Redefine HD Gaming

• 80 Stream Processing Units
  Enough power to tackle the most demanding HD games and applications.



• Microsoft DirectX10.1
  Play today while preparing for tomorrow with state-of-the-art DirectX 10.1 graphics capabilities.

• Enhanced Anti-Aliasing (AA) & Anisotropic Filtering (AF)
  High performance anisotropic filtering and anti-aliasing (4X AA) smooth jagged edges and create true-to- life graphics, for everything from grass to facial features

• ATI CrossFireX Technology
  Dual mode ATI CrossFireX technology offers superior scalability.

• PCI Express 2.0
  Support for PCI Express 2.0 will prepare you for bandwidth-hungry games and 3D applications.

Go Beyond HD Video

• Upscale Beyond 1080p
  Watch the hottest Blu-ray movies or other HD content at full 1080p display resolution and beyond.1

• Unified Video Decoder 2 (UVD 2)
  UVD 2 frees up your CPU for other tasks so you get The Ultimate Visual Experience for the most processing- intensive content. Take full advantage of Blu-ray functionality with dual-stream, picture in picture capabilities.

• Enhanced DVD Upscaling
  Watch standard DVD movies in near high-definition quality with DVD upscaling. The GPU uses post processing algorithms to enhance standard and low resolution videos and movies on your HD display.

• HDMI
  Enjoy the latest audio technologies using HDMI with 7.1 digital surround sound support. Also, xvYCC support allows the user to enjoy a wider range of color when connected to a capable HDTV.


1 Blu-ray drive and HD capable monitor required.

Save Time & Energy

• Consumes less than 25 watts under full load
  The ATI Radeon HD 4350 graphics card consumes less than 25 watts under full load, making it the ideal choice for implementation across a large diverse install base of desktop PCs.

• Dynamic Power Management
  ATI Radeon HD 4350 graphics card features ATI PowerPlay technology, delivering high performance when needed and conserving power when the demand on the graphics processor is low.1

• Energy Efficient Manufacturing Process
  Second generation 55nm chip uses the industrys most energy efficient manufacturing process.

• Stability & Reliability
  AMDs award-winning ATI Catalyst graphics software and drivers deliver unprecedented graphics stability and reliability.

1 ATI PowerPlay technology consists of numerous power saving features. Not all features may be available in all ATI Radeon HD 4350 graphics card.

System Requirements

PCI Express based PC is required with one X16 lane graphics slot available on the motherboard

300 Watt or greater power supply (350 Watt for ATI CrossFireX technology in dual mode) is recommended.Certified power supplies are recommended. Refer to https://ati.amd.com/certifiedPSU for a list of Certified products

1GB of system memory recommended

Installation software requires CD-ROM drive

Blu-ray playback requires Blu-ray drive and full 1080p display requires a 1080p-capable monitor

For Microsoft DirectX 10.1 support, Windows Vista Service Pack 1 is required

Dual mode software CrossFire.

ATI Radeon HD 4350 1024MB of DDR2 memory

DirectX 10.1

80 stream processing units

12x custom filter anti-aliasing (CFAA) and high performance anisotropic filtering

PCI Express 2.0 support

Dual mode ATI CrossFireX technology multi-GPU support for highly scalable performance

ATI Avivo HD video and display technology*

Unified Video Decoder 2 (UVD 2) for Blu-ray and HD Video

DVD Upscaling

Built-in HDMI with 7.1 surround sound support

Dynamic power management with ATI PowerPlay technology***



Specifications

I/O Output: Dual DL-DVI-I+HDTV

Core Clock: 600 MHz

80 Stream Processors

12x custom filter anti-aliasing (CFAA) and high performance anisotropic filtering

Dual mode ATI CrossFireX technology multi-GPU support for highly scalable performance*

Memory Clock: 400MHz, 800 Mbps.

PCI Express 2.0 x16 bus interface

1024MB /64bit DDR2 memory interface, supports Hyper Memory up to 1GB**

Single Slot heatsink

HDMI compliant via dongle

7.1 Audio Channel Support

Microsoft DirectX 10.1 support

Shader Model 4.1 support
