IMG 1 of 5
No Longer Available

Part Number:
118622
(?) Brand:
Manuf No:
WD2002FYPS
Shipping Weight:
0.6 KG (Includes product packaging)
Estimate Shipping
All stock codes associated to this product
, AMIHD2000WS4, AMI-HD2000WS4
2 TB, 1.2 million hours MTBF, 64 MB Cache, IntelliPower

Faster and greener
With improved performance, lower power consumption and higher capacity, this new generation of WD RE-GP drives provides even lower cost-of-ownership to organizations with large data centers.

Features

Faster - 64 MB cache, dual processors, and increased areal density yield twice the processing power results in up to 25% performance improvement over the previous generation.

Greener - Improvements in our power-conserving technologies - IntelliSeek, IntelliPark, and IntelliPower - deliver improved power consumption over our previous generation of WD RE-GP drive.

Improved rotary vibration tolerance - Advanced mechanical optimizations along with system characterization and validation provide the highest performance under vibration conditions of any WD product.

Lower total cost of ownership - Large data-hungry organizations such as financial institutions and web service providers may realize up to $10 savings per drive per year in electricity costs (U.S.). A large data center with 10,000 drives could realize up to $100,000 in saving per year.

24x7 reliability - With 1.2 million hours MTBF, these drives have the highest available reliability rating on a high-capacity drive.

IntelliPower - A fine-tuned balance of spin speed, transfer rate, and caching algorithms designed to deliver both significant power savings and solid performance. Additionally, GreenPower drives consume less current during start up allowing more drives to spin up simultaneously resulting in faster system readiness.

IntelliSeek - Calculates optimum seek speeds to lower unnecessary power consumption, noise, and vibration.

IntelliPark - Delivers lower power consumption by automatically unloading recording heads during idle to reduce aerodynamic drag, and by disengaging read/write channel electronics.

Active Power Management - WD drives with GreenPower Technology monitor work load and automatically invoke idle mode whenever possible to further reduce unnecessary power consumption. Drive recovery time from idle mode is less than one second, providing seamless power management between the drive and the host controller.

Perpendicular Magnetic Recording (PMR) - Employs PMR technology to achieve even greater areal density.
StableTrac - Secures the motor shaft at both ends to reduce system-induced vibration and stabilize platters for accurate tracking, during read and write operations.
RAID-specific time-limited error recovery (TLER) - Pioneered by WD, this feature prevents drive fallout caused by the extended hard drive error-recovery processes common to desktop drives.

Rotary Acceleration Feed Forward (RAFF) - Optimizes operation and performance when the drives are used in vibration-prone multi-drive systems such as rack mounted servers.

Ideal For - Large data centers, web service providers, commercial grade surveillance systems and organizations requiring huge amounts of storage with limited budget and power allotment.


Specifications
Performance Specifications
Rotational Speed IntelliPower *
Buffer Size 64 MB
Load/unload Cycles 300,000 minimum
Transfer Rates
Buffer To Host (Serial ATA) 3 Gb/s (Max)
Physical Specifications
Formatted Capacity 2,000,398 MB
Capacity 2 TB
Interface SATA 3 Gb/s
User Sectors Per Drive 3,907,029,168
Physical Dimensions
English
Height 1.028 Inches
Length 5.787 Inches
Width 4.00 Inches
Weight 1.61 Pounds
Metric
Height 26.1 mm
Length 147 mm
Width 101.6 mm
Weight 0.73 kg
Environmental Specifications
Shock
Operating Shock (Read) 30G, 2 ms
Non-operating Shock 300G, 2 ms
Acoustics
Idle Mode 25 dBA (average)
Seek Mode 0 29 dBA (average)
Seek Mode 3 26 dBA (average)
Vibration
Operating
Linear 20-300 Hz, .75G (0 to peak)
Random 0.004 g/Hz (10 to 300 Hz)
Non-operating
Low Frequency 0.05 g/Hz (10 to 300 Hz)
High Frequency 20-500 Hz, 4.0G (0 to peak)
Electrical Specifications
Current Requirements
12 VDC
Read/Write 340 mA
Idle 260 mA
Standby 5 mA
Sleep 5 mA
5 VDC
Read/Write 675 mA
Idle 140 mA
Standby 140 mA
Sleep 140 mA
Power Dissipation
Read/Write 6.8 Watts
Idle 3.7 Watts
Standby 0.80 Watts
Sleep 0.80 Watts
As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, megabit per second (Mb/s) = one million bits per second, and gigabit per second (Gb/s) = one billion bits per second.

Specification Sheets / Installation guides / Associated files

Warranty: 5 Years

Full manufacturers warranty details are available at the manufacturers (Western Digital) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
