Zalman VF900-Cu Dual Heatpipe Video Card Cooler - Copper

IMG 1 of 1
No Longer Available
Part Number:
59719
(?) Brand:
Zalman Web Site
Manuf No:
VF900-CU
VF900CU
Shipping Weight:
1 KG (Includes product packaging)
Estimate Shipping
Details Reviews Files Images & Video
All stock codes associated to this product
VF900CU, VF900-CU


1. Pure copper heatsink base and fins maximize cooling performance.
2. Use of two high performance heatpipes maximizes heat transfer.
3. Circular heatsink formed by radially aligned ultra-thin(0.2mm) fins minimizes airflow resistance
and maximizes heat dissipation surface area for excellent cooling performance.
4. Fan installed in the heatsink cools not only the VGA chipset and VGA RAM, but all other VGA
components.
5. Does not exert any excessive force on the VGA card due to the products light weight.
6. Improvement in the installation structure provides excellent compatibility and easy installation.
7. Adjustable fan speed controller(FAN MATE 2) enables control of noise and fan speed.
8. Does not generate noise or vibration in Silent Mode.
Specifications

- Dimensions : 96(L) X 96(W) X 30(H)mm
- Weight : 185g
- Base Material : Pure Copper
- Bearing Type : 2 Ball-Bearing
- Speed : 1,350 ~ 2,400rpm 10%
- Noise Level : 18.5 ~ 25.0dB 10%
Nipple Installation Holes for Various VGA Cards


Nipple Installation Holes VGA Card
ATI X1600 Series
ATI X1300 Series
ATI Radeon 9*** Series (except 9550/9600)
ATI Radeon X*** Series
NVIDIA Geforce4 MX Series
NVIDIA Geforce FX 5200
NVIDIA Geforce FX 5500
NVIDIA Geforce FX 5600(FX 5700)
NVIDIA Geforce 6600 Series (except 6600 AGP Series)
NVIDIA Geforce4 Ti 4*** Series
NVIDIA Geforce FX 5700(Ultra) Series
NVIDIA Geforce FX 5800 Series
NVIDIA Geforce 6600 Series (except 6600 AGP Series)
ATI X1600 Series
NVIDIA Geforce 6600 Series (except 6600 AGP Series)
NVIDIA Geforce 7600 Series
NVIDIA Geforce FX 5900 Series
NVIDIA Geforce FX 5950 Series
ATI X1900 Series
ATI X1800 Series
NVIDIA Geforce 7900 Series
NVIDIA Geforce 7800 Series (except 7800GS)
NVIDIA Geforce 7600 Series
NVIDIA Geforce 6800 Series

Incompatible VGA Cards
emTek GeForce 6600 HV6600GE2 SF 128MB
emTek HV GeForce 6600GE WoW Platinum2 128MB



1) Heatsink Assembly (VF900-Cu)
2) Eight RAM Heatsinks
3) Four Nipple
4) Four Fixing Nuts
5) One PVC Washer Plate
6) Four Rubber Rings
7) Four Springs
8) Thermal Grease
9) FAN Controller(FAN MATE 2)
10) Cable for FAN MATE 2
11) Dual-sided Tape(to attach FAN MATE 2)
12) User's Manual - in English and Korean


  Zalman affixes a Computer Noise Prevention System (CNPS) mark to all components used for
noiseless computers.  1. By installing this product on a VGA (Video Graphics Array) card, a PCI slot adjacent to the PCIe (or AGP) slot will become unusable.
   2. The product cannot be installed on Matrox VGA cards, NVIDIA PCX 5***, NVIDIA Geforce 7800GS/6600 AGP Series and ATI Radeon 9550/9600 Series.
   3. The use of an exhaust fan positioned on the rear side of the case is recommended for enhancementof product performance.












No additional files, specification sheets, guides or documentation found for product.

Warranty: 12-month Manufacturer

Full manufacturers warranty details are available at the manufacturers (Zalman) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.

Visitor Reviews

Average Visitor Review:
Number of Reviews Found: ( / 5 )

Reviewd By: James
Visitors Age: 30
Visitors Rating:

Grade A Cooling (as usual from Zalman)

NB: Overclocking voids warranty. My XFX 7900GT went from almost 70 degrees C to 46 (max) with this cooler, despite overclocking. Highly recommend this product, even if you arent overclocking to extend video card life. Default GPU Frequency: 470Mhz Highest stable OC with stock cooler: 555Mhz Highest stable OC with Zalman cooler: 563Mhz Card is completely stable at this level, and should last much longer at the lower temperature. One thing to look out for, dont overtighten the screws holding the heatsink on, I could easily see someone cracking their GPU. Read the instructions carefully, and be prepared to wipe stock thermal tape off of your GPU with methylated spirits and cotton buds.

Reviewd By: NT
Visitors Age: 16
Visitors Rating:

Zalman VF-900

After an easy installation, I overclocked my Video Card for the first time from stock 500s to 515 and the temperature still dropped 10+ degrees at idle.
