Essentials |
|
|
Product
Collection |
Intel
NUC Kit with 11th Generation Intel Core
Processors |
|
Code
Name |
Products
formerly Panther Canyon |
|
Status |
Launched |
|
Launch
Date |
Q1'21 |
|
Supported
Operating Systems |
Windows
10, 64-bit* |
|
Board
Number |
NUC11PABi5 |
|
Board
Form Factor |
UCFF
(4" x 4") |
|
Socket |
Soldered-down
BGA |
|
Internal
Drive Form Factor |
M.2
and 2.5" Drive |
|
#
of Internal Drives Supported |
2 |
|
Lithography |
10
nm |
|
TDP |
40
W |
|
DC
Input Voltage Supported |
19
VDC |
|
Processor
Included |
Intel
Core i5-1135G7 Processor (8M Cache, up to 4.20
GHz) |
|
Intel
vPro Platform Eligibility |
No |
|
#
of Cores |
4 |
|
#
of Threads |
8 |
|
Max
Turbo Frequency |
4.20
GHz |
|
Warranty
Period |
3
yrs |
|
Supplemental
Information |
|
|
Embedded
Options Available |
No |
|
Description |
Other
features: Includes far-field quad array
microphones |
|
Memory
& Storage |
|
|
Max
Memory Size (dependent on memory type) |
64
GB |
|
Memory
Types |
DDR4-3200
1.2V SO-DIMM |
|
Max
# of Memory Channels |
2 |
|
Max
Memory Bandwidth |
51.2
GB/s |
|
Max
# of DIMMs |
2 |
|
ECC
Memory Supported |
No |
|
Processor
Graphics |
|
|
Processor
Graphics |
Intel
Iris Xe Graphics |
|
Integrated
Graphics |
Yes |
|
Graphics
Output |
HDMI
2.0a; USB-C (DP1.4); MiniDP 1.4 |
|
#
of Displays Supported |
4 |
|
Expansion
Options |
|
|
PCI
Express Revision |
Gen4 |
|
PCI
Express Configurations |
M.2
slot with PCIe X4 lanes |
|
Removable
Memory Card Slot |
SDXC
with UHS-II support |
|
M.2
Card Slot (storage) |
22x80 |
|
I/O
Specifications |
|
|
#
of USB Ports |
7 |
|
USB
Configuration |
2x
front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C); USB
2.0, USB 3.1 Gen2 via internal headers |
|
USB
Revision |
2.0,
3.1 Gen2 |
|
USB
2.0 Configuration (External + Internal) |
0
+ 1 |
|
USB
3.0 Configuration (External + Internal) |
2B
2F + 1 |
|
Total
# of SATA Ports |
2 |
|
Max
# of SATA 6.0 Gb/s Ports |
2 |
|
Audio
(back channel + front channel) |
7.1
digital (HDMI mDP); L+R mic (F) |
|
Integrated
LAN |
Intel
Ethernet Controller i225-V |
|
Integrated
Wireless |
Intel
Wi-Fi 6 AX201 |
|
Integrated
Bluetooth |
Yes |
|
Consumer
Infrared Rx Sensor |
Yes |
|
Additional
Headers |
CEC,
USB3.1, USB2.0, FRONT_PANEL, RGB |
|
#
of Thunderbolt Ports |
2x
Thunderbolt 3 |
|
Package
Specifications |
|
|
Chassis
Dimensions |
117
x 112 x 51mm |
|
Advanced
Technologies |
|
|
Intel
Virtualization Technology for Directed I/O (VT-d)
|
Yes |
|
Intel
vPro Platform Eligibility |
No |
|
TPM |
No |
|
Intel
HD Audio Technology |
Yes |
|
Intel
Rapid Storage Technology |
Yes |
|
Intel
Virtualization Technology (VT-x) |
Yes |
|
Intel
Platform Trust Technology (Intel PTT) |
Yes |
|
Security
& Reliability |
|
|
Intel
AES New Instructions |
Yes |
