Hardware
- CPU: 1.06GHz, 64bit@DDR533, with floating point
- Memory: 512MB
- Internal HDD1: 3.5" SATA(II) X2
- Max Internal Capacity: 4TB (2x 2TB hard drives)8 (See All Supported HDD)
- External HDD Interface: USB 2.0 port X3, eSATA port X1
- Size: 160mm X 218mm X 88mm
- Weight: 0.98kg
- LAN: Gigabit X1
- Fan: X1(70mmX70mm)
- Noise Level:2 24dB(A)
- Power Recovery
- AC Input Power Voltage: 100V to 240V
- Power Frequency: 50Hz to 60Hz, Single Phase
- Max Supported IP Camera: 107 (See All Supported IP Cameras)
- Operating Temperature: 5C to 35C (40F to 95F)
- Storage Temperature: -10C to 70C (15F to 155F)
- Relative Humidity: 5% to 95%RH
- Maximum Operating Altitude: 10,000 feet
Power Consumption3
- 30W(Access);
14.4W(Hibernation)
Certification
- FCC Class B, CE Class B, BSMI Class B
Networking Protocols
- CIFS
- AFP (3.1)
- FTP
- NFS
- Telnet/SSH
Windows ADS Domain Integration
- ADS Support
- Domain users login via Samba/AFP/FTP
- Synology Data Replicator 3 for Domain Users
Security
- "FTP over SSL (explicit)" or "FTP over TLS (explicit)"
- FTP Auto-Block
- Encrypted Network Backup
- Encrypted rsync
- HTTPS Connection
File System
- EXT3
- FAT (External Disk Only)
- NTFS (External Disk Read Only)
File Sharing
- Max User Accounts: 2,048
- Max Groups: 256
- Max Shared Folder: 256
- Max Concurrent Connections(SAMBA, FTP, AFP): 256
Utilities
- Synology Assistant
- Synology Data Replicator 3
- Synology Download Redirector
- Add printer wizard
|
Applications
- Surveillance Station 2
- Photo Station 3
- File Station 2
- Audio Station
- Web Station
- PHP/MySQL
- Download Station 2
- iTunes Server
Packages
- Mail Station
- SqueezeCenter
- Webalizer
UPnP Multimedia Service Support
- Sony PS3, Microsoft Xbox360 (See All Supported DMA)
- Audio Format: AAC, FLAC, M4A, MP3, Ogg Vorbis, WAV, WMA, WMA VBR, WMA PRO, WMA Lossless
- Video Format: ASF, AVI, DAT, DivX, MP4, MPEG1, MPEG2, MPEG4, VOB, WMV, XviD
- Image Format: BMP, JPG (jpe, jpeg), GIF, ICO, PNG, PSD, TIF (tiff), UFO
- Playlist Format: WPL, M3U
iTunes Server Support
- Audio Format: MP3, M4A, M4P, WAV4, AIF4
- Playlist Format: M3U, WPL
Audio Station Support
- USB Mode: (Audio) AAC, FLAC, M4A, MP3, Ogg Vorbis, WMA, WMA VBR (Playlist) M3U, WPL (Internet Radio) SHOUTcast, Radioio
- Streaming Mode: (Audio) MP3 (Playlist) M3U, WPL
Photo Station 3 Support
- Video Format: ASF, AVI, MPEG1, MPEG4, WMV, XviD, DivX, FLV, DAT5, MP45, MPEG25, RM5, RMVB5, VOB5
- Image Format: BMP, JPG (jpe, jpeg), GIF
Management
- AJAX-based Management UI
- Sub-folder Privileges Setting
- User Home
- Applications privileges Setting
- BitTorrent Port Range Setup
- BitTorrent DHT Support
- CIFS Recycle Bin
- Download Station Bandwidth control
- Download Station Port Range Setup
- Editable HTTP Error Page
- Email Alert Message
- Email Notification for New User
- Package Management
- External HDD Hibernation (eSATA, USB)
- Scheduled Power On/Off
- Firmware Upgrade
- FTP passive port range
- Hide-able Shared Folder
- Internal HDD Hibernation
- Movable Shared Folder
- Removable Default Shared Folder
- System Temperature
- Ez-Internet
- PPPoE
- UPS Management (Over USB 2.0)
- User Quota
- Web-based Download Station 2
|
RAID Management
- Volume Type: Basic, JBOD, RAID 0, RAID 1
- Upgrade from Basic to RAID 1
- Expand RAID 1 with Larger Hard Drives
Backup Solutions
- Network Backup
- Local Backup
- Desktop Backup (using Synology Data Replicator 3)
- 3rd-Party Backup Support
Supported Clients
- Windows 2000 onward
- Mac OS X 10.3 onward
- Linux
Printer Support6
- Max Printer #: 2
- Supported Protocols: LPR, CIFS, AppleTalk
Languages
- English, German, French, Italian, Spanish, Danish, Norwegian, Swedish, Dutch, Russian, Korean, Polish, Traditional Chinese, Simplified Chinese, Portuguese (Brazil), Portuguese (European), Turkish, and Hungarian
Environment
Package Content
- DS209+II Main Unit
- Installation CD
- Welcome Note
- Assembling Kit
- AC Power Adapter
- AC Power Cord
- 2M RJ-45 LAN Cable
- SATA Hard Drive Power Cable X2
- SATA Hard Drive Data Cable X2
___
1.Hard drive not included.
2.FAN only. Measured at 2300~6200RPM, varied among models. More details about dB(A) value, check
https://www.quietnoise.com/facts.htm
3.Measured with 2 Seagate 750GB ST3750640NS hard drives. The figures could vary on different environments.
4.The music can be streamed, but the metadata (ex:title, album) may not be indexed on the iTunes.
5.User can click and download the file, but not play it in Photo Station as compressed Flash video.
6.For Mac users, DS209+II supports PostScript USB printers only.
7.1 free license to install 1 IP camera. Additional licenses can be purchased to expand the license quota.
8.The actual capacity will differ according to volume types.
|
