Xigmatek 600W NRP-PC602 - ATX12V v2.3, 140mm Fan, 80 PLUS Bronze Certified
8xSATA, 2xPCI-E 6+2-Pin, 2xPCI-E 6-Pin

No Longer Available

Part Number:

132193

(?) Brand:

Xigmatek Web Site

Manuf No:

CPH-0600U-X02
CPH0600UX02

Shipping Weight:

3 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

CPH0600UX02, CPH-0600U-X02, 02XTPC602, 02XT-PC602

NRP-PC602 is a totally green and eco-friendly power supply with high efficiency and green package to save energy, reduce heat, and help you to save more forest to protect our environment.

Compliant with latest Intel ATX12V Ver.2.3 with 80Plus Bronze certification. NRP-PC602 is compatible with Quad-core CPU and high-end graphic card with PCIe 6pin and PCIe 6+2pin connectors.

Fancy semi-transparent black 140mm cooling fan with thermal fan speed control and all DC cables with mesh sleeves provide optimized airflow and lower noise level.

High efficiency over 85%
Higher efficiency, lower energy loss, cooler our Earth.

Compliant with ATX12V Ver.2.3
Compliant with latest Intel ATX12V Ver.2.3 PSU design guide.

0.99 Active PFC rate
The highest AC utility rate and active switch for universal AC voltage.

Real and stable 600W output
Continuous 600W total DC output for real 100% loading.

DC quality with low ripple noise
Low ripple noise DC output for better devices performance.

Japanese 105C Main Capacitor
High-end and more stable Japanese capacitor for better output performance.

140mm silent cooling fan
The bigger fan is equal to lower RPM and less noise.

Smart thermal fan control
Fan RPM was controlled by temperature and
keep silence in typical loading.

All DC cables with mesh sleeve
Reduce airflow resistance for better thermal release in PC case.

PCIe graphic card connector support
Support high-end graphic card with PCIe 6/8pin connector.

14cm Cooling Fan

Smart & Silent Fan Control

PCI-E Connector

Patented Easy Swap

4+4Pin Connector

Japanese Main Capacitor

Mesh Sleeves

Product Name	NRP-PC602
Product Number	CPH-0600U-X02
Power	600W
Dimension	150mm(L) x 160mm(W) x 86mm(H)
Power Factor	PF > 0.9
Cooling System	14cm fan, Max. 1800RPM10%
Hold-up Time	16 ms
Noise Level	16dBA10% at 800RPM
INPUT
Input Voltage	100-240VAC
Input Frequency Range	47/63Hz
MTBF	100,000 hrs minimum (at 25)
Input Current	115Vac/10A max. 230Vac/5A max.
OUTPUT
	Max/Min	Regulation	Ripple & Noise	Output
+5V	15.0A/0.2A	+5, -5%	50mV	130W
+3.3V	24.0A/0.5A	+5, -5%	50mV
+12V1	30.0A/0.5A	+5, -5%	120mV	504W
+12V2	22.0A/1.0A	+5, -5%	120mV
-12V	0.3A/0.0A	+10, -10%	120mV	3.6W
+5Vsb	2.5A/0.1A	+5, -5%	50mV	12.5W
Total Power	600W
Environment
Operating Temp.	10 to 40
Storage Temp.	-40 to 70
Operating Humidity	20% to 90%, non-condensing
Storage Humidity	5% to 95%, non-condensing
Protection
	DC Rail		Trigger Point/Range
Over Voltage Protection	Trippunkt +3,3 V		4.5 V max.
	Trippunkt +5,0 V		7.0 V max.
	Trippunkt +12,0 V		15.6 V max.
Over Current Protection	The power supply should provide OCP and should shutdown before 240VA of each output power (included +5V, +3.3V). The power supply should provide OCP when over current output. of each output power(included +12V).
Short Protection	All output to GND

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Xigmatek) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
