Hardware
Specifications |
|
CPU |
|
CPU
Model |
Intel Xeon
D-1541 |
CPU
Architecture |
64-bit |
CPU
Frequency |
8-Core 2.1 (base) / 2.7
(turbo) GHz |
Hardware Encryption
Engine (AES-NI) |
Yes |
|
|
Memory |
|
System
Memory |
16 GB DDR4 ECC
RDIMM |
Memory Module
Pre-installed |
16GB (1 x
16GB) |
Total Memory
Slots |
4 |
Memory Expandable up
to |
128GB (32 GB x
4) |
|
|
Storage |
|
Drive
Bays |
24 |
Maximum Drive Bays with
Expansion Unit |
48 (RX1217sas) / 72
(RX2417sas) |
Compatible Drive
Type* |
2.5" SATA
SSD |
|
2.5" SAS
HDD |
|
2.5" SAS
SSD |
Maximum Internal Raw
Capacity |
92.16 TB (3.84 TB drive
x 24) (Capacity may vary by RAID types) |
Maximum Raw Capacity
with Expansion Units |
276.48 TB (3.84 TB
drive x 72) (Capacity may vary by RAID types) |
Maximum Single Volume
Size |
200 TB (32GB RAM
required, for RAID 5 or RAID 6 groups only) |
|
108
TB |
Hot Swappable
Drive |
Yes |
Notes |
"Compatible drive type"
indicates the drives that have been tested to be compatible with Synology
products. This term does not indicate the maximum connection speed of each
drive bay. |
|
Expansion of the
internal volume is only supported if the combined single volume size does
not exceed the maximum limit of 108TB or 200TB if upgraded to 32GB RAM or
more. |
|
|
External
Ports |
|
RJ-45 1GbE LAN
Port |
4 (with Link
Aggregation / Failover support) |
RJ-45 10GbE LAN
Port |
2 (with Link
Aggregation / Failover support) |
USB 3.0
Port |
2 |
Expansion
Port |
1 |
|
|
PCIe |
|
PCIe
Expansion |
1 x Gen3 x8 slot (x8
link) |
Add-in-card
support |
PCIe Network Interface
Card |
|
|
File
System |
|
Internal
Drives |
Btrfs |
|
EXT4 |
External
Drives |
Btrfs |
|
EXT4 |
|
EXT3 |
|
FAT |
|
NTFS |
|
HFS+ |
|
exFAT* |
Notes |
exFAT Access is
purchased separately in Package Center. |
|
|
Appearance |
|
Size (Height x Width x
Depth) |
88 mm x 482 mm x 724
mm |
Weight |
14.9
kg |
|
|
Others |
|
System
Fan |
80 mm x 80 mm x 4
pcs |
Fan Speed
Mode |
Full-Speed
Mode |
|
Cool
Mode |
|
Quiet
Mode |
Easy Replacement System
Fan |
Yes |
Wireless Support
(dongle) |
Yes |
Power
Recovery |
Yes |
Noise
Level* |
57
dB(A) |
Scheduled Power
On/Off |
Yes |
Wake on
LAN/WAN |
Yes |
Power Supply Unit /
Adapter |
2 X
500W |
AC Input Power
Voltage |
100V to 240V
AC |
Power
Frequency |
50/60 Hz, Single
Phase |
Power
Consumption* |
313 W
(Access) |
|
126 W (HDD
Hibernation) |
British Thermal
Unit |
1068 BTU/hr
(Access) |
|
430 BTU/hr (HDD
Hibernation) |
Redundant Power Supply
(for xs+ and RP model) |
Yes |
|
|
Environment
Temperature |
|
Operating
Temperature |
5 DegreeC to 35 DegreeC
(40 DegreeF to 95 DegreeF) |
Storage
Temperature |
-20 DegreeC to 60
DegreeC (-5 DegreeF to 140DegreeF) |
Relative
Humidity |
5% to 95%
RH |
|
|
Certification |
FCC Class
A |
|
CE Class
A |
|
BSMI Class
A |
|
|
Warranty |
5
Years |
|
|
DSM
Specifications |
|
Storage
Management |
|
Maximum Internal Volume
Number |
1024 |
Maximum iSCSI Target
Number |
128 |
Maximum iSCSI
LUN |
512 |
iSCSI LUN
Clone/Snapshot, Windows ODX |
Yes |
RAID
Group |
Yes |
Supported RAID
Type |
RAID
F1 |
|
Basic |
|
JBOD |
|
RAID
0 |
|
RAID
1 |
|
RAID
5 |
|
RAID
6 |
|
RAID
10 |
RAID
Migration |
Basic to RAID
1 |
|
Basic to RAID
5 |
|
RAID 1 to RAID
5 |
|
RAID 5 to RAID
6 |
Volume Expansion with
Larger HDDs |
RAID
F1 |
|
RAID
1 |
|
RAID
5 |
|
RAID
6 |
Volume Expansion by
Adding a HDD |
RAID
F1 |
|
RAID
5 |
|
RAID
6 |
|
JBOD |
Global Hot Spare
Supported RAID Type |
RAID
F1 |
|
RAID
1 |
|
RAID
5 |
|
RAID
6 |
|
RAID
10 |
|
|
SSD
Support |
|
SSD Read/Write
Cache (White Paper) |
Yes |
SSD
TRIM |
Yes |
|
|
File Sharing
Capacity |
|
Maximum Local User
Accounts |
16000 |
Maximum Local
Groups |
512 |
Maximum Shared
Folder |
512 |
Maximum Shared Folder
Sync Tasks |
32 |
Maximum Concurrent
CIFS/AFP/FTP Connections |
4096 |
Windows Access Control
List (ACL) Integration |
Yes |
NFS Kerberos
Authentication |
Yes |
|
|
High Availability
Manager |
Yes |
|
|
Log
Center |
Yes |
Syslog Events per
Second |
3000 |
|
|
Virtualization |
|
VMware vSphere 6 with
VAAI |
Yes |
Windows Server
2012 |
Yes |
Windows Server 2012
R2 |
Yes |
Citrix
Ready |
Yes |
OpenStack |
Yes |
|
|
Add-on
Packages |
|
Antivirus by McAfee
(Trial) |
Yes |
|
|
Central Management
System |
Yes |
|
|
Chat |
Yes |
Maximum
Users |
2000 |
Notes |
The number of
concurrent HTTP connections for Chat was configured to the
maximum. |
|
CPU and RAM usage were
both under 80% when the number of maximum users was
reached. |
|
For tested models with
expandable memory, the maximum amount of RAM was
installed. |
|
|
Cloud Station
Server |
Yes |
Maximum Concurrent File
Transfers |
16000 |
Maximum Concurrent File
Transfers (with RAM expansion) |
30000 |
|
|
DDSM |
Yes |
Maximum DDSM Number
(Licenses required) |
100 (including 1 Free
License) (Learn more) |
|
|
exFAT Access
(optional) |
Yes |
|
|
MailPlus / MailPlus
Server |
Yes |
Free Email
Accounts |
5 (Licenses
required for additional accounts) |
Recommended MailPlus
Client Number |
Up to
900 |
Maximum Server
Performance |
3,604,000 emails per
day, approx. 110GB |
Notes |
The CPU and RAM usages
were both under 80% when testing recommended client
numbers. |
|
For tested models with
expandable memory, the maximum amount of RAM was
installed. |
|
Read-write SSD cache
was enabled in 5-bay (and above) NAS models with 2 SSDs units
installed. |
|
The performance of the
mail system will slightly decrease in high-availability mode due to data
synchronization between the two servers. |
|
Functions that were
enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist,
content scan, full-text search (English only). |
|
|
Office |
Yes |
Maximum
Users |
2000 |
Maximum Simultaneous
Editing Users |
100 |
Notes |
CPU and RAM usage were
both under 80% when the number of maximum users was
reached. |
|
For tested models with
expandable memory, the maximum amount of RAM was
installed. |
|
Client performance may
affect maximum simultaneous editing users. Client PCs used for testing:
Intel Core i3-3220 / 8GB RAM |
|
|
Snapshot
Replication |
Yes |
Maximum Snapshots per
Shared Folder |
1024 |
Maximum Snapshots of
all Shared Folder |
65536 |
|
|
Surveillance
Station |
Yes |
Maximum IP cam
(Licenses required) |
100 (including 2 Free
License) (See All Supported IP Cameras) |
Total FPS
(H.264)* |
3000 FPS @ 720p
(1280x720) |
|
2800 FPS @ 1080p
(1920x1080) |
|
1200 FPS @ 3M
(2048x1536) |
|
700 FPS @ 5M
(2591x1944) |
Total FPS
(MJPEG)* |
1300 FPS @ 720p
(1280x720) |
|
700 FPS @ 1080p
(1920x1080) |
|
500 FPS @ 3M
(2048x1536) |
|
400 FPS @ 5M
(2591x1944) |
Notes |
Surveillance Station
throughput is tested with Axis network camera, using continuous recording
with live view from Surveillance Station and motion detection by camera.
Live view and recording are sharing the same stream from the
camera. |
|
|
VPN
Server |
Yes |
Maximum
Connections |
30 |
|
|
Environment &
Packaging |
|
Environment |
RoHS
Compliant |
|
|
Packaging
Content |
Main Unit X
1 |
|
Accessory Pack X
1 |
|
AC Power Cord X
2 |
|
Quick Installation
Guide X 1 |
|
|
Optional
Accessories |
Surveillance Device
License Pack |
|
16GB DDR4 ECC
RDIMM |
|
32GB DDR4 ECC
RDIMM |
|
Expansion
Unit: RX1217sas X 2 |
|
Expansion
Unit: RX2417sas X 2 |
|
VS360HD |
|
Synology RKS1317 - Rail
Kit Sliding |
|
Synology Ethernet
Adapter E10G15-F1 |
|
Synology Ethernet
Adapter
E10G17-F2 |
