Model
Numbers (512E) |
ST8000NE0001 |
Rescue
Model Number |
ST8000NE0011 |
Interface
Options |
SATA
6Gb/s |
|
|
Features |
|
RV
Sensors |
Yes |
5-Year
Option with Rescue Model only |
Yes |
Humidity
Sensor |
Yes |
Super
Parity |
Yes |
Low
Halogen |
Yes |
AcuTracâ„¢
Technology |
Yes |
Power
Balance Technology |
Yes |
Hot-Plug
Support3 |
Yes |
Cache,
Multisegmented (MB) |
256 |
|
|
Reliability/Data
Integrity |
|
Mean
Time Between Failures (MTBF, hours) |
1.2M |
Reliability
Rating @ Full 24x7 Operation (AFR) |
0.63% |
Nonrecoverable
Read Errors per Bits Read |
1
sector per 10E15 |
Power-On
Hours per Year |
8760
(24x7) |
Sector
Size (Bytes per Logical Sector) |
512/4096 |
Limited
Warranty (years) |
5 |
|
|
Performance |
|
Spindle
Speed (RPM) |
7200 |
Interface
Access Speed (Gb/s) |
6.0,
3.0, 1.5 |
Max.
Sustained Transfer Rate OD (MB/s) |
230 |
Average
Latency (ms) |
4.16 |
Interface
Ports |
Single |
Rotation
Vibration @ 1500 Hz (rad/s² |
12.5 |
|
|
Power
Consumption |
|
Startup
Current, Average (12V, A) |
1.8 |
Idle
Power, Average (W |
TBD |
Operating
Mode, Typical (W) |
9 |
Standby/Sleep
Mode, Typical (W) |
0.6 |
Power
Supply Requirements |
+12V
and +5V |
|
|
Environmental |
|
Temperature,
Operating (°C) |
5
to 60 |
Vibration,
Nonoperating: 10Hz to 500Hz (Grms) |
5 |
Shock,
Operating, 2ms (Read/Write) (Gs) |
70/40 |
Shock,
Nonoperating, 1ms and 2ms (Gs) |
250 |
|
|
Physical |
|
Height
(in/mm, max)4 |
1.028/26.1 |
Width
(in/mm, max)4 |
4.010/101.85 |
Depth
(in/mm, max)4 |
5.878/147.0 |
Weight
(g/lb) |
1.720/780 |
Carton
Unit Quantity |
20 |
Cartons
per Pallet |
40 |
Cartons
per Layer |
8 |
