Processor
|
- Socket AM2+/AM2 for AMD Phenom* / AMD Athlon 64 FX / AMD Athlon 64 X2 / AMD Athlon 64 / AMD Sempron processors (*Note: 125W TDP processor models are not supported.)
|
|
Chipset
|
- NVIDIA MCP78V (Built in NVIDIA GeForce 8100 Graphics, DirectX 10 Ready, supports Hybrid SLI technology, built-in NVIDIA PureVideovideo decoder)
- Marvell 10/100/1000 Mbps Ethernet Controller
- Super I/O: Winbond W83627EHG chip
- Realtek ALC 883 HD Audio Codec
- 8M bit flash ROM
|
|
HyperTransport
|
- HyperTransport 3.0/1.0, 5200/2000 MT/s (CPU dependent)
|
|
Memory
|
- Dual Channel DDR2 1066/800/667/533 support (DDR2 1066 support is dependent on CPU)
- Max capacity:4 GB
- DIMM slots: 2
|
|
Internal I/O
Connectors
|
- 1 x 24-pin ATX power connector
- 1 x 4-pin ATX 12V power connector
- 1 x floppy drive connector
- 1 x IDE connector (for 2 PATA devices)
- 4x SATA 3Gb/s connectors (Support RAID 0,1,0+1, 5)
- 1 x CPU fan connector
- 1 x system fan connector
- 1 x front panel header
- 1 x front audio header
- 2 x USB 2.0 headers for additional4 USB 2.0 ports (by cables)
- 1 x buzzer header
- 1 x IR header
- 1 x SPDIF In/Out header
- 1 x serial port header
|
|
Expansion Slots
|
- 1 x PCI-E x16 slot
- 2 x PCI slots
|
|
Rear Panel I/O
|
- 1 x PS/2 Keyboard port
- 1 x DVI port
- 1 x HDMI port
- 1 x VGA port
- 4 x USB 2.0 ports
- 1 x RJ45 GigaLAN port
- 3 x Audio ports (Line In / Line Out / MIC In), optional (Rear Speaker Out / Center-Subwoofer Speaker Out / Side Speaker Out)
|
|
Form Factor
|
- Micro-ATX
- 190x 245mm
|
|
H/W Monitoring
|
- Winbond W83627EHG
- System health status auto-detect and reported by BIOS
|
|
BIOS
|
- 8 Mbit flash ROM, AMI BIOS
|
|
Bundle Software
|
- Driver and Utility CD/DVD
|
|
Remark
|
- Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
- This product does not support Win9X/ME.
- Solid Capacitors on PWM Area.
- This board does not support the 125W TDP Phenom Quad Core/ Athlon X2 Processors.
|
