Corsair 750W HX-750 - ATX 12V v2.3, EPS 12V v2.91, 140mm Fan, Modular Cables, 80 PLUS Silver Certified
  • 12xSATA, 4xPCI-E 6+2-Pin

IMG 1 of 1
No Longer Available
Part Number:
114699
(?) Brand:
Corsair Web Site
Manuf No:
750HXAU
Shipping Weight:
3 KG (Includes product packaging)
Estimate Shipping
Date Added:
15/5/2009
Details Files Images & Video
All stock codes associated to this product
750HXAU, CMPSU750HX, CMPSU-750HX
Overview

Corsair Professional Series power supply units have been designed by Corsair and engineered to the highest quality standards to meet the demands of enthusiasts that expect the very best. The Corsair Professional Series HX750W PSU utilizes advanced DC-to-DC circuitry and meets 80 PLUS SILVER certification standards for up to 90% energy-efficiency*, reducing wasted energy and lowering the amount of excess heat generated. Corsair Professional Series power supplies are built using industrial grade electrical components, ensuring the stable, clean and reliable voltages that are essential for high-end gaming PCs and workstations.

Corsair Professional Series power supplies boast an innovative cabling configuration that uses low-profile, flat modular cables that reduce air friction to help maximize airflow through the computer chassis. The modular design also simplifies installation as it allows unprecedented flexibility in using only those cables which are needed.
* Tested at room temperature, using a 50% load and 230V AC input.

Features

  • Guaranteed to sustain its full rated wattage at an ambient temperature of 50C
  • Up to 90% energy-efficiency under real-world load conditions*
  • Single +12V rail design providing up to 62A
  • Multi-GPU ready
  • 105C solid state capacitors
  • Active Power Factor Correction (PFC) with PF value of 0.99
  • Supports ATX12V 2.3 and EPS12V 2.91 standards. Backwards compatible with ATX12V 2.01
  • Auto switching circuitry for universal AC input from 90-264V
  • Over Current/Voltage/Power Protection, Under Voltage Protection and Short Circuit Protection provide complete component safety
  • Dimensions: 150mm(W) x 86mm(H) x 180mm(L)
  • MTBF: 100,000 hours
  • Safety Approvals: UL, CUL, CE, CB, FCC Class B, TV, CCC, C-tick

Specifications

AC INPUT 100-240V ~ 12A 50/60Hz
DC OUTPUT +3.3V +5V +12V -12V +5Vsb
MAX CURRENT 25A 25A 62A 0.8A 3A
MAX COMBINED WATTAGE 150W 744W 9.6W 15W
  TOTAL POWER: 750W

Connectors

Connectors Included
#

ATX 24 pin & 20 pin compatible 		x1

EPS/ATX12V 8-4 pin 		x1

PCI-E 6+2 pin 		x4

SATA 		x12

4 pin Peripheral 		x8

Floppy 		x2

/images/extra/11/4/p114699-i9.jpg

/images/extra/11/4/p114699-i10.jpg

No additional files, specification sheets, guides or documentation found for product.

Warranty: 7-year Manufact.

Full manufacturers warranty details are available at the manufacturers (Corsair) web site.
