Uncompromising HD Digital Audio and Video with World's Only True Blu-ray Audio Bitstreaming
The Xonar HDAV1.3 features Protected Audio Playback Systems (PAPS) and full Advanced Access Content System (AACS) certification. Without both certifications, typical PCs must down-sample Blu-ray audio into DVD quality (48K/16bit). Utilizing ArcSoft's Total Media Theater, the ASUS Xonar HDAV1.3 is capable of decoding Blu-ray movies and takes full advantage of lossless digital audio formats such as Dolby TrueHD and DTS-HD Master Audio for professional, high-fidelity sound at 24bit, 96C192Khz. The PCI-based Xonar HDAV1.3 Slim is also designed from the ground up, and is built for next generation HTPCs. Equipped with the proprietary AV200 audio processor and certified HDMI1.3a connect, it is capable of delivering the highest quality 7.1 channel 192K linear pulse code modulation (LPCM) audio and high definition video through the HDMI port.
Perfectly Designed for Next-ge HTPCs
The Xonar HDAV1.3 Slim is equipped with an essential digital HDMI1.3 interface, which bitstreams next-generation Blu-ray quality audio formats such as Dolby TrueHD, DTS HD Master and Dolby Digital Plus via the ArcSoft TotalMedia Theatre application to the user's AV receiver. This powerful playback ability, combined with a low-profile design and bundled low-profile bracket, makes the HDAV1.3 Slim perfect for next-generation HTPCs right out of the box.
True Cinematic Video Enjoyment
The Xonar HDAV1.3 Slim offers bit-to-bit exact lossless audio output, eliminating the need for Blu-ray audio downsampling that would result in poor quality audio output. It also transmits both video and audio through a single HDMI cable, helping to eliminate cable clutter. Furthermore, most motion picture cameras used for Hollywood movies capture video at 24 frames per second. Content recorded on Blu-ray media are also based on 24p. With the Xonar HDAV1.3 Slim's support for 24p video via HDMI, users with a 1080/24p compatible LCD monitor and a 1080/24p player will be able to bring cinema-like visuals out of their HTPCs and fully experience digital videos the way they were produced in Hollywood studios.
Key Features at a Glance The Xonar HDAV1.3 Slim:
- Supports DTS-HD, Dolby TrueHD and Dolby Digital Plus, up to 192Khz, 24bit, and 7.1 channel LPCM audio formats
- Delivers bit-to-bit exact lossless audio output without Blu-ray audio downsampling
- Supports 24p frame rate video playback
- Transmits both video and audio through a single HDMI cable
Specifications
| Items |
Description |
| Processor and Interface |
| Audio processor |
ASUS AV200 (Max. 192KHz/24bit) |
| Bus Compatibility |
PCI 2.1 specification compatible |
| HDMI |
HDMI 1.3a, HDCP1.2, DVI 1.0 |
| Video Specifications |
| Video Resolution |
- DTV Resolution: up to 1080p
- PC Resolution: up to UXGA |
| Color Depth and Range |
- Up to 48-bit/per pixel color depths (RGB or YCbCr)
- Broader xvYCC color space standard |
| Audio Sample Rate and Resolution |
| HDMI1.3 Playback Formats |
- 7.1 channel LPCM 192KHz/24bit
- Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio bitstreaming |
| S/PDIF Digital Input and Output |
192KHz/24bit |
| I/O Ports |
| HDMI Ports |
- HDMI-Out Type A x 1
- HDMI-In Type A x 1 |
| Digital S/PDIF |
Coaxial/TOSLINK combo |
| Front Panel Header |
HD Audio and AC97 |
| AUX in |
Aux-in-4-pin Header |
| Driver Features |
- Complete Dolby and DTS technologies
- DS3D GX2.5
- VocalFX
- ASIO2.0 |
| Software Utility |
- ArcSoft Total Media Theatre
- 7.1-ch Blu-ray movie player |
|
