GCS1764 | IOGEAR 4 Port DVI KVMP Switch USB Console - USB Keyboard

The IOGEAR DVI KVMP Switch GCS1764 charts a revolutionary new direction in KVM switch functionality by providing an interface for today's digital monitors while integrating a 4-port USB KVM switch with USB peripheral sharing capabilities. As a KVM switch, the unit allows the user to access four computers from a single USB keyboard, USB mouse, and monitor, and also share among the computers peripherals such as external hard drives, printers and scanners. The GCS1764's independent (asynchronous) switching feature allows the KVM focus to be on one computer while the USB peripheral focus is on another. The user can switch from one computer to another without interrupting print jobs, downloads or other functions being handled by connected peripherals. This eliminates the need to purchase a separate USB hub as well as the need to purchase separate stand-alone peripheral sharers - such as printer servers, modem splitters, etc. The GCS1764 further improves on previous designs with DVI (Digital Video Interface) connectors, and the transfer of keyboard and mouse data to the computers via a fast, reliable USB connection. DVI supports both digital input (flat panel displays, data projectors, plasma displays, digital TVs and set-top boxes) and analog video input (traditional monitors and TVs).



Requirements:

Console:

• A DVI monitor
• A USB style mouse
• A USB style keyboard
• Microphone and speakers (optional)

Computer:

• A DVI port
• Type A USB port
• Audio ports (optional)
• Windows 98, 98SE, ME, 2000, XP
• Mac OS 8.6 or greater
• Sun Solaris
• Linux, UNIX and other USB supported systems*

*Additional drivers and support may be needed

Cables:

• Only IOGEAR Custom cable sets specifically designed to work with this switch may be used to link to the computers. Four cable sets are provided with this package.

Audio

• Requires 2-piece powered speaker system



Package Contents:

• 1 x GCS1764 KVMP switch
• 4 x6' custom cables
• 1 x Firmware upgrade cable
• 1 x Power Adapter
• 1 x User Manual
• 1 x Quick Start Guide

Specifications:

Function	GCS1764
Housing
Case	Metal
CPU Connectors
Monitor	4 x DVI-I ports (female)
Microphone	4 x Microphone jack
Audio	4 x Stereo earphone jack
Keyboard & Mouse	4 x USB Type B sockets
Console Connectors
Mouse	1 x USB Type A socket
Keyboard	1 x USB Type A socket
Monitor	1 x DVI-I (female) port
Microphone	1 x Microphone jack
Audio	1 x Stereo earphone jack
LEDs
Selected	4 x Orange
On Line	4 x Orange
USB Peripherals	4 x Green
Port Selection	Front Panel Switches; Hotkey
Video Resolution	Up to 1920 x 1200; DDC2B
Scan Interval	1-99 secs (default: 5 secs)
Emulation
Keyboard	USB
Mouse	USB
Computer Connections
Direct	4
Operating Temperature	0 - 50 C
Storage Temperature	-20 - 60 C
Humidity	0-80% RH
Cable Length	USB DVI (D) cables 4 @ 3.9 ft (1.8m)
Power Adaptor Part #
for North America	# 0AD8-0005-261G
for Continental Europe	# 0AD6-1005-261G
for UK	# 0AD4-3005-261G
Peripheral Sharing	2 x USB 1.1

Dimensions	GCS1764
Unit Dimensions
Width	2.93 in. (7.44 cm.)
Height	1.65 in. (4.19 cm.)
Depth	10.25 in. (26.04 cm.)
Unit Package Dimensions
Width	13 in. (33.02 )
Height	8.375 in. (21.27 cm)
Depth	3.875 in. (9.855 cm)
Master Carton
Width	9 in (22.86 cm)
Height	13in (33.02 cm)
Depth	13.5in ( 34.29 cm)
Master Carton Qty.	3
Weight
Master Carton Wt.	21.6 lbs (9.797 kg)
Unit Pack Wt.	7 lbs ( 3.175 kg)
Unit Wt.	2.2 Lbs. (0.99 kg.)
