Synology DS-109 Network Storage Device
  • 1x3.5"SATA HDD, Disk Station Manager 2.1, 3xUSB2.0, 1xeSATA, 1xGigLAN

IMG 1 of 0
No Longer Available
Part Number:
125266
(?) Brand:
Synology Web Site
Manuf No:
DS109
Shipping Weight:
3 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
DS109
Synology Disk Station DS109 (1.2GHZ 128MB RAM) is designed to provide users with a flexible solution to share files and increase productivity. Packed with the Synology Disk Station Manager 2.1, it delivers ease of use and variety of features. Furthermore, the optional Synology 2.5" HDDDisk Holder provides an easy way for users to deploy a 2.5" hard drive on the DS109, bringing the library quietness, power saving, and higher reliability for the DS109.

  • Easy-to-use
  • Cool and Quiet
  • Power-Saving (9W~19W)
    •

    Features-rich 1 bay SATA NAS

    Product Code: DS-109



    Technical Specifications
      Applications
    Hardware Surveillance Station 2
    CPU Clock Rate: 1.2 GHz Photo Station 3
    RAM Size: 128 MB File Station 2
      Audio Station
    Internal HDD: Web Station
    1X 3.5" SATA(II) or 1X 2.5 PHP/MySQL
    SATA using Synology Disk Holder Type A Download Station 2
    External HDD Interface: 3X USB 2.0 ports,  iTunes Server
    1X eSATA port Packages
    Size: 160mm X 218mm X 63mm Mail Station
    Weight: 0.81kg  SqueezeCenter
    LAN: Gigabit X1 UPnP Multimedia Service Support
    Fan: 1X (50mmX50mm) Sony PS3, Microsoft Xbox360
      Audio Format: AAC, FLAC, M4A, MP3, Ogg
    Noise Level : 25 dB(A) Vorbis, WAV, WMA, WMA VBR, WMA PRO,
    Power Recovery WMA Lossless
    AC Input Power Voltage: 100V to 240V Video Format: ASF, AVI, DAT, DivX, MP4,
    Power Frequency: 50Hz to 60Hz, Single  MPEG1, MPEG2, MPEG4, VOB, WMV, XviD
    Phase Image Format: BMP, JPG (jpe, jpeg), GIF, ICO,
    Max HDD Support (Internal HDD): 1.5 TB PNG, PSD, TIF (tif), UFO
    Max Supported IP Camera #: 5 Playlist Format: WPL, M3U
    Operating Temperature: 5FXC to 35FXC  Subtitles: srt, psb, smi, ass, ssa, sub, idx, ifo
      iTunes Server Support
    Storage Temperature: -10FXC to 70FXC  (4) (4)
      Audio Format: MP3, M4A, M4P, WAV
    Relative Humidity: 5% to 95%RH , AIF
    Maximum Operating Altitude: 10,000 feet Playlist Format: M3U, WPL
      Audio Station Support
    Power Consumption USB Mode: (Audio) AAC, FLAC, M4A, MP3,
    19 W (Access); 9 W (Hibernation) Ogg Vorbis, WMA, WMA VBR (Playlist) M3U,
    Certification WPL (Internet Radio) SHOUTcast, Radioio
    FCC Class B, CE Class B, BSMI Class B Streaming Mode: (Audio) MP3 (Playlist)
    Networking Protocols M3U, WPL
    CIFS Photo Station 3 Support
    AFP (3.1) Video Format: ASF, AVI, MPEG1, MPEG4,
    FTP (5) (5) (5)
    NFS WMV, XviD, DivX, FLV, DAT
    Telnet/SSH , MP4 , MPEG2 ,
    Security (5) (5) (5)
    FTP over SSL/TLS (explicit) RM , RMVB , VOB
    FTP Auto-Block Image Format: BMP, JPG (jpe, jpeg), GIF
    Encrypted Network Backup Management
    Encrypted rsync AJAX-based Management UI
    HTTPS Connection BitTorrent Port Range Setup
    File System BitTorrent DHT Support
    EXT3 CIFS Recycle Bin
    FAT (External Disk Only) Download Station Bandwidth control
    NTFS (External Disk Read Only) Download Station Port Range Setup
    File Sharing Editable HTTP Error Page
    Max User Accounts: 1,024 Email Alert Message
    Max Groups: 128 Email Notiication for New User
    Max Shared Folder: 256 Package Management
    Max Concurrent Connections (SAMBA, FTP,  External HDD Hibernation (USB)
    AFP): 64 Scheduled Power On/Of
    Utilities Firmware Upgrade
    Synology Assistant FTP passive port range
    Synology Data Replicator 3 Hide-able Shared Folder
    Synology Download Redirector Internal HDD Hibernation
    Add printer wizard Removable Default Shared Folder
      Ez-Internet
      PPPoE
      UPS Management (Over USB 2.0)
    User Quota
    Web-based Download Station
    Backup Solutions
    Network Backup
    Local Backup
    Desktop Backup (using Synology Data
    Replicator 3)
    3rd-Party Backup Support
    Supported Clients
    Windows 2000 onward
    Mac OS X 10.3 onward
    Linux
    Printer Support
    Max Printer #: 2
    Supported Protocols: LPR, CIFS, AppleTalk
    Languages
    English, Danish, Dutch, Norwegian, Swedish,
    German, French, Italian, Polish, Russian,
    Spanish, Korean, Japanese, Traditional
    Chinese, Simpliied Chinese, Hungarian,
    Turkish, Portuguese Brazil, Portuguese
    European
    Environment
    RoHS Compliant
    Package Content
    DS109 Main Unit
    Installation CD
    Welcome Note
    Assembling Kit
    AC Power Adapter
    AC Power Cord
    2M RJ-45 LAN Cable
    ___
    (1) Hard drive not included.
    (2) FAN only. Measured at 2300~6200RPM, varied
    among models. More details about dB(A) value,
    check https://www.quietnoise.com/facts.htm
    (3) Measured with 1 Seagate 750GB ST3750640NS
    hard drive. The igures could vary on diferent
    environments.
    (4) The music can be streamed, but the metadata
    (ex: title, album) may not be indexed on the iTunes.
    (5) User can click and download the file, but not
    play it in Photo Station 3 as compressed Flash video.
    (6) For Mac users, DS109 supports PostScript USB
    printers only.





    Effortless File Sharing & Backup:

    Synology Disk Station is designed for data storage and sharing among Windows, Mac, and Linux. Seamless file sharing across diferent operation systems is an effortless process.

    Synology File Station 2 ofers an innovative user interface with drag-n-drop and right-click capability allowing
    users not familiar with FTP to easily access files with a web browser.
    Synology Data Replicator 3 allows Windows users to back up desktop data to the Synology Disk Station.
    Immediate, Sync, and Scheduled Backup are fully-supported.
    Synology Local Backup helps to safeguard data by backing up to external hard drives via either USB or eSATA interfaces with flexible scheduling options.

    Office Application:
    Synology Mail Station add-on provides a one step installation and enables Synology Disk Station to be a mail
    server that supports Outlook-like Web mail, SMTP, POP3, and IMAP.

    Synology Web Station with Virtual Host option allows users to host up to 30 websites on one single Synology
    Disk Station. The built-in PHP+MySQL provides the ability to create interactive websites without complicated setting.


    Synology Disk Station supports two USB printers simultaneously, and the Add Printer Wizard simpliies setup
    process with a wizard.


    3rd-Pary Application integration


    Following Synology NAS Server 3rd-Party Apps Integration Guideon Synology website, users can customize
    their Synology Disk Station by installing their favorite applications.




    Synology Disk Station is designed and developed perpetually with the concept of energy saving. Compared
    with its average PC counterparts, Synology Disk Station consumes a relatively low amount of power and
    hibernates when not in use. This not only helps to save energy but also extends the lifespan of the hard disk.
    Synology Disk Station truly earns the title of green product because of the unique Scheduled Power On/Off
    feature, and the smart fan design effectively cools down the system with minimum power consumption, yet
    keeps the system quiet on operation.






    Eco Friendly
    Finally, all Synology products are produced with RoHS compliant parts and packed with recyclable packing
    materials. Synology recognizes its responsibility as a global citizen and is continually working to reduce the
    environmental impact of the products we create.

    No additional files, specification sheets, guides or documentation found for product.

    Warranty: 1 Year Return to Base

    Full manufacturers warranty details are available at the manufacturers (Synology) web site.
