| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback |
| Chipset | Intel B860 Chipset |
| Form Factor | mATX Form Factor 9.6inch x 9.6 inch ( 24.4 cm x 24.4 cm ) |
| I/O Connectors | 1 x USB 20Gbps port (1 x USB Type-C with DP Alt mode), 2 x USB 10Gbps port (2 x Type-A), 4 x USB 5Gbps ports (4 x Type-A), 1 x USB 2.0 port (1 x Type-A), 1 x DisplayPort, 1 x HDMI port, 1 x Wi-Fi Module, 1 x Realtek 2.5Gb Ethernet port, 5 x Audio jacks, 1 x Optical S/PDIF out port |
| Integrated CPU Graphics | 1 x DisplayPort, 1 x HDMI port, 1 x USB 20Gbps port (USB Type-C) supports DisplayPort video output |
| LAN | 1 x Realtek 2.5Gb Ethernet, TUF LANGuard |
| PCI Slots | Intel CoreTM Ultra Processors(Series 2): 1 x PCIe 5.0 x16 slot; Intel B860 Chipset: 1 x PCIe 4.0 x4 slot |
| Processor Support | Support Intel Core Ultra Processors (Series 2) ,LGA1851; Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
| RAID | ntel Rapid Storage Technology supports SATA RAID 0/1/5/10 |
| RAM Type/Bus/Max | 4 x DIMM slots, max. 256GB, DDR5; Support up to 8800+MT/s (OC), Non-ECC,Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*; Dual Channel Memory Architecture; DIMM Fit; Supports Intel Extreme Memory Profile (XMP) memory module; ASUS Enhanced Memory Profile III(AEMPIII) |
| Socket | LGA1851 |
| Storage Interface | Supports 3 x M.2 slots and 4 x SATA 6Gb/s ports; Intel Core Ultra Processors(Series 2): M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode); Intel B860 Chipset: M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode), 4 x SATA 6Gb/s ports |
| Warranty | 3 years |
| Weight | 1.65kg |
| Wireless & Bluetooth | Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency band, Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate, Bluetooth v5.4 |
