Billion BIPAC 5200SRD ADSL2+ Modem/Router - 1-Port 10/100 RJ45, Supports VPN

IMG 1 of 1
No Longer Available
Part Number:
131880
(?) Brand:
Billion Web Site
Manuf No:
BIPAC5200S RD
Shipping Weight:
1 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
BIPAC5200SRD, BIPAC5200S RD

BiPAC 5200S RC / RD
Pocket-size ADSL2+ Modem/Router

Billions BiPAC 5200S RC/RD is an easy-to-use yet economical pack of ADSL2+ Modem/Router perfectly designed for home and SOHO users to enjoy rich firewall security, user-friendly Web interface, and faster speed when using ADSL Internet connection. The router lets you share high-speed ADSL Internet connection, even faster with advanced ADSL2+ capability of downstream rates of up to 24 Mbps. The powerful SOHO Firewall feature protects against hackers attacks when you surf the Internet. VPN pass-through is also built-in for secure access. In addition, the web-based Graphic User Interface allows you to install and manage your network easily. The BiPAC 5200S RC/RD makes fast net surfing affordable and easy - Going online is just plug & play.

Green ProductBlankADSL2+ RouterBlankEasy WebBlankFirewall Router
Key Features
  • High speed Internet access with ADSL2/2+; backward compatible with ADSL
  • Easy Network Management
  • Single Ethernet Port
  • SOHO Firewall Security with DoS Prevention and Packet Filtering
  • Universal Plug and Play (UPnP) Compliant
  • Dynamic Domain Name System (DDNS)
  • Supports Virtual Private Network (VPN) pass-through
  • Ideal for Home and SOHO Users
 Benefits
Express Internet Access
The router complies with worldwide ADSL standards. It supports downstream rates of up to 12/24 Mbps with ADSL2/2+, 8 Mbps with ADSL, and upstream rates of up to 1 Mbps. With this technology, users enjoy not only high-speed ADSL service but also broadband multimedia applications such as interactive gaming, video streaming and real-time audio much more quickly and easily than ever. Particularly, the Annex A+M model also supports the latest ADSL2/2+ for higher upload speeds by doubling the upstream data rate.
SOHO Firewall Security
Along with the built-in NAT firewall feature, the routers advanced anti-hacker pattern-filtering protection feature automatically detects and blocks Denial of Service (DoS) attacks. In addition to the NAT technology, the BiPAC 5200S RC/RD supports Packet Filtering for high-level security control.
Easy Network Management
The Web-based User Interface makes the BiPAC 5200S RC/RD extremely easy for users to install and manage the network. The router supports DHCP client and server, enabling system administrators to easily fit this router into existing network environment and manage the IP assignment without re-configuring other stations. Furthermore, future firmware upgrades can be downloaded via the user-friendly Web-based Interface.


















Features & Specifications

ADSL Compliance
Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.lite (ITU G.992.2)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
Compliant with ADSL2 Standard
- G.dmt.bis (ITU G.992.3)
- ADSL2 Annex M (ITU G.992.3 Annex M)
(Available for BiPAC 5200S RCA/5200S RDA model only)
Compliant with ADSL2+ Standard
- G.dmt.bis plus (ITU G.992.5)
- ADSL2+ Annex M (ITU G.992.5 Annex M)
(Available for BiPAC 5200S RCA/5200S RDA model only)

Network Protocols and Features
NAT, static routing and RIP-1/2
Multi-to-multi NAT
Transparent Bridging
Dynamic Domain Name System (DDNS)
SNTP
DNS client/relay

Firewall & Virtual Private Network (VPN)
Built-in NAT Firewall
Prevents DoS attacks including Land Attack, Ping of Death, etc.
Anti probe function
Packet filtering
Password protection for system management
VPN pass-through

Operating Environment
Operating temperature: 0 - 40oC
Storage temperature: -20 - 70oC
Humidity: 20 - 95% non-condensing

ATM and PPP Protocols
ATM Adaptation Layer Type 5 (AAL5)
Multiple Protocol over AAL5 (RFC 2684, formerly RFC 1483)
Bridged or routed Ethernet encapsulation
VC and LLC based multiplexing
PPP over Ethernet (PPPoE)
PPP over ATM (RFC 2364)
OAM F4/F5
ATM QoS: UBR, CBR, VBR-rt, VBR-nrt

Management
Web-based configuration
Firmware upgrades and configuration data upload and download via HTTP/FTP
SNMP v2 MIB supported
Supports DHCP server/client/relay
TR-069 supports remote management (BiPAC 5200S RD only)

Hardware Specifications
Physical Interface
DSL: ADSL port
Ethernet: single port 10/100M auto-crossover (MDI/MDI-X) switch
Factory default reset button
Power jack
Power switch (BiPAC 5200S RD only)
Physical Specifications
Dimensions: 5.53" x 3.56" x 1.38 (140.5mm x 90.5mm x 35mm)
Power Requirements
Input: 12V AC, 1A

Models & Standards Supported
Product Models
BiPAC 5200S RC/RD: Pocket-size ADSL2+ Modem/Router
Standards
BiPAC 5200S RCA/5200S RDA:
Supports Annex A and Annex M (Annex A and Annex M: ADSL over POTS)
BiPAC 5200S RCU/5200S RDU:
Supports Annex B and U-R2 (Annex B and U-R2: ADSL over ISDN)

Application Diagram



Application Diagram (BiPAC 5200S RC / RD - Pocket-size ADSL2+ Modem/Router)
