Intel Core i7-950 Processor (8M Cache, 3.06 GHz, 4.80 GT/s Intel QPI)
| Essentials |
| Status |
Launched |
| Launch Date |
Q2'09 |
| Processor Number |
i7-950 |
| # of Cores |
4 |
| # of Threads |
8 |
| Processor Base Frequency |
3.06 GHz |
| Max Turbo Frequency |
3.33 GHz |
| Intel Smart Cache |
8 MB |
| Bus/Core Ratio |
23 |
| Intel QPI Speed |
4.8 GT/s |
| # of QPI Links |
1 |
| Instruction Set |
64-bit |
| Instruction Set Extensions |
SSE4.2 |
| Embedded |
No |
| Supplemental SKU |
No |
| Processing Die Lithography |
45 nm |
| Max TDP |
130 W |
| VID Voltage Range |
0.800V-1.375V |
| 1ku Bulk Budgetary Price |
$562.00 |
| Memory Specifications |
Max Memory Size
(dependent on memory type) |
24 GB |
| Memory Types |
DDR3-800/1066 |
| # of Memory Channels |
3 |
| Max Memory Bandwidth |
25.6 GB/s |
| Physical Address Extensions |
36-bit |
| ECC Memory Supported |
No |
| Package Specifications |
| Max CPU Configuration |
1 |
| Package Size |
42.5mm x 45.0mm |
| Processing Die Lithography |
45 nm |
| Processing Die Size |
263 mm2 |
| # of Processing Die Transistors |
731 million |
| Sockets Supported |
FCLGA1366 |
| Halogen Free Options Available |
Yes |
| Advanced Technologies |
| Intel Turbo Boost Technology |
Yes |
| Intel Hyper-Threading Technology |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Trusted Execution Technology |
No |
| AES New Instructions |
No |
| Intel 64 |
Yes |
| Idle States |
Yes |
| Enhanced Intel Speedstep Technology |
Yes |
| Intel Demand Based Switching |
No |
| Thermal Monitoring Technologies |
No |
| Execute Disable Bit |
Yes |
| Block Diagrams |
 |
