All stock codes associated to this product
, CS1784, CS-1784
The CS1784 DVI KVMP Switch charts a revolutionary new direction in KVM switch functionality by combining a 4-port KVM switch with a 2-port USB 2.0 hub at the same time as providing an interface for a DVI monitor and audio support.
* One USB console controls four computers and two additional USB devices
* 2-port USB 2.0 hub built in
* USB 2.0 compliant
* Full bass response provides a rich experience for 2.1 channel surround sound systems
* Console audio ports on front panel for easy access ideal for IP phone users
* Independent switching of KVM, USB, and Audio focus
* DVI digital and analog monitor support fully compliant with the DVI specifications; also HDCP compliant
* Superior video quality - 3840 x 2400 (DVI Single Link)*; 2048 x 1536; DDC2B (DVI-A)
* Supports widescreen resolutions
* Computer selection via front panel pushbuttons and hotkeys
* Console mouse port emulation / bypass feature supports full mouse driver and multifunction mice
* Video DynaSync - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
* HDCP compliant
* Complete keyboard emulation for error-free booting
* Sun/Mac keyboard support and emulation**
* Auto Scan Mode for monitoring all computers
* Firmware upgradeable
* OS Support:Windows 2000, Windows XP/Vista, LINUX, Mac, Sun and FreeBSD
*
*2560x1600@60Hz (DVI Dual Link);3840x2400@13Hz (DVI Single Link) only supports specific monitor resolution
** 1. PC keyboard combinations emulate Sun/Mac keyboards
* 2. Sun/Mac keyboards only work with their own computers
Package Contents:
* 1x USB 2.0 DVI KVMP Switch
* 4x Custom KVM Cable Sets (DVI-D)
* 1x USB-to-PS/2 Converter
* 1x Firmware Upgrade Cable
* 1x Power Adapter
* 1x User Manual
* 1x Quick Start Guide
