Replacing your hard disk drive with a Corsair Expert Series SSD will revolutionize your computing experience. Games load more quickly, your computer starts faster, and multiple applications run more smoothly, all while running cool and silent.
Corsairs Extreme Series drives are among the fastest available today. The combination of the Indilinx Barefoot controller, Samsung flash memory, and a generous onboard cache, results in extreme performance with up to 220MB/s sequential read and 175MB/s sequential write speeds. Available in 32GB, 64GB, and 128GB configurations, the Extreme Series drives are for RAID 0 configurations on your desktop, delivering blistering speed and eliminating the long-standing performance bottleneck of traditional mechanical hard disks.
- Fast - Games and apps load faster, Windows is more responsive
- Compatible - The Extreme Series uses the proven Indilinx Barefoot controller, found on SSDs installed in tens of thousands of systems worldwide
- Stutter free - Samsung controller ensures smooth performance, unlike that of cheaper SSDs
- Silent - No moving parts means zero noise and high reliability
- Low Power - Longer battery life for laptop users means greater productivity
- Backed by Corsair - A respected name with a passion for great service and support
Features
- Maximum sequential read speed up to 240MB/s
- Maximum sequential write speed up to 170MB/s
- Indilinx Barefoot controller and Samsung MLC NAND flash for maximum performance
- 64MB DRAM cache for stutter-free performance
- No moving parts for increased durability over standard hard disk drives
- Decreased power usage for cool and quiet operation and increased laptop battery life
- 100+ Year Life Expectancy (MTBF)
- User upgradeable firmware
- Two year warranty
- Unformatted capacity. The total formatted capacity for the drive will be lower, depending on the operating system and file system used.
General Information
| Model |
CMFSSD-128D1 |
CMFSSD-64D1 |
CMFSSD-32D1 |
| Technology |
High-reliability Samsung MLC NAND flash |
High-reliability Samsung MLC NAND flash |
High-reliability Samsung MLC NAND flash |
| Form factor |
2.5 inch |
2.5 inch |
2.5 inch |
| Unformatted capacity |
128GB |
64GB |
32GB |
| Interface |
SATA II (3.0Gb/s)
Backward compatible with SATA I |
SATA II (3.0Gb/s)
Backward compatible with SATA I |
SATA II (3.0Gb/s)
Backward compatible with SATA I |
| Performance |
240 MB/s sequential read
170 MB/s sequential write |
220 MB/s sequential read
135 MB/s sequential write |
220 MB/s sequential read
135 MB/s sequential write |
| DRAM cache memory |
64MB |
64MB |
64MB |
| User upgradeable firmware |
Yes |
Yes |
Yes |
| Weight |
80g |
80g |
80g |
Electrical and Power Characteristics
|
| Voltage |
5V 5% |
5V 5% |
5V 5% |
Power consumption
(active) |
2.0W Max |
2.0W Max |
2.0W Max |
Power consumption
(idle/standby/sleep) |
0.5W Max |
0.5W Max |
0.5W Max |
Reliability
|
| S.M.A.R.T. support |
Yes |
Yes |
Yes |
| MTBF |
1,000,000 hours |
1,000,000 hours |
1,000,000 hours |
| Shock |
1500G |
1500G |
1500G |
| Warranty |
Two Years |
Two Years |
Two Years |
