All stock codes associated to this product
TS419U, TS-419U, NASQNP41901B
QNAP TS-419U Turbo NAS is the 4-bay, 1U chassis multi-functional network attached storage (NAS) server designed for small and mid-sized business who is looking an affordable and low-powered network storage solution. The TS-419U can be easily installed and maintained in the server room. It is an ideal solution for mass data backup, management and sharing. Moreover, the NAS supports excellent hardware design, outstanding performance, high system reliability and expandability, and numerous powerful software applications. It is undeniably the top-notch model in the 4-bay 1U chassis NAS market.
The TS-419U adopts Marvell 1.2GHz CPU and 512MB DDRII memory. It supports 4 2.5-inch and 3.5-inch hot-swappable SATA hard drives, 2 Gigabit LAN ports for multi-IP settings and port trunking (7 bonding modes). The NAS is equipped with 4 USB ports and 2 eSATA ports for storage expansion or external data backup.
The TS-419U supports RAID 0/ 1/ 5/ 6/ 5+spare, single and JBOD disk configurations. The unique Online RAID Capacity Expansion and Online RAID Level Migration allow the users to expand the storage capacity of the RAID configuration and upgrade the RAID level without turning off the server respectively. The RAID recovery feature secures the server data against accidental removal of the hard drives.
In addition, the TS-419U supports NAS and iSCSI applications to provide a low-cost, highly flexible and efficient IP SAN solution for SMB users. Up to 8 iSCSI targets can be created on the NAS for storage expansion of the PC or other servers and backup destination of the database servers and mail servers, etc. The TS-419U is featured with virtual disk drive (VDD) by built-in iSCSI initiator that other iSCSI devices on the network can be added to expand the storage capacity of the NAS.
The TS-419U supports abundant powerful applications which can be accessed across Windows, Mac, Linux, and UNIX. Also, numerous management tools, e.g. Windows Active Directory (AD), real-time system monitoring, detailed event logs, Simple Network Management Protocol (SNMP), instant SMS alert, and schedule power on/ off management are provided for the users to manage the NAS efficiently.
Specifications:
| CPU |
Marvell 6281 1.2GHz |
| DRAM |
512MB DDRII RAM |
| Flash Memory |
16MB |
| HDD |
4 x 3.5" or 2.5 SATA I/II HDD
NOTE:
- The system is shipped without HDD.
- For the HDD compatibility list, please visit https://www.qnap.com/pro_compatibility.asp
|
| HDD Tray |
4 x hot-swappable and lockable tray |
| LAN Port |
2 x Gigabit RJ-45 Ethernet port |
| LED Indicators |
USB, Status, HDD 1, HDD 2, HDD 3, HDD 4, LAN |
| USB |
4 x USB 2.0 port (Front: 1; Back: 3)
Supports USB printer, disk, pen drive, USB hub, and USB UPS, etc. |
| eSATA |
2 x eSATA port (Back) |
| Buttons |
System: Power button, USB one-touch-backup button, reset button |
| Alarm Buzzer |
System warning |
| Form Factor |
Rackmount |
| Dimensions |
44(H) x 439(W) x 483(D) mm
1.73(H) x 16.97(W) x 19.02(D) inch |
| Weight |
Net weight: 6.7 Kg (14.77 lbs)
Gross weight: 11.06 Kg (24.38 lbs) |
| Sound Level (dB) |
W/o HDD installed: 33 dB
Stand by: 33.2 dB
In operation: 35.1dB
(Background: 25.5 dB) |
| Power Consumption (W) |
Sleep mode: 15W
In operation: 29W
(with 4 x 500GB HDD installed) |
| Temperature |
0~40C/ 32~104F |
| Humidity |
0~95% R.H. |
| Power Supply |
Input: 100-240V AC, 50/60Hz, Output: 250W |
| Fan |
3 x quiet cooling fan (4 cm, 12V DC) |
