Specifications |
|
|
Processor
/ System Bus |
1
x Socket LGA1200 |
|
Intel
Xeon processor E-2300 family |
|
Intel Pentium
processors |
|
*Refer
to support page for more information |
|
Generation |
E11 |
|
Core
Logic |
Intel
C252 Chipset |
|
Memory |
|
|
Total
Slots : |
4
(2-channel) |
|
Capacity
: |
Maximum
up to 128GB UDIMM |
|
Memory
Type : |
DDR4 3200/2933/2666 UDIMM |
|
Memory
Size : |
32GB,
16GB, 8GB, 4GB UDIMM |
|
*
Refer to support page for more information |
|
Expansion
Slots |
Total
PCI/PCI-X/PCI-E/PIKE Slots: 3 |
|
1
x PCI-E x 16 (Gen4 x16 Link, switch to x8 link when slot B occupied),
FH/HL |
|
1
x PCI-E x 8 (Gen4 x8 Link), HH/HL* |
|
1
x PCI-E x 4 (Gen3 x4 Link), Proprietary R/A
slot |
|
(optional
for Intel X710 10G LAN card) |
|
*
not available when supporting NVME SSD |
|
Storage |
|
|
Storage
Controller : |
Intel
C252 Chipset |
|
6
x SATA3 6Gb/s ports |
|
IntelVROC
(For Linux/Windows) |
|
(Support
Software RAID 0/1/5/10 ) |
|
SAS
Controller : |
ASUS
PIKE II 3008-8i 8-port SAS 12G RAID card |
|
ASUS
PIKE II 3108-8i 8-port SAS 12G HW RAID card |
|
HDD
Bays |
4
x 3.5 Hot-Swap HDD Bays |
|
-up
to (2*SATA/SAS/NVMe + 2*SATA/SAS) |
|
*SAS
support only from optional SAS HBA/RAID card |
|
*NVMe
support only from optional NVMe upgrade kit |
|
Auxiliary
Storage FDD/CD/DVD |
1
x Slim-type Optical Drive Bay |
|
Options:
No Device / DVD-RW / DVD-ROM |
|
Networking |
2
x Intel I210AT + 1 x Mgmt LAN |
|
Graphic |
Aspeed
AST2600 with 64MB VRAM |
|
Front
I/O Ports |
1
x VGA port* |
|
2
x USB 3.2 Gen1 ports |
|
*Must
support by ASMB10 |
|
Rear
I/O Ports |
2
x USB 3.2 Gen 2 ports |
|
1
x VGA port * |
|
1
x HDMI port from CPU |
|
1
x COM port |
|
2
x RJ-45 ports |
|
1
x RJ-45 ports (One for ASMB10-iKVM)(Optional) |
|
*Must
support by ASMB10 |
|
Switch/LED |
Rear
Switch/LED: |
|
1
x Q-Code/Port 80 LED |
|
1
x Power switch |
|
Front
Switch/LED: |
|
1
x Power switch/LED |
|
1
x Location switch/LED |
|
1
x Reset switch |
|
1
x HDD Access LED |
|
1
x Message LED |
|
LAN
1-2 LED |
|
Management
Solution |
ASUS
Control Center Enterprise (Optional) Optional ASMB10-iKVM for
KVM-over-Internet |
|
Regulatory
Compliance |
BSMI,
CE, FCC(Class A) |
|
Dimensions |
497mm
x 439.5mm x 44mm |
|
Form
Factor |
1U |
|
Power
Supply |
1+1
Redundant 450W 80 PLUS PLATINUM Power Supply |
|
Environment |
Operating
temperature: 10C ~ 35C |
|
Non
operating temperature: -40C ~ 70C |
|
Non
operating humidity: 20% ~ 90% ( Non
condensing) |
