ST-MCB-120 | Swiftech MCB120 (Rev. 2) Radbox External Radiator Mount

The MCB120 rev2 "Radbox" is made of injection molded plastic and has a gorgeous silky black paint finish. Overall, the Radbox offers a clean, uncluttered, pleasing look along with easier installations for a variety of 120mm radiators. The Radbox is very sturdy thanks to the base plate featuring numerous reinforcement ribs and the Radbox can support single, dual or triple 120mm radiators. The included PCI pass-thru bracket is simplified, with the tubing passing straight thru the bracket improving flow rate, reducing connection requirements and therefore the possibilities for leaks.

The PCI pass-thru bracket is simplified, eliminating the nipple connections used in the previous kit. The tube passes straight thru the bracket which improves flow rate, eliminates four connections, and therefore the possibilities for leaks.

Specifications

Housing:

• Housing assembly dimensions - 130x130x35mm

• Material - injection molded POM

• Features - slotted holes allow installation to 60mm, 80mm, 92mm or 120mm fan holes. Up to 3" of vertical travel, and 2" of lateral travel with 80mm fan holes

• Finish - silk-black paint

PCI Pass-thru kit:

• Custom PCI bracket with U-shape holes for tube pass-thru and slotted hole for electrical routing.
