files |
|
Contact
exporting to CSV or vCard 3.0 files |
|
Duplicate
contact searching and merging |
|
Snapshot
management for contacts database |
|
Contact
management: Groups, favorites, lock, search, delete and
restore |
|
Support
for Android and iOS |
IFTTT
Agent |
Daily
task automation |
|
Social
media data archiving |
|
File
synchronization between the NAS and various cloud
services |
|
System
event notifications on Line, Skype, Gmail, and mobile
phones |
|
Music
playback on Music Station using Amazon Echo voice
commands |
|
Usage
of motion detection sensors as trigger for camera recording on
Surveillance Station |
General
Notes |
Designs
and specifications are subject to change without
notice. |
|
Some
features may vary by model. |
|
QTS
does not support DRM content and some IPv6 services. |
|
Some
data encryption features may be unavailable because of country-specific
legislative restrictions. |
