Hardware
- CPU Clock Rate: 1.2GHz
- Memory: 256MB
- Internal HDD1: 3.5" SATA(II) X2
- External HDD Interface: USB 2.0 port X3
- Size: 160mm X 218mm X 88mm
- Weight: 0.98kg
- LAN: Gigabit X1
- Fan: X1(70mmX70mm)
- Noise Level:2 24dB(A)
- Power Recovery
- AC Input Power Voltage: 100V to 240V
- Power Frequency: 50Hz to 60Hz, Single Phase
- Max Capacity (Internal HDD): Up to 4TB8 (See All Supported HDD)
- Max Supported IP Camera: 57 (See All Supported IP Cameras)
- Operating Temperature: 5C to 35C (40F to 95F)
- Storage Temperature: -10C to 70C (15F to 155F)
- Relative Humidity: 5% to 95%RH
- Maximum Operating Altitude: 10,000 feet
Power Consumption3
- 25W(Access);
10W(Hibernation)
Certification
- FCC Class B, CE Class B, BSMI Class B
Networking Protocols
- CIFS
- AFP (3.1)
- FTP
- NFS
- Telnet/SSH
Windows ADS Domain Integration
- ADS Support
- Domain users login via Samba/AFP/FTP
- Synology Data Replicator 3 for Domain Users
Security
- "FTP over SSL (explicit)" or "FTP over TLS (explicit)"
- FTP Auto-Block
- Encrypted Network Backup
- Encrypted rsync
- HTTPS Connection
File System
- EXT3
- FAT (External Disk Only)
- NTFS (External Disk Read Only)
File Sharing
- Max User Accounts: 1,024
- Max Groups: 128
- Max Shared Folder: 256
- Max Concurrent Connections(SAMBA, FTP, AFP): 64
Utilities
- Synology Assistant
- Synology Data Replicator 3
- Synology Download Redirector
- Add printer wizard
|
Applications
- Surveillance Station 2
- Photo Station 3
- File Station 2
- Audio Station
- Web Station
- PHP/MySQL
- Download Station 2
- iTunes Server
Packages
- Mail Station
- SqueezeCenter
UPnP Multimedia Service Support
- Sony PS3, Microsoft Xbox360 (See All Supported DMA)
- Audio Format: AAC, FLAC, M4A, MP3, Ogg Vorbis, WAV, WMA, WMA VBR, WMA PRO, WMA Lossless
- Video Format: ASF, AVI, DAT, DivX, MP4, MPEG1, MPEG2, MPEG4, VOB, WMV, XviD
- Image Format: BMP, JPG (jpe, jpeg), GIF, ICO, PNG, PSD, TIF (tiff), UFO
- Playlist Format: WPL, M3U
iTunes Server Support
- Audio Format: MP3, M4A, M4P, WAV4, AIF4
- Playlist Format: M3U, WPL
Audio Station Support
- USB Mode: (Audio) AAC, FLAC, M4A, MP3, Ogg Vorbis, WMA, WMA VBR (Playlist) M3U, WPL (Internet Radio) SHOUTcast, Radioio
- Streaming Mode: (Audio) MP3 (Playlist) M3U, WPL
Photo Station 3 Support
- Video Format: ASF, AVI, MPEG1, MPEG4, WMV, XviD, DivX, FLV, DAT5, MP45, MPEG25, RM5, RMVB5, VOB5
- Image Format: BMP, JPG (jpe, jpeg), GIF
Management
- AJAX-based Management UI
- Sub-folder Privileges Setting
- User Home
- Applications privileges Setting
- BitTorrent Port Range Setup
- BitTorrent DHT Support
- CIFS Recycle Bin
- Download Station Bandwidth control
- Download Station Port Range Setup
- Editable HTTP Error Page
- Email Alert Message
- Email Notification for New User
- Package Management
- External HDD Hibernation (USB)
- Scheduled Power On/Off
- Firmware Upgrade
- FTP passive port range
- Hide-able Shared Folder
- Internal HDD Hibernation
- Movable Shared Folder
- Removable Default Shared Folder
- System Temperature
- Ez-Internet
- PPPoE
- UPS Management (Over USB 2.0)
- User Quota
- Web-based Download Station 2
|
RAID Management
- Volume Type: Basic, JBOD, RAID 0, RAID 1
- Upgrade from Basic to RAID 1
- Expand RAID 1 with Larger Hard Drives
Backup Solutions
- Network Backup
- Local Backup
- Desktop Backup (using Synology Data Replicator 3)
- 3rd-Party Backup Support
Supported Clients
- Windows 2000 onward
- Mac OS X 10.3 onward
- Linux
Printer Support6
- Max Printer #: 2
- Supported Protocols: LPR, CIFS, AppleTalk
Languages
- English, German, French, Italian, Spanish, Danish, Norwegian, Swedish, Dutch, Russian, Korean, Polish, Traditional Chinese, Simplified Chinese, Portuguese (Brazil), Portuguese (European), Turkish, and Hungarian
Environment
Package Content
- DS209 Main Unit
- Installation CD
- Welcome Note
- Assembling Kit
- AC Power Adapter
- AC Power Cord
- 2M RJ-45 LAN Cable
- SATA Hard Drive Power Cable X2
- SATA Hard Drive Data Cable X2
___
1.Hard drive not included.
2.FAN only. Measured at 2300~6200RPM, varied among models. More details about dB(A) value, check
https://www.quietnoise.com/facts.htm
3.Measured with 2 Seagate 750GB ST3750640NS hard drives. The figures could vary on different environments.
4.The music can be streamed, but the metadata (ex:title, album) may not be indexed on the iTunes.
5.User can click and download the file, but not play it in Photo Station as compressed Flash video.
6.For Mac users, DS209 supports PostScript USB printers only.
7.1 free license to install 1 IP camera. Additional licenses can be purchased to expand the license quota.
8.The actual capacity will differ according to volume types.
|
