All stock codes associated to this product
AFACO090P0GBA01, AFACO-090P0-GBA01, ACF9PWM, AC-F9-PWM
Patented PST (PWM Sharing Technology)
- Regulate RPM speed of up to 5 fans by the onboard CPU fan controller
- Lowest noise level for a given system load
- Control the entire cooling for your needs (silent / quiet / overclocking) via BIOS settings
Lowest Noise Level at its Air Flow Rate
Patented Case Design
Patented Vibration Absorption
Circulation Optimized Fan Blades
High Airflow
High Static Pressure
Compatible with toolless Mounting Mechanisms for Standard 25 mm deep fans
Long Lifetime
6 Years Warranty
The Fluid Dynamic Bearing offers a unique 400'000 h MTTF at 40C. Therefore we grant a unique 6 years warranty.
PST:
PWM amplifier integrated on motor circuit
4 pin plug for receiving power and PWM signal from motherboard
4 pin socket for CPU cooler or second fan
3 pin plug to send fan RPM signal to motherboard
Dimensions:
92 x 92 x 38.5mm
Rated Fan Speed:
600 - 2000 RPM
Air Flow:
34.8 CFM / 59 m3/h
Noise Level:
9.5 dB(A) - 23.5 dB(A), 0.08 Sone - 0.5 Sone
Power Consumption:
12 V, 0.13 Amp.
Weight:
92 g
Bearing:
Fluid Dynamic Bearing
Cable Length:
300mm
Warranty:
6 Year
