Essentials |
|
Product
Collection |
4th Generation Intel
Core i7 Processors |
Code
Name |
Products formerly
Haswell |
Vertical
Segment |
Mobile |
Processor
Number |
i7-4710MQ |
Status |
Launched |
Launch
Date |
Q2'14 |
Lithography |
22 nm |
|
|
Performance |
|
# of
Cores |
4 |
# of
Threads |
8 |
Processor Base
Frequency |
2.50
GHz |
Max Turbo
Frequency |
3.50
GHz |
Cache |
6 MB
SmartCache |
Bus
Speed |
5 GT/s
DMI2 |
TDP |
47
W |
|
Supplemental
Information |
|
Embedded Options
Available |
No |
Conflict
Free |
Yes |
|
|
Memory
Specifications |
|
Max Memory Size
(dependent on memory type) |
32
GB |
Memory
Types |
DDR3L 1333/1600 |
Max # of Memory
Channels |
2 |
Max Memory
Bandwidth |
25.6 GB/s |
ECC Memory
Supported |
No |
|
|
Graphics
Specifications |
|
Processor
Graphics |
Intel HD Graphics
4600 |
Graphics Base
Frequency |
400
MHz |
Graphics Max Dynamic
Frequency |
1.15
GHz |
Graphics Video Max
Memory |
2
GB |
Graphics Output |
eDP/DP/HDMI/VGA |
Max Resolution (HDMI
1.4) |
3840x2160@60Hz |
Max Resolution
(DP) |
3840x2160@60Hz |
Max Resolution (eDP -
Integrated Flat Panel) |
2880x1800@60Hz |
DirectX*
Support |
11.2/12 |
OpenGL*
Support |
4.3 |
Intel Quick Sync
Video |
Yes |
Intel InTru 3D
Technology |
Yes |
Intel Clear Video HD
Technology |
Yes |
Intel Clear Video
Technology |
Yes |
# of Displays
Supported |
3 |
Device
ID |
0x416 |
|
|
Expansion
Options |
|
PCI Express
Revision |
3 |
PCI Express
Configurations |
1x16, 2x8, 1x8 2x4 |
Max # of PCI Express
Lanes |
16 |
|
|
Package
Specifications |
|
Sockets
Supported |
FCPGA946 |
Max CPU
Configuration |
1 |
T
JUNCTION |
100degree
C |
Package
Size |
37.5mm x 32mm x
1.6mm |
Low Halogen Options
Available |
See
MDDS |
|
|
Advanced
Technologies |
|
|
|
Intel Turbo Boost
Technology |
2.0 |
Intel vPro
Technology |
No |
Intel Hyper-Threading
Technology |
Yes |
Intel Virtualization
Technology (VT-x) |
Yes |
Intel Virtualization
Technology for Directed I/O (VT-d) |
No |
Intel VT-x with
Extended Page Tables (EPT) |
Yes |
Intel
TSX-NI |
No |
Intel
64 |
Yes |
Instruction
Set |
64-bit |
Instruction Set
Extensions |
SSE4.1/4.2, AVX 2.0 |
Idle
States |
Yes |
Enhanced Intel
SpeedStep Technology |
Yes |
Thermal Monitoring
Technologies |
Yes |
Intel Identity
Protection Technology |
Yes |
|
|
Security &
Reliability |
|
Intel AES New
Instructions |
Yes |
Secure
Key |
Yes |
Intel Trusted Execution
Technology |
No |
Execute Disable
Bit |
Yes |
Anti-Theft
Technology |
No |
