General |
|
|
Capacity |
8
TB |
|
Standard Model
Numbers |
ST8000VX004 |
|
SkyHawk Health
Management Included |
Yes |
|
Interface |
SATA 6
Gb/s |
|
|
|
Features and
Performance |
|
Drive Bays
Supported |
Up to
16 |
|
Cameras
Supported |
Up to
64 |
|
RV
Sensors |
Yes |
|
Max. Sustained Transfer
Rate OD (MB/s) |
210MB/s |
|
Cache
(MB) |
256 |
|
|
|
Reliability/Data Integrity |
|
Tarnish
Resistant |
Yes |
|
Load/Unload
Cycles |
300,000 |
|
Non-recoverable Read
Errors per Bits Read, Max |
1 per
10E15 |
|
Power-On Hours per Year
(247) |
8,760 |
|
Workload Rate Limit
(WRL)2 |
180 |
|
MTBF |
1,000,000
hr |
|
Warranty, Limited
(years) |
3 |
|
|
|
Power
Management |
|
Startup Current,
Typical (12V, A) |
1.8 |
|
Average Operating Power
(W) |
8.73
W |
|
Idling Average
(W) |
7.06
W |
|
Standby Mode/Sleep
Mode, Typical (W) |
0.96/0.96 |
|
Voltage Tolerance (5
V) |
+10/-5% |
|
Voltage Tolerance (12
V) |
10% |
|
|
|
Environmental/Temperature |
|
Operating (ambient, min
C) |
5 |
|
Operating (drive case,
max C)4 |
70 |
|
Non-operating (ambient,
min C) |
-40 |
|
|
|
Physical |
|
Height (mm/in,
max) |
26.11 mm/1.028
in |
|
Width (mm/in,
max) |
101.85 mm/4.01
in |
|
Depth (mm/in,
max) |
146.99 mm/5.787
in |
|
Weight
(lb/g) |
716 g/1.579
lb |
|
Carton Unit
Quantity |
20 |
|
Cartons per Pallet /
Cartons per Layer |
40/8 |
