| Processor |
|---|
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Processor cache | 8 MB |
| Processor frequency | 2.8 GHz |
| Processor family | Intel Xeon E |
| Processor model | E-2314 |
| Processor boost frequency | 4.5 GHz |
| Processor manufacturer | Intel |
| Memory |
|---|
| Internal memory | 16 GB |
| Maximum internal memory | 128 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 4x DIMM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory clock speed | 3200 MHz |
| ECC | Yes |
| Storage |
|---|
| Number of HDDs installed | 8 |
| HDD interface | Serial Attached SCSI (SAS) |
| RAID support | Yes |
| Optical drive type | No |
| Maximum storage capacity | 61.44 TB |
| Network |
|---|
| LAN controller | Broadcom BCM5720 |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| USB 2.0 ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Expansion slots |
|---|
| PCI Express x8 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| Design |
|---|
| Chassis type | Tower (4U) |
| Optical drive type | No |
| Product colour | Black |
| Performance |
|---|
| Operating system installed | No |
| Compatible operating systems | Microsoft Windows Server 2019: Essentials, Standard, Datacenter, Hyper-V
Microsoft Windows Server 2022: Essentials, Standard, Datacenter
Red Hat Enterprise Linux (RHEL): 8.4 (64 bit, includes KVM)
SUSE Linux Enterprise Server (SLES): 12 SP5, 15 SP3 (64 bit, includes KVM & Xen)
VMware ESXi: 7.0 U3 |
| Software |
|---|
| Operating system installed | No |
| Compatible operating systems | Microsoft Windows Server 2019: Essentials, Standard, Datacenter, Hyper-V
Microsoft Windows Server 2022: Essentials, Standard, Datacenter
Red Hat Enterprise Linux (RHEL): 8.4 (64 bit, includes KVM)
SUSE Linux Enterprise Server (SLES): 12 SP5, 15 SP3 (64 bit, includes KVM & Xen)
VMware ESXi: 7.0 U3 |
| Processor special features |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| CPU configuration (max) | 1 |
| Power |
|---|
| Redundant power supply (RPS) support | No |
| Power supply | 500 W |
| Power supply input voltage | 100 - 240 V |
| Technical details |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Weight & dimensions |
|---|
| Width | 175 mm |
| Weight | 10.1 kg |
| Height | 368.3 mm |
| Depth | 475 mm |
| Other features |
|---|
| CPU configuration (max) | 1 |
