All stock codes associated to this product
CN8000ATU, CN8000-AT-U, CN8000, CN-8000
The CN8000 is a control unit that provides "over-IP" capability to KVM switches that do not have built in over-IP functionality. It allows operators to monitor and access their computers from remote locations using a browser-based Windows Client or Java Applet, or with AP Windows and Java application programs.
The CN8000 provides a dedicated RS-232 port for modem access, as well as a USB 2.0 port for virtual media capability. With its advanced features, the CN8000 is the fastest, most reliable, most cost effective way to remotely access and manage widely distributed multiple computer installations.
* Provides over-IP capability to KVM switches that do not have built in over-IP functionality
* Virtual media via USB 2.0 data transmission NEW!
* Enhanced fps (frames per second) throughput for crisp responsive video display NEW!
* Ultra-Sync - with USB mice local mouse movement becomes the remote mouse movement NEW!
* Superior video resolution: up to 1600 x 1200 @ 60Hz; vibrant 24-bit color depth for rich remote session display NEW!
* PPP mode (modem) dial up support for out-of-band, and low bandwidth operation NEW!
* Full-screen or sizable remote desktop window - in full-screen mode the remote desktop display scales to user's monitor display size NEW!
* PON (Power Over the NET™) support via Java
* Up to 64 user accounts - Up to 32 concurrent user logins for single-bus sharing
* Message board feature allows logged in users to communicate with each other, and allows a user to take exclusive control of the KVM functions
* External authentication support: RADIUS; LDAP; LDAPS; MS Active Directory
* Web-based Windows and Java implementations allow the server to be controlled from any browser
* Windows GUI and Java client software for non-browser access - Java works with practically all operating systems
* Supports TCP/IP, HTTP, HTTPS, UDP, DHCP, SSL, ARP, DNS, ICMP, CHAP, PPP, 10Base-T, 100Base-T
* Bandwidth optimization via grayscale and video quality setting
* On-screen keyboard
* Export/import user account and configuration settings
* Advanced security features include password protection and advanced encryption technologies
* Secure 128-bit SSL encryption
* Enable/disable browser operation
* Event logging
* Remote firmware upgrading
* Multiplatform support: Windows 2000/XP/Vista, Mac, Linux, Unix, Sun and FreeBSD
Package Contents:
* 1x KVM on the NET™ Switch
* 2x Custom KVM Cable Sets
* 1x Custom Console Cable Set
* 1x USB 2.0 Virtual Media Cable
* 1x Power Adapter
* 1x Mounting Kit
* 1x Software CD
* 1x User Manual
* 1x Quick Start Guide
