The CL1016 LCD KVM Switch series are control units that allow access to multiple computers from a single keyboard, video, and mouse (KVM), console. A single CL1016 can control up to 16 computers. As many as 15 additional KVM switches can be daisy-chained to the CL1016, so that up to 256 computers can all be controlled from a single KVM console. The CL1016 offers a space-saving, streamlined approach to KVM switch technology by integrating a keyboard, 17" LCD monitor, and touchpad in a 1U rack-mountable sliding housing.
* KVM console with 17" LCD monitor in a sliding housing with top and bottom clearance for smooth operation in a 1U high system rack
* LCD module rotates up to 115 degrees for a more comfortable viewing angle
* Standard rack mount kit included - optional Easy Rack Mounting (single person installation) rack mount kit available (requires separate purchase)
* Daisy-chain up to 15 additional units - control up to 256 computers
* No software required - convenient computer selection via hotkeys and mouse driven intuitive on screen display (OSD) menus
* Auto Scan feature for monitoring user-selected computers
* Broadcast support - commands from the keyboard can be broadcast to all available computers on the installation
* Hot pluggable - add or remove computers without having to power down the switch
* Two level password security - only authorized users view and control the computers; up to four users plus an administrator with separate profiles for each
* Video settings of attached computers are automatically adjusted for optimal output to the LCD monitor
* Upgradable firmware
* Keyboard Language support: English(US); English(UK); German; German(Swiss); French; Spanish; Traditional Chinese; Japanese; Korean; Swedish; Italian; Russian; Hungarian
* Multiplatform support: Windows 2000/XP/Vista and FreeBSD
Rack Mounting Kit Depth
Long (Optional) 68cm - 110cm
Short (Standard) 42cm - 82cm
Easy Installation Rack Mounting Kit Depth
Long (Optional) 68cm - 110cm
Short (Optional) 52cm - 70cm
Package Contents
1x CL1016 with Standard Rack Mount Kit
2x Custom KVM Cable Sets
1x Power Cord
1x Firmware Upgrade Cable
1x User Manual
1x Quick Start Guide
