CPU |
1.
AMD Socket AM4, support for: AMD Ryzen 5000 Series Processors/ AMD Ryzen
4000 G-Series Processors/ AMD Ryzen 3000 Series Processors/ AMD Ryzen 3000
G-Series Processors/ AMD Ryzen 2000 Series Processors/ AMD Ryzen 2000
G-Series Processors |
|
(Please
refer "CPU Support List" for more
information.) |
|
Chipset |
1.
AMD X570 |
|
Memory |
1.
AMD Ryzen 5000 Series Processors/AMD Ryzen 4000 G-Series Processors/AMD
Ryzen 3000 Series Processors: |
|
Support
for DDR4 3200/2933/2667/2400/2133 MHz memory
modules |
|
2.
AMD Ryzen 3000 G-Series Processors/AMD Ryzen 2000 Series Processors/AMD
Ryzen 2000 G-Series Processors: |
|
Support
for DDR4 2933/2667/2400/2133 MHz memory
modules |
|
3.
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory |
|
4.
Dual channel memory architecture |
|
5.
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory
modules |
|
6.
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory
modules |
|
7.
Support for Extreme Memory Profile (XMP) memory
modules |
|
(Please
refer "Memory Support List" for more
information.) |
|
Onboard
Graphics |
Integrated
Graphics Processor: |
|
1.
1 x HDMI port, supporting a maximum resolution of 4096x2160@60
Hz |
|
*
Support for HDMI 2.1 version, HDCP 2.3, and
HDR. |
|
Maximum
shared memory of 16 GB |
|
For
AMD Ryzen 4000 G-Series Processors/AMD Ryzen 3000 G-Series Processors/AMD
Ryzen 2000 G-Series Processors only. |
|
Audio |
1.
Realtek ALC1220-VB Audio CODEC |
|
*
The back panel line out jack supports DSD
audio. |
|
2.
Support for DTS:X Ultra |
|
3.
High Definition Audio |
|
4.
2/4/5.1/7.1-channel |
|
5.
Support for S/PDIF Out |
|
LAN |
1.
Intel 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100
Mbps) |
|
Wireless
Communication module |
Intel Wi-Fi
6 AX200 |
|
1.
WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz
Dual-Band |
|
2.
BLUETOOTH 5.1 |
|
3.
Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data
rate |
|
*
Actual data rate may vary depending on environment and
equipment. |
|
Expansion
Slots |
1
x PCI Express x16 slot (PCIEX16), integrated in the
CPU: |
|
1.
AMD Ryzen 5000 Series Processors/AMD Ryzen 3000 Series Processors support
PCIe 4.0 x16 mode |
|
2.
AMD Ryzen 4000 G-Series Processors/AMD Ryzen 2000 Series Processors
support PCIe 3.0 x16 mode |
|
3.
AMD Ryzen 3000 G-Series Processors/AMD Ryzen 2000 G-Series Processors
support PCIe 3.0 x8 mode |
|
1
x PCI Express x16 slot (PCIEX8), integrated in the
CPU: |
|
1.
AMD Ryzen 5000 Series Processors/AMD Ryzen 3000 Series Processors support
PCIe 4.0 x8 mode |
|
2.
AMD Ryzen 4000 G-Series Processors/AMD Ryzen 2000 Series Processors
support PCIe 3.0 x8 mode |
|
3.
AMD Ryzen 3000 G-Series Processors/AMD Ryzen 2000 G-Series Processors do
not support this slot. |
|
*
For optimum performance, if only one PCI Express graphics card is to be
installed, be sure to install it in the PCIEX16
slot. |
|
*
The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8
slot is populated, the PCIEX16 slot operates at up to x8
mode. |
|
1
x PCI Express x16 slot (PCIEX4), integrated in the
Chipset: |
|
1.
Supporting PCIe 4.0*/3.0 x4 mode |
|
*
For AMD Ryzen 5000 Series Processors/AMD Ryzen 3000 Series Processors
only. |
|
Multi-Graphics
Technology |
1.
Support forAMDQuad-GPU CrossFire and 2-WayAMD CrossFire
technologies |
|
For
AMD Ryzen 5000 Series Processors/AMD Ryzen 4000 G-Series Processors/AMD
Ryzen 3000 Series Processors/AMD Ryzen 2000 Series Processors
only |
|
Storage
Interface |
1
x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M
key, type 2242/2280/22110 SSDs: |
|
1.
AMD Ryzen 5000 Series Processors/AMD Ryzen 3000 Series Processors support
SATA and PCIe 4.0 x4/x2 SSDs |
|
2.
AMD Ryzen 4000 G-Series Processors/AMD Ryzen 3000 G-Series Processors/AMD
Ryzen 2000 Series Processors/AMD Ryzen 2000 G-Series Processors support
SATA and PCIe 3.0 x4/x2 SSDs |
|
1
x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3,
M key, type 2242/2280/22110 SSDs: |
|
1.
Supporting PCIe 4.0*/3.0 x4/x2 SSDs |
|
*
For AMD Ryzen 5000 Series Processors/AMD Ryzen 3000 Series Processors
only. |
|
1
x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3,
M key, type 2242/2280/22110 SSDs: |
|
1.
Supporting SATA and PCIe 4.0*/3.0 x4/x2 SSDs |
|
*
For AMD Ryzen 5000 Series Processors/AMD Ryzen 3000 Series Processors
only. |
|
6
x SATA 6Gb/s connectors, integrated in the
Chipset: |
|
1.
Support for RAID 0, RAID 1, and RAID 10 |
|
*
Refer to "1-8 Internal Connectors," for the installation notices for the
M.2 and SATA connectors. |
|
USB |
CPU: |
|
1.
1 x USB 3.2 Gen 2 Type-A port (red) on the back
panel |
|
2.
3 x USB 3.2 Gen 1 ports on the back panel |
|
Chipset+ASMedia USB
3.2 Gen 2x2 Controller: |
|
1.
1 x USB Type-C port on the back panel, with USB 3.2 Gen 2x2
support |
|
Chipset: |
|
1.
1 x USB Type-C port with USB 3.2 Gen 2 support, available through the
internal USB header |
|
2.
3 x USB 3.2 Gen 2 Type-A ports (red) on the back
panel |
|
3.
4 x USB 3.2 Gen 1 ports available through the internal USB
headers |
|
Chipset+2
USB 2.0 Hubs: |
|
1.
8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available
through the internal USB headers) |
|
Internal
I/O Connectors |
1.
1 x 24-pin ATX main power connector |
|
2.
1 x 8-pin ATX 12V power connector |
|
3.
1 x 4-pin ATX 12V power connector |
|
4.
1 x CPU fan header |
|
5.
1 x water cooling CPU fan header |
|
6.
4 x system fan headers |
|
7.
2 x system fan/water cooling pump headers |
|
8.
2 x addressable LED strip headers |
|
9.
2 x RGB LED strip headers |
|
10.
1 x CPU cooler LED strip/RGB LED strip header |
|
11.
3 x M.2 Socket 3 connectors |
|
12.
6 x SATA 6Gb/s connectors |
|
13.
1 x front panel header |
|
14.
1 x front panel audio header |
|
15.
1 x USB Type-C header, with USB 3.2 Gen 2
support |
|
16.
2 x USB 3.2 Gen 1 headers |
|
17.
2 x USB 2.0/1.1 headers |
|
18.
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only) |
|
19.
1 x Thunderbolt add-in card connector |
|
20.
1 x Clear CMOS jumper |
|
21.
2 x temperature sensor headers |
|
Back
Panel Connectors |
1.
4 x USB 2.0/1.1 ports |
|
2.
2 x SMA antenna connectors (2T2R) |
|
3.
1 x HDMI port |
|
4.
1 x USB Type-C port, with USB 3.2 Gen 2x2
support |
|
5.
4 x USB 3.2 Gen 2 Type-A ports (red) |
|
6.
3 x USB 3.2 Gen 1 ports |
|
7.
1 x RJ-45 port |
|
8.
1 x optical S/PDIF Out connector |
|
9.
5 x audio jacks |
|
I/O
Controller |
1.
iTE I/O Controller Chip |
|
H/W
Monitoring |
1.
Voltage detection |
|
2.
Temperature detection |
|
3.
Fan speed detection |
|
4.
Water cooling flow rate detection |
|
5.
Overheating warning |
|
6.
Fan fail warning |
|
7.
Fan speed control |
|
*
Whether the fan (pump) speed control function is supported will depend on
the fan (pump) you install. |
|
BIOS |
1.
1 x 256 Mbit flash |
|
2.
Use of licensed AMI UEFI BIOS |
|
3.
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI
5.0 |
|
Unique
Features |
1.
Support for APP Center |
|
*
Available applications in APP Center may vary by motherboard model.
Supported functions of each applicationmay also vary depending
onmotherboard specifications. |
|
@BIOS |
|
EasyTune |
|
Fast
Boot |
|
Game
Boost |
|
ON/OFF
Charge |
|
RGB
Fusion |
|
Smart
Backup |
|
System
Information Viewer |
|
2.
Support for Q-Flash Plus |
|
3.
Support for Q-Flash |
|
4.
Support for Xpress Install |
|
Bundled
Software |
1.
Norton Internet Security (OEM version) |
|
2.
cFosSpeed |
|
Operating
System |
1.
Support for Windows 10 64-bit |
|
Form
Factor |
1.
ATX Form Factor; 30.5cm x
24.4cm |
