Hardware |
|
CPU |
Intel Celeron J4105
quad-core 1.5 GHz processor (burst up to 2.5 GHz) |
CPU
Architecture |
64-bit
x86 |
Graphic
Processors |
Intel HD Graphics
600 |
Floating Point
Unit |
|
Encryption
Engine |
(AES-NI) |
Hardware-accelerated
Transcoding |
|
System
Memory |
4 GB SO-DIMM DDR4 (2 x
2 GB) |
Maximum
Memory |
8 GB (2 x 4
GB) |
Memory
Slot |
2 x SO-DIMM DDR4
|
For dual-DIMM
configuration, you must use a pair of identical RAM
modules. |
Flash
Memory |
4GB (Dual boot OS
protection) |
Drive
Bay |
2 x 3.5-inch SATA
6Gb/s, 3Gb/s |
The system is shipped
without HDD. |
For the HDD
compatibility list, please
visit https://www.qnap.com/compatibility/ |
Drive
Compatibility |
3.5-inch SATA hard disk
drives |
2.5-inch SATA hard disk
drives |
2.5-inch SATA solid
state drives |
Hot-swappable |
|
M.2 SSD
Slot |
2 x M.2 2280 SATA 6Gb/s
slots |
SSD Cache
Acceleration Support |
|
Gigabit Ethernet Port
(RJ45) |
1 |
10 Gigabit Ethernet
Port |
1 x 10GBASE-T
(10G/5G/2.5G/1G/100M) |
Jumbo
Frame |
|
USB 2.0
port |
2 |
USB 3.0
port |
3 (1 x USB-C, 2 x
USB-A) |
IR
Sensor |
(RM-IR004) |
HDMI
Output |
2, HDMI 2.0 (up to
resolution 3840 x 2160 @ 60Hz) + HDMI 1.4b (up to 3840 x 2160 @
30Hz) |
Audio
Input |
2 x 3.5mm dynamic
microphone input jacks |
Audio
Output |
1 x built-in speaker, 1
x 3.5mm line out jack (for amplifiers or speakers) |
Form
Factor |
Set-top
design |
LED
Indicators |
Power/Status,
HDD1-2 |
Buttons |
Power,
Reset |
Dimensions
(HxWxD) |
43.8 404 220
mm |
Weight
(Net) |
2.4
kg |
Weight
(Gross) |
3.87
kg |
Operating
temperature |
0 - 35 C (32F -
95F) |
Relative
Humidity |
5-95% RH
non-condensing, wet bulb: 27C (80.6F) |
Power Supply
Unit |
External Power Adapter,
90W, 100-240V |
Power Consumption: HDD
Sleep Mode |
13.55
W |
Power Consumption:
Operating Mode, Typical |
22.38
W |
Sound
Level |
6.2
db(A) |
System
Warning |
Buzzer |
Software |
|
Operating
System |
QTS (embedded
Linux) |
Supported Client
Operating Systems |
1. Apple Mac OS 10.7 or
later |
2. Linux and
UNIX |
3. Microsoft Windows 7,
8, and 10 |
4. Microsoft Windows
Server 2003, 2008 R2, 2012, 2012 R2 and 2016 |
Supported
Browsers |
1. Apple Safari 7 or
later |
2. Google
Chrome |
3. Microsoft Internet
Explorer 10 or later |
4. Mozilla
Firefox |
Supported
Languages |
Chinese (traditional
and simplified), Czech, Danish, Dutch, English, Finnish, French, German,
Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese
(Brazil), Romanian, Russian, Spanish, Swedish, Thai, and
Turkish |
Supported File
Systems |
1. Internal hard drive
(EXT4) |
2. External hard drive
(EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT) |
Note: To use exFat you
must purchase an exFAT driver license from License
Center. |
Network & Virtual
Switch |
1. TCP/IP: Dual stack
(IPv4 and IPv6) |
2. Jumbo
frame |
3. Port trunkingLink
aggregation |
failover |
Web
Server |
1. HTTP/HTTPS
Connections |
2. Supports WebDAV
Connection |
3. Supports Virtual
Host (Max: 32) |
4. Importable SSL
Certificate |
Security |
1. Network access
protection with auto-blocking (SSH, Telnet, HTTP(S), FTP, CIFS/SMB, and
AFP) |
2. Host access control
for shared folders (CIFS/SMB) |
3. AES 256-bit
folder-based and volume-based encryptions which are validated by FIPS
140-2 CAVP (Cryptographic Algorithm Validation
Program) |
4. 256-bit external
drive encryption (AES) |
Storage
Management |
1. Supported RAID
types: RAID 0, 1, 5, 6, 10, JBOD, Single |
2. RAID Hot Spare and
Global Hot Spare |
3. RAID Rebuild Speed
Customization |
4. Online RAID capacity
expansion |
iSCSI (IP
SAN) |
1. iSCSI targets with
multiple LUNs per target |
Note: The maximum
number of targets is 256. |
2. LUN mapping and
masking |
3. Online LUN capacity
expansion |
4. SPC-3 persistent
reservation |
Notification
Center |
1. Added support for
sending notifications via SMS providers, including Nexmo, Twilio, and
Clickatell. |
2. Added Outlook as an
SMTP service option. |
3. Added support for
sending notifications via instant messaging applications, including Skype
and Facebook Messenger. |
4. Added support for
Overview and History in Notification Center. |
Power
Management |
1. Wake-on-LAN
(WoL) |
2. Standby mode for
internal drives |
3. Scheduled power on
and off |
4. Automatic power on
after power recovery |
Access Rights
Management |
1. Multiple user
creation |
2. User data importing
and exporting |
3. User quota
management |
4. Local user access
control (AFP, CIFS/SMB, FTP, and WebDAV) |
Domain
Authentication |
1. Microsoft Active
Directory (AD) and domain controller support |
2. LDAP server and
client |
3. Domain user login
(AFP, CIFS/SMB, FTP, and File Station) |
myQNAPcloud |
1. Free host name
registration (DDNS) |
2. Optional myQNAPcloud
SSL certificates (DDNS) |
3. Auto router
configuration using UPnP |
4. Web-based file
manager with HTTPS 2048-bit encryption |
Qsync |
1. File syncing across
multiple devices with SSL secure connection |
2. Selective
synchronization for specific folders or subfolders |
3. Team folders as file
center for better collaboration |
4. File sharing using
email links |
Resource
Monitor |
1. Monitoring of NAS
system resources such as CPU, memory and network |
2. Monitoring of NAS
storage resources such as volumes, RAID, and disk
activity |
3. Monitoring of NAS
application resource use |
4. Creation of extra
swap space when SSDs are installed |
Helpdesk |
1. Reporting of issues
to the QNAP support team, with automatic collection of system
information |
2. Remote connection
between QNAP support engineers and NAS for issue resolution (with user
permission) |
Web
Administration |
1. Multi-window,
multitasking system management |
2. Smart toolbar and
dashboard for system status display |
3. SNMP versions 2 and
3 |
4. Resource
monitor |
File
Server |
1. File sharing across
Windows, Mac, and Linux/UNIX |
2. Microsoft
networking |
3. Windows
ACL |
4. Advanced folder
permissions (AFP, CIFS/SMB, and FTP) |
FTP
Server |
1. FTP over SSL/TLS
(explicit) |
2. FXP
support |
File
Station |
1. Cloud drive mounting
for Google Drive, Dropbox, Microsoft OneDrive, Microsoft OneDrive for
Business, HiDrive, Amazon Cloud Drive, Yandex Disk and
Box |
2. Remote shared folder
mounting (CIFS/SMB, FTP, and WebDAV) |
3. Document viewing
using Office Online, Google Docs, and Chrome
extension |
4. Microsoft Office
file editing using Google Docs, Sheets, and Slides |
Qfiling |
1. Auto
filing |
2. Recipe
function |
3. Archiving through
iSCSI, USB, DVD and remote NAS |
4. Advanced
settings |
Transcode
Management |
1. Video transcoding
(240p, 360p, 480p, 720p and 1080p resolution) |
2. Automatic video
transcoding for watched folders |
3. Hardware-accelerated
transcoding |
4. Embed subtitles into
videos for background transcoding |
Hybrid Backup
Sync |
1. Cloud storage backup
to Amazon Glacier, Amazon S3, Azure Storage, Google Cloud Storage, HKT
Object Storage, OpenStack Swift, WebDAV |
2. Cloud storage
syncing with Alibaba Cloud, Amazon Drive, Amazon S3, BackBlaze B2, Box,
Dropbox, OneDrive, Google Drive, HiDrive, hubiC, OneDrive, OneDrive For
Business, ShareFile, Yandex.Disk |
3. RTRR server &
client with bandwidth control |
4. Rsync server with
download bandwidth control |
Station |
1. Photo organization
by thumbnail, list, timeline, or folder |
2. Virtual and smart
albums |
3. Validity control for
album sharing |
4. Photo tagging with
text, colors, and ratings |
Music
Station |
1. Music playing and
sharing through web browsers |
2. Music streaming to
multiple devices |
3. Changing of album
covers through Google search or by uploading photos |
4. Internet radio
(MP3) |
iTunes
Server |
Audio and video sharing
for Windows & Mac iTunes |
Video
Station |
1. Video organization
by thumbnail, list, timeline, or folder |
2. Virtual and smart
collections |
3. Video tagging with
text, colors, and ratings |
4. Video link sharing
through social media and email |
Virtualization
Station |
1. Virtual machine
creation (Windows, Linux, Unix, and Android) |
2. Virtual machine
importing, exporting, cloning, snapshot capturing, backup, and
restoration |
3. Console display
using HDMI output (QVM) |
4. HTML5-based shared
remote console |
Container
Station |
1. Support for LXC and
Docker |
2. Application
downloading from the built-in Docker Hub Registry |
3. One-click
installation |
4. Container importing
and exporting |
Qsirch |
1. Full-text
search |
2. Data distribution
using a bar chart |
3. Previews for photos,
music, videos, PDFs, Gmail, and others |
4. Advanced search
operators and search scope |
Surveillance
Station |
1. Support for up to
5,000 IP cameras |
2. 4 free camera
licenses |
Note: Surveillance
Station supports a maximum of 40 camera channels. To add more camera
channels, you need to purchase licenses from the QNAP License
Store. |
3. Instant playback for
recent surveillance events |
4. Visual options for
e-maps |
QVR
Pro |
1. Free 8 built-in
camera channels for all models |
2. Expandable up to 128
camera channels (QVR Pro Gold license required) |
Note: The maximum
number of channels supported varies by NAS model, network configuration,
and camera settings. For more information,
visit https://www.qnap.com/go/qvr-nas-selector. |
3. Support for using
QVR Pro as the motion detector |
4. Camera management
across different networks |
QVR Pro Client
(Desktop) |
1. Instant switch
between Live and Playback modes |
2. Dynamic and
adjustable layouts for camera and E-map views |
3. Qdewarp technique
for dewarping fisheye and 360-degree cameras |
4. Region of interest
for each channel |
QVR Pro Client
(Mobile) |
1. Instant switch
between Live and Playback modes |
2. Cross-platform
support: Android and iOS |
3. Various advanced
monitoring options, including sequential mode, PTZ control, auto cruising,
and preset point control |
4. Support for
receiving Instant push notifications |
QVR
Center |
1. Support for managing
up to 128 QVR Pro servers (QVR Pro Gold license
required) |
2. Statistical graphics
for visualizing event data |
3. Log management for
all added servers |
4. Integration with QVR
Pro Client for central monitoring across multiple
servers |
QVR
Guard |
1. Failover solution
designed for QVR Pro to ensure server availability |
2. Viewing task details
during the failover period |
3. Automatic switch
between Standby and Takeover modes based on the QVR Pro server
status |
QVR Pro
CamPack |
Support for more camera
manufacturers and models |
Note: To download the
Camera Package, go to QVR Pro Plug-in Center. |
QUSBCam2 |
1. Support for
configuring USB webcams as ONVIF IP cameras (remotely
manageable) |
2. Support for
monitoring live views (no other apps required) |
3. Support for
RTSP |
QVPN
Service |
1. VPN
server |
Friendly graphical
overview page. |
Secure remote access
with PPTP, L2TP/IPSec, OpenVPN, QBelt(QNAP proprietary)
protocol. |
Support for a maximum
of 100 clients. |
DLNA
Server |
1. Support for
DLNA/UPnP TVs and players such as PlayStation 4 and Xbox
One |
2. Support for CUE
indexing file for APE and FLAC |
Qcenter (NAS
CMS) |
1. Monitoring of
multiple NAS devices |
2. Utilization history
reports |
3. Unified
configuration management |
4. Monitoring of NAS
devices behind NAT routers with Connect to Qcenter |
Note: The application
is available in the App Center and in virtual appliance marketplaces
(VMware vSphere ESXi and Microsoft Hyper-V). |
OceanKTV |
1. YouTube video
streaming |
2. Sorting by artist,
language, and favorites |
3. Effects such as
tuning echo, key, and applause |
4. Playlist control
with a mobile application |
Note: Microphones are
not included. |
Qfinder
Pro |
1. QNAP NAS location on
the same local network |
2. NAS shared folder
mounting |
3. Basic setting
configuration (firmware, SMTP server, and network
settings) |
4. Storage Plug &
Connect (Windows only) |
App
Center |
1. Official and
community software add-ons |
2. Automatic updates
and notifications for new versions |
3. Repository for
imported third-party content |
4. User-specified
volume for storing applications |
AirPlay &
Chromecast |
1. Video, photo and
music streaming to Apple TV or Chromecast using the
following: |
NAS applications: File
Station, Music Station, Photo Station, and Video
Station |
Mobile applications:
Qfile, Qmusic, Qphoto, and Qvideo |
Note: You must install
the Media Streaming add-on from App Center. |
Download
Station |
1. PC-less downloads
(BitTorrent, FlashGet, FTP/FTPS, HTTP/HTTPS, QQDL, and
Thunder) |
Note: |
The application
supports a maximum of 500 tasks. |
The maximum number of
concurrent downloads is 90 (30 BT/PT, 30 HTTP, 30
FTP) |
2. BitTorrent: Support
for search, magnet links, private trackers, and proxy |
Notes Station
3 |
1. Insert Evernote
Notes in Notes Station 3 |
2. Enable Embedding
YouTube video into Notes |
3. Table creation using
the insert table editor |
HD (HybridDesk)
Station |
1. Photo, video, and
music playback on TV through HDMI |
2. Support for Chrome
and Firefox |
3. Support for
international keyboards and mouse input |
4. User login
permissions |
Note: The decoding
capability of the CPU and graphics card may affect playback of some video
files. |
Linux
Station |
1. Usage of the NAS as
a Linux-based computer |
2. Support for Ubuntu
14.04, Ubuntu 16.04 and Ubuntu Kylin 16.04 |
3. Application
downloading and usage from the Ubuntu Software Center |
4. Remote desktop for
remote monitoring and accessing of Ubuntu |
Qcontactz |
1. One-way scheduled
sync of contacts from multiple Google accounts |
2. Contact importing
from CSV or vCard 3.0 files |
3. Contact exporting to
CSV or vCard 3.0 files |
4. Duplicate contact
searching and merging |
IFTTT
Agent |
1. Daily task
automation |
2. Social media data
archiving |
3. File synchronization
between the NAS and various cloud services |
4. System event
notifications on Line, Skype, Gmail, and mobile
phones |
QIoT Suite
Lite |
1. Launch your IoT
application with the shortest time and least human
force |
2. Supports multiple
protocols (MQTT, HTTP and CoAP) and dashboards, and allows for the quick
connection of development boards along with multiple
sensors |
3. The graphical rules
engine provides drag-and-drop blocks with connection nodes, making it
flexible to form a workflow |
4. The customizable
dashboard offers great advantages to help monitor important information of
connected IoT devices. |
QRM+ |
1. Centralized Remote
Management solution designed for IT Teams in every industry relying on
networked computing devices. |
2. Remote Management of
Windows, Linux and IPMI compatible devices |
3. Offers you threshold
based alerts to fix performance problems before they impact your users,
applications and the business. |
4. Supports many active
monitors like CPU Utilization, Memory Utilization, Disk Utilization, CPU
Temperature, CPU Fan speed, and many more, giving complete visibility for
administrators across all the mission critical computing
devices. |
Security
Counselor |
1. Multiple Security
Policies (Basic/Intermediate/Advanced/Custom). |
2. Checks NAS settings
for security weaknesses. |
3. Integrates with
existing anti-virus services. |
4. Integrates with
existing anti-malware services. |
General
Notes |
1. Designs and
specifications are subject to change without notice. |
2. Some features may
vary by model. |
3. QTS does not support
DRM content and some IPv6 services. |
4. Some data encryption
features may be unavailable because of country-specific legislative
restrictions. |
