| Audio | Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC |
| Chipset | Intel B860 Chipset |
| Form Factor | Mini-ITX Form Factor 6.7 inch x 6.7 inch ( 17 cm x 17 cm ) |
| I/O Connectors | 1 x Thunderbolt 4 port (1 x USB Type-C), 1 x USB 20Gbps port (1 x USB Type-C), 1 x USB 10Gbps ports (1 x Type-A), 3 x USB 5Gbps ports (3 x Type-A), 2 x USB 2.0 ports (2 x Type-A), 1 x DisplayPort, 1 x HDMI port, 1 x Wi-Fi module, 1 x Intel 2.5Gb Ethernet port, 2 x Audio jacks, 1 x Optical S/PDIF out port, 1 x Clear CMOS button |
| Integrated CPU Graphics | 1 x DisplayPort, 1 x HDMI port, 1 x Intel Thunderbolt 4 supports DisplayPort and Thunderbolt video outputs |
| LAN | 1 x Intel 2.5Gb Ethernet, ASUS LANGuard |
| PCI Slots | Intel Core Ultra Processors (Series 2): 1 x PCIe 5.0 x16 slot |
| Processor Support | Support Intel Core Ultra Processors (Series 2), Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
| RAID | Intel Rapid Storage Technology supports SATA RAID 0/1/5/10. |
| RAM Type/Bus/Max | 2 x DIMM slots, max. 128GB, DDR5; Supports up to 9066+MT/s (OC), Non-ECC Un-buffered ,Clocked Unbuffered DIMM (CUDIMM); Dual channel memory architecture; DIMM Fit; Supports Intel Extreme Memory Profile (XMP) memory module; ASUS Enhanced Memory Profile III (AEMP III) |
| Socket | LGA1851 |
| Storage Interface | Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports; Intel Core Ultra Processors (Series 2): M.2_1 slot (Key M), type 2260/2280 (supports PCIe 5.0 x4 mode); Intel B860 Chipset: M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode); 4 x SATA 6Gb/s ports |
| Warranty | |
| Weight | |
| Wireless & Bluetooth | Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency band, Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate, Bluetooth v5.4 |
