Introducing the four port MiniView Micro USB KVM switch from IOGEAR the simplest way to simultaneously run and share audio among four computers with a single USB keyboard, monitor and USB mouse.
This self-powered KVM switch features the unique USB sniffing technology for USB mouse and keyboard emulation to ensure smooth operation, as well as support for Plug-n-Play monitors and most wheel mice. Our patented VSE Video Signal Enhancement technology provides rich, 32-bit color at resolutions up to 2048 x 1536.
Another big plus is the MiniView capability to provide audio support, it allows you to share your multimedia speakers among the connected computers.
This switch also offers multi-platform support; it is compatible with Windows and Mac computers as well as Sun Solaris workstations. IOGEAR delivered a huge breakthrough in KVM operation to Mac and Sun users by enabling functionality for the special keys on these systems. When using a PC keyboard, a special set of hot keys are designed to emulate the special keys on Mac and Sun machines.
The Miniview Micro USB KVM has two 6' long KVM cables molded-in, and two detachable 6' long KVM cables, all you need to do is to plugthem into your computers and you'e got a complete KVM solution from IOGEAR.
Features:
- Control up to 4 computers from a single video, USB keyboard and USB mouse
- Expandable & extendable: two 6' molded-in cables, and two detachable 6' cables
- Full support for Mac, PC & Sun systems
- Supports Mac & Sun special keys
- Connect speakers to enjoy audio from any connected system
- Select system by tapping Hot Keys on keyboard
- Instant, error-free boot-up
- Plug-n-Play
- 2048 x 1536 video resolution
- Requires no software
- Requires no external power
Requirements:
- Computers with a USB connection and VGA connection
- Windows98SE, and above
- Mac OS 8.6 or greater
- Sun Solaris work station
- Linux, UNIX and other USB
- Audio: Requires powered speakers systems
Package Contents:
- 1 MiniView Micro USB KVM Switch
- 2 detachable KVM cables (6 feet)
- 1 User Manual
- 1 Quick Start Guide
- 1 Warranty Registration Card
Specifications:
| Function |
GCS634U |
| CPU Connectors |
| Monitor |
2 x HDB15 Male |
| Audio |
2 x stereo speaker |
| Keyboard & Mouse |
2 x USB Type A |
| Keyboard, Mouse, and Monitor |
2 x DB15 for detached cables |
| Console Connectors |
| Mouse |
1 x USB Type A |
| Keyboard |
1 x USB Type A |
| Monitor |
1 x HDB15 Female |
| Audio |
1 x stereo speaker |
| Cable Length |
6 ft. (1.83 m.) |
| Dimensions |
GCS634U |
| Unit Dimensions |
| Width |
6.45 in ( 16.4 cm) |
| Height |
1.25 in ( 3.175 cm) |
| Length |
6.45 in ( 16.4 cm) |
| Unit Package Dimensions |
| Width |
10.5 in. ( 26.67 cm) |
| Height |
8.875 in. ( 22.5 cn) |
| Depth |
3.875 in. ( 9.84 cm) |
| Master Carton |
| Width |
11.375 in. ( 28.9 cm) |
| Height |
9.75 in. ( 25 cm) |
| Depth |
12.5 in.( 31.75 cm ) |
| Master Carton Qty. |
3 |
| Weight |
| Master Carton Wt. |
11.25 lbs. ( 5.1 kg) |
| Unit Pack Wt. |
3.4 lbs. ( 1.54 kg) |
| Unit Wt. w/accessories |
2.5 lb ( 1.13 kg) |
| Unit Wt. |
1.5 lb ( 0.68 kg) |
