Viewing excellence
View your pictures on the20.3 cm (8 in.) digital photo display featuring KODAK Color Science Technology for vibrant color and crisp detail.
Simple to use touch controls
- Kodaks Quick Touch Border with automatic motion sensorthe unique touch border keeps fingerprints off of your viewing screen so your images stay beautiful
- The touch panel features yellow lights that illuminate to tell you exactly where to touch
- Scroll through photos and view slideshowsall at the touch of your fingertips
Store more pictures
- Store up to 4000[1]pictures directly on your frames 512 MB of internal memory
- Pictures are automatically resized to fit on the frame
- Use the USB port and 2 card slots to add pictures from other sources
Plug and playdone your way
- Start viewing your pictures right awayjust insert a memory card or USB flash drive and enjoy
- See more memories at once using the dynamic collage mode that shows off several pictures at the same timeplus other options like clock and calendar views
Environmentally responsible operation
- ENERGY STAR qualified for efficient power consumption
- Mercury-free panel
- Programmable timer automatically shuts down power at preferred times
- Make your frame even more energy efficient by upgrading your firmware
Easily access and transfer pictures
- KODAK EASYSHARE Software, Digital Frame Edition, makes it simple to browse and edit your pictures
- Use KODAK EASYSHARE Software to quickly re-size your pictures so you can fit more on your frame
- The convenient drag-and-drop feature is perfect for transferring pictures onto a memory card or USB drive
- Learn more about KODAK EASYSHARE Software, Digital Frame Edition and download it for free
Product Specifications
| Image file formats |
JPEG, EXIF
|
| Weight |
843 g (1.9 lb. ) (includes frame, stand, and AC adapter)
|
| Dimensions |
- frame only: 24.9 19.8 3.3 cm (9.8 7.8 x 1.3 in.)
- frame and faceplate: 28.4 24.4 4.6 cm (11.2 9.6 1.8 in.)
|
| Display size |
20.3 cm (8 in. )
|
| Display area |
16.3 12.2 cm (6.4 4.8 in.)
|
| Display resolution |
800 600 pixels
|
| Aspect ratio |
4:3
|
| Display type |
aSi TFT active matrix
|
| Display backlight |
LED
|
| Display brightness |
270 NITs (typical)
|
| Contrast ratio |
500:1 (typical)
|
| Supported Memory Card Formats |
2 slotsSecure Digital (SD), Secure Digital High Capacity (SDHC), Multimedia Card (MMC), MEMORY STICK (MS), MS PRO/MS PRO DUO, XD-Picture Card (xD)
|
| Internal Memory |
512 MB[1]
|
| Display modes |
full screen, collage, clock, calendar
|
| Power consumption |
- 5.5 W (frame running in slideshow mode)
|
| Power supply |
- 100240 V AC, 5060 Hz (WW)
- 5 V DC
|
| Operating temperature |
32 to 104 F (0 to 40 C)
|
| Storage temperature |
-24 to 160 F (-31 to 71 C)
|
Package Contents
- KODAK EASYSHARE D830 Digital Frame with Faceplate
- Power supply with 1.8 m (6 ft) cord
- AC plug(s)
- User Guide
System Requirements
WINDOWS
- WINDOWS XP or higher
- INTERNET EXPLORER 6.0 or higher
- 600 MHz processor or greater
Hardware
- 128 MB RAM (256 MB recommended)
- 200 MB hard disk drive space available
- CD-ROM drive
- Available USB port
1Actual storage capacity will vary based on image content.
