Capacity |
10TB |
|
Internal
Storage Media |
5
x hot-swappable* 7200 RPM/64MB cache (or greater) hard
disks |
|
|
5
x hot-swappable* 7200 RPM/256MB cache hard disks with 2 million hours MTBF
and 24x7 power-on operation |
|
Interface |
2
x Thunderboltâ„¢ 2 |
|
Interface
Transfer Rate |
20
Gb/s |
|
Performance
Benchmark |
Reads
| Writes (MB/s)** |
|
|
10TB
RAID 0: 660 | 650 |
|
|
10TB
RAID 5: 520 | 530 |
|
|
20TB
RAID 0: 920 | 880 |
|
|
20TB
RAID 5: 700 | 720 |
|
|
30TB
RAID 0: 1050 | 900 |
|
|
30TB
RAID 5: 840 | 840 |
|
|
40TB
RAID 0: 1050 | 950 |
|
|
40TB
RAID 5: 850 | 850 |
|
Thunderbolt
2 Technology |
Bidirectional
20 Gb/s permits a high-resolution display and RAW 4K video
editing |
|
Power-Saving
Mode |
Reduce
power consumption by pressing the front button to spin down disks without
disrupting daisy chain transfers (short press initiates power-saving mode;
long press turns product off completely) |
|
RAID
Modes |
Preconfigured
HFS+ RAID 5 |
|
|
Hardware
RAID 0 / 1 / 5 / 6 / 10 / JBOD |
|
|
Configure
RAID using LaCie RAID Manager software |
|
Daisy
Chain |
Connect
up to six Thunderbolt-compatible devices - including Thunderbolt 2 and
LaCie Thunderbolt Series products - to a computer via a single Thunderbolt
cable*** |
|
Security |
AES
256-bit software encryption² |
|
|
Kensington
lock compatible |
|
|
Cable
lock |
|
Cooling |
Aluminum
enclosure with improved internal heat dissipation Thermoregulated Noctua
cooling fan: effective and whisper-quiet cooling |
|
Additional
Features |
System
monitoring and email alerts for failure or warning
events |
|
Acoustic |
Standby:
Negligible |
|
|
Idle:
25-28 dBA |
|
|
Operating:
25-29 dBA²² |
|
Power
Supply |
100-240
V; 50/60 Hz; 150 W |
|
Dimensions
(W x H x D) |
173
x 220 x 196 mm | 6.8 x 8.6 x 7.7 in. |
|
Weight |
7.6
kg | 16.8 lbs |
|
System
Requirements |
Computer
with a Thunderbolt 2 or Thunderbolt*** port |
|
|
Latest
version of Windows 7, Windows 8 (see here for drivers information) / Mac
OS X 10.9 or later |
|
|
Minimum
free disk space: 600MB recommended |
|
Software |
Intego®
Backup Manager Pro for Mac |
|
|
Genie®
Backup Manager Pro for PC |
|
|
LaCie
Private-Public²(protect data with AES 256-bit
encryption) |
|
|
LaCie
RAID Manager (administration console) |
|
Box
Content |
LaCie
5big Thunderbolt 2 |
|
|
External
power supply |
|
|
Thunderbolt
cable |
|
|
Drawer
key |
|
|
Cable
lock clip |
|
|
Quick
Install Guide |
