All stock codes associated to this product
121LFE652KR, 121-LF-E652-KR, EVG6002
Key Features
USB 2.0 Support
A standard plug and play interface providing easy-to-use connectivity for USB devices.
PCI Express 2.0 / 1.1 Support
Allows 500MB a lane or up to 8 GB/s at 16x speeds - allows for full support for new PCI-E 2.0 graphics cards.
Serial ATA II
Also known as SATA2, features a 3.0 Gbit/s transfer speed, faster than Standard Serial ATA.
Solid Capacitors
Offers a longer lifespan, better stability when at high frequencies, can operate at higher temperatures, and no longer runs the risk of exploding.
Passive Heatsink
Consist of a metal heatsink.
On-Boad Clear CMOS Button
An onboard clear CMOS button which allows you to easily clear your BIOS without moving a jumper.
2-Way SLI Support
Feel free to turn up the eye candy and experience the performance of 2 Graphics Cards running together.
Windows XP/Vista Support
DDR3 Support
Full support for the latest in DDR technologies.
Dual-Channel Support
Supports Dual-Channel memory configurations for increased amounts of system memory bandwidth.
Specifications
Performance Based on Intel P55 chipset
Supports Intel Socket 1156 Processors
Memory 4 x 240-pin DIMM sockets
Dual Channel DDR3
Maximum of 16GB of DDR3 1600MHz+
Expansion Slot 1 x 32-bit PCI, support for PCI 2.1
Storage I/O x UltraDMA133
6 x Serial ATA 300MB/sec with support for RAID 0, RAID1, RAID 0+1, RAID5, JBOD
Integrated Peripherals 8 Channel High Definition
1 x 10/100/1000
Multi I/O 1 x PS2 Keyboard
13 x USB2.0 ports (7 external + 6 internal headers)
Audio connector (Line-in, Line-out, MIC)
FireWire
Form Factor mATX Form Factor
Length: 9.6in - 243.84mm
Width: 9.6in - 243.84mm
