All stock codes associated to this product
CPU1200UC01, CPU-1200U-C01, 02XTHC1200, 02XT-HC1200
No Rules Power, NRP-HC series, complies with the newest Intel standard ATX 12V V2.2 and SSI standard EPS 12V V2.91 simultaneously. The advanced features, including bead core protection fro PCI-e connectors, worry-free power failure detector and an over 80% efficiency rating, enable NRP-HC series to the stable and clean power. No Rules Power proves to be a spectacular performer, and full product line also provides various choices for different kinds of consumers.
 |
 |
 |
Perfectly balanced high Power with all detail connectors to fulfil every customer need, NRP-HC Series supports ATX 12V Vers. 2.2, EPS 12V Vers. 2.92, QUAD SLI Systems and AMD/INTEL QUAD CORE Platforms. |
|
Outstanding Performance (over 87% Efficiency), covering all features, cable management and nice outlook design match perfectly to PC Enthusiasts imaginations. |
|
With 140mm powerful but silent fan protecting from Overheating, easy to install and absolutely user-friendly, NRP-HC Series will run your PC stable and save cost by high efficiency and less power consumption. |
|
|
|
|
|
|
 |
|
Multiple +12V Output
Enhanced +12V current capability broadens utilization possibilities. |
|
High Efficiency (up to 80%)
Optimal solution for lower energy consumption, noise, and heat. |
|
Active Power Factor Correction (0.99 PFC)
Reduce line loss & power distortion. |
|
Double Forward Circuit Design
Increase the reliability and efficiency of power. |
|
Universal AC Input(Full Range)
Plug & run safely anywhere in the world. |
|
Smart and Silent Fan Control
Smart thermal control to balance noise and cooling. |
|
13.5(14)cm Cooling Fan
Maximum airflow, minimum noise level and extra durable life. |
|
PCI-Express Connector
Support new PCI-E connectors for Video Card. |
|
Patented Easy Swap Connector
Unplug connectors easily & quickly. |
|
Cable Management Swap Connector
Improve messy cable problem.
With cable management swap connector. |
|
PC Power Supply Design Guide
Support ATX / BTX / EPS. |
|
Multiple Platforms
Capability for Intel / AMD platforms. |
|
Output Protection
Completed protection OVP / OCP / OPP / UVP / SCP / OTP. |
|
Mesh Sleeve Cable Design
Make cable management easier & airflow efficient. |
|
Honey Comb Structure |
|
Japan Electric Capacity |
|
|
|
|
| 14cm Cooling Fan |
|
|
|
|
| Smart & Silent Fan Control |
|
|
|
|
| PCI-E Connector |
|
|
|
|
| Patented Easy Swap |
|
|
|
|
| Cable Management |
|
|
|
|
| Japan Electric Capacity |
|
|
|
|
| Honey Comb Structure |
|
|
|
|
 |
|
Product Name
|
NRP-HC1201 |
|
Product Number
|
CPU-1200U-C01 |
|
Power
|
1200W |
|
Dimension
|
200mm(L) x 150mm(W) x 86mm(H) |
|
Switches
|
ATX Logic on-off additional power rocker switch |
|
Power Factor
|
Active PFC (PF > 0.9) |
|
Cooling System
|
140mm Fan, 2300RPM10% |
|
Noise
|
16 dBA at 1300RPM |
|
P.G. Signal
|
100-500 ms |
|
Efficiency
|
Up to 87% |
|
Hold-up Time
|
16 ms |
|
INPUT
|
|
Input Voltage
|
100-240VAC |
|
Input Frequency Range
|
47~63Hz |
|
MTBF
|
120,000 hrs minimum (at 25) |
|
Input Current
|
15A |
|
OUTPUT
|
| |
Max/Min |
Regulation *1 |
Ripple & Noise *2 |
Output |
|
+12V1
|
20A/1A |
+3, -3% |
120mV |
600W |
|
+12V4
|
36A/1A |
+3, -3% |
120mV |
|
+3.3V
|
30A/0.5A |
+3, -3% |
50mV |
600W |
|
+12V2
|
20A/1A |
+3, -3% |
120mV |
|
+12V3
|
36A/1A |
+3, -3% |
120mV |
|
+5V
|
30A/0.5A |
+3, -3% |
50mV |
|
-12V
|
0.8A/0A |
+10, -10% |
120mV |
9.6W |
|
+5Vsb
|
3.5A/0A |
+3, -5% |
50mV |
17.5W |
|
Total Power
|
1200W |
|
Peak Power
|
1300W |
+5Vsb operate at 3.5A max load base on PS-ON mode.
If PS-OFF +5Vsb only operate at 3A max load.
Add 0.1F capacitors across output terminal during ripple & noise test.
|
|
Environment
|
|
Operating Temp.
|
10 to 50 |
|
Storage Temp.
|
-20 to 70 |
|
Operating Humidity
|
20% to 90%, non-condensing |
|
Storage Humidity
|
5% to 95%, non-condensing |
|
Protection
|
| |
DC Rail |
Trigger Point/Range |
|
Over Voltage Protection
|
+3.3V trip point |
4.5 Vmax |
| +5.0V trip point |
7.0 Vmax |
| +12.0V trip point |
15.6 Vmax |
|
Over Current Protection
|
+3.3V |
33A ~ 50A |
| +5.0V |
33A ~ 50A |
| +12V1 & +12V2 |
22A ~ 35A |
| +12V3 & +12V4 |
39A ~ 55A |
|
Under Voltage Protection
|
+3.3V trip point |
2.0 Vmin |
| +5.0V trip point |
3.3 Vmin |
| +12.0V trip point |
8.5 Vmin |
|
Short Protection
|
All output to GND |
|
|
