All stock codes associated to this product
MPX6501ACAABAU, MPX-6501-ACAAB-AU, 4719512061282, 884102033964
Coolermaster MWE Bronze 650 80 Plus Bronze Certified
Power Supply
Overview
Cooler Master's family of power options features a line of stable, high
quality, 80 Plus Bronze power supplies. The MWE Bronze series is compact and
available in outputs suitable for most systems. On top of safety regulations,
the MWE Bronze includes Cooler Master's 3 year warranty. Inside, the Silencio
fan blades run with less turbulence while sealed LDB bearings guarantee a longer
service life. High quality components keep up with daily power demands, while
delivering consistent output even in 40C surroundings cool and quietly.
DC-DC Circuit Design
The DC-DC circuit design offers your system more reliable and stable output
voltages, providing more consistent power delivery at up to 40°C.
Durable LDB Bearing
Cooler Master 120mm Silencio FP fan combines sealed LDB bearings with quiet
fan blades offering a long lifetime of quiet cooling.
QUALITY AND RELIABILITY
- self-lubricating, dustproof design (ipx6)
- 160,000hr life expectancy
REDUCED NOISE AND POWER CONSUMPTION
- silent driver IC reduces clicks and vibration
REDUCED NOISE AND POWER CONSUMPTION
Quality Capacitors
Solid, high quality capacitors are used in the MWE Bronze power supply for
increased product lifespan and higher temperature resistance.
Sleeved Cables
Sleeved cables provide easier cable management, offering a clean and
professional look. They also save space for better airflow within the PC system,
improving thermal performance and heat dissipation.
Low Standby Power
The MWE Bronze will consume no more than 0.5W when your PC is in standby
mode, complying with ErP 2013 lot 6.
Specifications
Product
Number |
MPX-6501-ACAAB |
Type |
Intel ATX 12V
V2.31 |
PFC |
Active
PFC |
Operation
Voltage |
100-240
Vac |
Input
Voltage |
100-240
Vac |
Input
Current |
10-5
A |
Input
Frequency |
50-60
Hz |
Dimensions
(LxBxH) |
140 x 150 x 86
mm |
Fan
Size |
120
mm |
Fan
Bearing |
LDB |
Power Good
Signal |
100-500
ms |
Hold Up
Time |
16ms at 80%
load |
Efficiency |
85%
Typically |
ErP 2013 Lot
6 |
Yes |
MTBF |
>100,000
Hours |
Operating
Temperature |
40C |
Protections |
OVP / OPP / OTP / SCP /
OCP |
Regulatory |
TUV-RH, CE, CCC, KC,
EAC, RCM, cTUVus, FCC, BSMI |
Connectors |
|
MB 20+4
Pin |
1 |
CPU 12V 4+4
Pin |
1 |
SATA |
8 |
Peripheral 4
Pin |
4 |
FDD Cable 4
Pin |
1 |
PCI-e 6+2
Pin |
4 |
