BIPAC5210S RC | Billion BIPAC 5210SRC ADSL2+ Modem/Router - 1-Port 10/100

Express Internet Access
The router complies with ADSL worldwide standards. It supports downstream rate up to 12/24 Mbps with ADSL2/2+, 8 Mbps with ADSL and upstream rate up to 1 Mbps. Users enjoy not only high-speed ADSL services but also broadband multimedia applications such as interactive gaming, video streaming and real-time audio much easier and faster than ever. Particularly, the Annex A+M model also supports the latest ADSL2/2+ Annex M technology for higher upload speeds by doubling the upstream data rate.

SOHO Firewall Security
Powered by NAT technology integrated in BiPAC 5210S RC, dozens of users not only surf Internet and share the ADSL connection simultaneously by using one ISP account and one IP address, but are also provides advanced hacker pattern-filtering protection. It can automatically detect and block Denial of Service (DoS) attacks. In addition to NAT technology, the BiPAC 5210S RC supports Packet Filtering feature for higher-level security control.

Easy Network Management
The Web-based User Interface makes the BiPAC 5210S RC extremely easy for users to install and manage the network. With DHCP client and server built-in, system administrators can easily attach the router into existing network and manage the IP assignment without re-configuring other stations. Furthermore, future firmware upgrade can be done via friendly Web-based User Interface.

Dual Flexibility
The BiPAC 5210S RC integrates both USB and Ethernet LAN interface into one box. Whenever you like, BiPAC 5210S RC let you connect your computer by either USB cable or Ethernet port to access the Internet. You can easily share your Internet connection and multimedia applications with other users. Just plug and play and experience dual-flexibility of 10/100 Ethernet and USB at the same time.

ADSL Compliance
Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.lite (ITU G.992.2)
- G.hs (ITU G.994.1)
- ADSL over ISDN / U-R2
Compliant with ADSL2 Standard
- G.dmt.bis (ITU G.992.3)
- ADSL2 Annex M (ITU G.992.3 Annex M)
Compliant with ADSL2+ Standard
- G.dmt.bis plus (ITU G.992.5)
- ADSL2+ Annex M (ITU G.992.5 Annex M)

Network Protocols and Features
NAT, static routing and RIP-1 / 2
Multi-to-multi NAT
Transparent Bridging
Dynamic Domain Name System (DDNS)
SNTP
DNS client/relay
USB driver support: Windows 98SE/ME/XP/2K/Vista 32/64 bit

Firewall & Virtual Private Network (VPN)
Built-in NAT Firewall
Prevent DoS attacks including Land Attack, Ping of Death, etc.
Anti probe function
Packet filtering
Password protection for system management
VPN pass-through

Operating Environment
Operating temperature: 0 - 40oC
Storage temperature: -20 - 70oC
Humidity: 20 - 95% non-condensing

ATM and PPP Protocols
ATM Adaptation Layer Type 5 (AAL5)
Multiple Protocol over AAL5 (RFC 2684, formerly RFC 1483)
Bridged or routed Ethernet encapsulation
VC and LLC based multiplexing
PPP over Ethernet (PPPoE)
PPP over ATM (RFC 2364)
OAM F4/F5
ATM QoS: UBR, CBR, VBR-rt, VBR-nrt

Management
Web-based configuration
Firmware upgraded and configuration data upload and download via HTTP/FTP
SNMP v2 MIB supported
Supports DHCP server/client/relay
TR-069 supports remote management

Hardware Specifications
Physical Interface
DSL: ADSL port
USB: Comply to USB v1.1
Ethernet: single Ethernet 10/100M auto-crossover (MDI/MDI-X) switch
Factory default reset button
Power jack
Power Switch
Physical Specifications
Dimensions: 5.53" x 3.56" x 1.38 (140.5mm x 90.5mm x 35mm)
Power Requirements
Input: 12V AC, 1A
