| Standards |
IEEE 802.11b/g and 802.11n draft 3.0 Wireless Standard IEEE 802.3, 802.3u 10/100M Ethernet standard |
| Interface |
USB 1.1/2.0 Interface Compliant LED indicator |
| Wireless Features |
Comply with IEEE 802.11b/g and 802.11n draft 3.0 Wireless Standard Superior wireless coverage and high performance, up to 300Mbps for wireless data rates Support 64/128-Bit WEP encryption, WPS, WPA-PSK, WPA2-PSK, WPS and 802.1x Support Software AP |
| Modulation Types Supported |
OFDM: BPSK, QPSK, 16QAM, 64QAM, Proprietary MIMO modulation (11g) DSSS: DBPSK, DQPSK, CCK(11b) |
| Data Rates Supported |
IEEE 802.11b: 1, 2, 5.5 and 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n(draft 3.0): up to 150 Mbps |
| QoS and Value-Added MAC Features |
IEEE 802.11e QoS Wi-Fi Alliance WMM (Wi-Fi Multimedia Enhancement) support Hardware-Based Priority Queues |
| BUS Type |
USB 2.0/1.1 Type A |
| Physical Interfaces |
Link, ACT LED 1 internal antenna |
| Software |
Windows 2000/XP/ Vista |
| Security |
Support 64/128-Bit WEP encryption, WPS, WPA-PSK, WPA2-PSK, WPS and 802.1x |
| Ethernet Features |
Compliant with IEEE 802.3 and 802.3u 10/100 Mbps All Ethernet ports support auto-crossover (MDI/MDI-X) |
| Enviroment |
Operating Temperature: 0C~40C Operating Humidity: 10%~90% (Non-Condensing) |
| Certifications |
FCC, CE |
