All stock codes associated to this product
NETBP7300RA, NET-BP7300RA
BiPAC 7300 RA
ADSL2+ Firewall Router with QoS and EZSO |
Easy to set up to surf the net! Billions BiPAC 7300 RA series is an all-in-one compact package of ADSL2+ router perfectly designed for home and SOHO users to enjoy the mobility and faster speed when using ADSL Internet connection. The device lets you access high-speed ADSL Internet connection, even faster with
advanced ADSL2+ capability with downstream rate up to 24 Mbps. The router supports Easy Sign-On (EZSO) technology, enabling users to establish ADSL connections via standard web browsers such as Internet Explorer. This user-friendly design supports all kinds of operating systems, significantly reducing the time and efforts spent configuring your system. An abundance of integrated firewall security features such as SPI, DoS attack prevention, and URL Content Filtering provide users unparalleled protection from hackers. The Quality of Service feature ensures a smooth net connection for inbound and outbound data, with minimal traffic
congestion.
Key Features
- High speed Internet access with ADSL2/2+; backward compatible with ADSL
- Auto channel select
- SOHO firewall security with DoS prevention and packet filtering
- Easy Sign-On (EZSO) and web-based configuration
- Quality of Service control
- Universal Plug and Play (UPnP) ompliant
- Dynamic Domain Name System (DDNS)
- Supports VPN pass-through
- Ideal for home & SOHO users
Benefits
Express Internet Access
This router complies with worldwide ADSL standards. It supports downstream rates of up to 12/24 Mbps with ADSL2/2+, 8 Mbps with ADSL, and upstream rates of up to 1 Mbps. With this technology, users enjoy not only high-speed ADSL service but also broadband multimedia applications such as interactive gaming, video streaming and real-time audio much more quickly and easily than ever. In particular, by doubling the upstream data rate, the Annex M standard included in the BiPAC 7300 RA A model supports the latest ADSL2/2+ for higher upload speeds.
Smooth and Responsive Net Connection
Quality of Service (QoS) gives you full control over outgoing data traffic. Priority can be assigned by the router to ensure that important data like gaming packets, customer information, or management information passes through the router at lightning speed, even under a heavy load. You can also control the speed of different types of outgoing data passing through the router to ensure that users do not saturate your bandwidth with their browsing activities.
Easy Sign-On (EZSO)
Easy Sign-On (EZSO) technology allows users to effortlessly establish an ADSL connection through standard web browsers such as Internet Explorer. The router can automatically detect the PPPoE/PPPoA or DHCP protocol for your ADSL connection. Just log into the system with the required username and password provided by your ISP, and the router will automatically establish the Internet connection for you. This user-friendly design supports all kinds of operating systems.
Robust Firewall Security
Along with the built-in NAT natural firewall feature, the routers advanced anti-hacker pattern-filtering protection feature automatically detects and blocks Denial of Service (DoS) attacks. Built with Stateful Packet Inspection (SPI), the router enables users to determine whether or not a given data packet is allowed to pass through the firewall to the private LAN.
ATM and PPP Protocols
ATM Adaptation Layer Type 5 (AAL5)
Multiple Protocol over AAL5 (RFC 2684, formerly RFC 1483)
Bridged or routed Ethernet encapsulation
VC and LLC based multiplexing
PPP over Ethernet (PPPoE)
PPP over ATM (RFC 2364)
OAM F4/F5
Management
Quick Installation Wizard and Auto-scan ADSL settings
Web-based for remote and local management
Firmware upgrades and configuration data upload/download via web-based interface
Embedded Telnet server for local management
SNMP v1/v2/v3, MIB-I and MIB-II support
Available Syslog monitoring
Supports DHCP server/client/relay
Mail Alert
Operating Environment
Operating temperature: 0 - 40C
Storage temperature: -20 - 70C
Humidity: 20 - 95% non-condensing
Hardware Specifications
Physical Interface (BiPAC 7300 RA)
Power jack
Factory default reset button
LAN: 4-port 10/100M auto-crossover (MDI/MDI-X) switch
LINE: ADSL port
Physical Specifications
BiPAC 7300G RA
Dimensions: 7.28" x 4.86" x 1.42" (185mm x 123.5mm x 35mm)
BiPAC 7300 RA
Dimensions: 5.51" x 3.54" x 1.38 (140.5mm*90.5mm*35mm)
Power Requirements
Input: 12V DC, 1A
Models & Supported Standards
BiPAC 7300(G) RA A: Annex A & Annex M (Annex A and Annex M: ADSL over POTS)
BiPAC 7300(G) RA U: Annex B & U-R2 (Annex B and Annex U-R2: ADSL over ISDN)
*Notes:
1. The router may require firmware modification for certain ADSL2/2+/ Annex M DSLAMs.
2. Specifications in this datasheet are subject to change without prior notice.
