All stock codes associated to this product
Cougar1000CM, Cougar-1000CM
ougar 1000CM also uses105 C high temperature resistance capacitor to guarantee long term operation is smooth and stable for Australian hot summer, it is designed again for the gaming guru machinesthat has extreme specificationfor the best, it comes with super quiet 14CM thermal managedcooling fan giving you whisper quiet operation environment. Up to 88% of efficiency, compliant with 80-PLUSR Bronze efficiency requirement .Due to the extremely high efficiency of the COUGARR-Series you can reduce your electricity costs in spite of high performance. In addition, less energy is converted into heat, which improves the cooling of the entire PC. Furthermore, the PSU fan can rotate more slowly, which reduces the noise-level of the whole system. In short, the PSU is efficient, cool and silent! You can find further information on the 80-plus certification on https://www.80plus.org
Safety function
-
UVP (Undervoltage protection)
If the voltages fall below a certain tolerance value on the single lines, the PSU automatically switches off.
-
OVP (Overvoltage protection)
If the voltages increase above
a certain tolerance value on the single lines, the PSU automatically switches off.
-
SCP (Short-circuit protection)
In the case of a short-circuit this feature prevents damage to the core components of the PSU and its system components.
-
OPP (Overload protection)
If the system is oversized and requires more power from the PSU than it can perform, this protection function is activated.
-
OCP (Overcurrent protection)
If the load on a single line is higher than indicated, the PSU automatically switches
- M/B Supports: ATX form factor P4
- DC output: 1000W
- Efficiency: up to88%
- Connectors:24+4+2x4+7xPATA+8xSATA+1xFDD+2x 6pins PCI+2x 8pins PCI
- DC Current:3.3V/30A, 5V/30A, 12V1/24A, 12V2/24A, 12V3/24A, 12V4/24A, 12V5/28A, 12V6/28A, 5VSB/3A
- AC input: full range
- Cooling fan:14CM super silent fanx1
- Rear:on/off Switch
- Cables: native+modular management
